1 - GEAR COVER
BSD-2605500042.A18
2605500042
|
£48.38
|
£58.06
|
|
2 - GEAR HOUSING
BSD-2605806312.A3
2605806312
|
£48.38
|
£58.06
|
|
3 - ECCENTRIC SHAFT
BSD-2606122001.A3
2606122001
|
£102.57
|
£123.08
|
|
4 - GROOVE BALL BEARING 20x42x12
BSD-1900900274.A39
1900900274
|
£27.23
|
£32.68
|
|
5 - RING GEAR Z=66
BSD-2606334040.A22
2606334040
|
£27.23
|
£32.68
|
|
6 - CYLINDRICAL GEAR Z=30
BSD-3606316057.A21
3606316057
|
£7.36
|
£8.83
|
|
7 - BEARING BOLT
BSD-2603105021.A7
2603105021
|
£2.61
|
£3.13
|
|
8 - CONNECTING ROD
BSD-2602001001.A31
2602001001
|
£54.42
|
£65.30
|
|
9 - RETAINING RING
BSD-2600224009.A17
2600224009
|
£1.75
|
£2.10
|
|
10 - NEEDLE-ROLLER CAGE
BSD-2600913035.A31
2600913035
|
£11.30
|
£13.56
|
|
11 - BEARING BOLT
BSD-2603100003.A63
2603100003
|
£2.61
|
£3.13
|
|
12 - POWER PISTON
BSD-2603104001.A24
2603104001
|
£54.42
|
£65.30
|
|
13 - BUSHING
BSD-2600422005.A25
2600422005
|
£18.96
|
£22.75
|
|
14 - UNION NUT
BSD-3603340017.A23
3603340017
|
£33.74
|
£40.49
|
|
15 - HOLLOW BOLT
BSD-2603455006.A5
2603455006
|
£2.80
|
£3.36
|
|
18 - NIBBLING PUNCH
BSD-2608639013.A6
2608639013
|
£24.49
|
£29.39
|
|
19 - HEX SOCKET HEAD CAP SCREW
BSD-2603414003.A19
2603414003
|
£6.52
|
£7.83
|
|
20 - NEEDLE BEARING
BSD-2600914011.A16
2600914011
|
£21.52
|
£25.83
|
|
21 - SPRING RETAINING RING DIN 471 20x1.2
BSD-2916650011.A10
2916650011
|
£2.16
|
£2.59
|
|
22 - DISC SPRING
BSD-2600550017.A16
2600550017
|
£5.58
|
£6.70
|
|
23 - NEEDLE ROLLER
BSD-1903201520.A10
1903201520
|
£1.75
|
£2.10
|
|
24 - SHIM 1.2 MM
BSD-1600100611.A27
1600100611
|
£1.75
|
£2.10
|
|
25 - LOCKING WASHER 5 DIN 6799
BSD-2916080908.A243
2916080908
|
£1.75
|
£2.10
|
|
28 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A53
2916690003
|
£1.75
|
£2.10
|
|
29 - SOCKET HEAD CAP SCREW DIN 84-BM4x40-8.8
BSD-2910021138.A21
2910021138
|
£2.61
|
£3.13
|
|
31 - SEAL BUSHING
BSD-2600300047.A51
2600300047
|
£2.61
|
£3.13
|
|
32 - BEARING FLANGE
BSD-2605700189.A3
2605700189
|
-
|
|
|
33 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A215
2600905007
|
-
|
|
|
34 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A179
2916660010
|
£1.75
|
£2.10
|
|
102 - COVER DISC
BSD-2600522009.A40
2600522009
|
-
|
|
|
103 - POLE SHOE 220V
BSD-2604220380.A4
2604220380
|
-
|
|
|
103 - POLE SHOE 220V
BSD-2604220381.A0
2604220381
|
-
|
|
|
104 - COMPRESSION SPRING
BSD-2604611024.A154
2604611024
|
£2.16
|
£2.59
|
|
106 - SQUARE NUT M4
BSD-2603320001.A8
2603320001
|
£1.75
|
£2.10
|
|
108 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A306
2910021125
|
£1.75
|
£2.10
|
|
112 - SHIM
BSD-2916010005.A9
2916010005
|
-
|
|
|
113 - SPIRAL SPRING
BSD-2604652000.A28
2604652000
|
-
|
|
|
115 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A157
2914501011
|
£1.75
|
£2.10
|
|
117 - ARMATURE 220V
BSD-2604010513.A4
2604010513
|
-
|
|
|
118 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A48
1900905019
|
£14.91
|
£17.89
|
|
120 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A78
2603435016
|
-
|
|
|
123 - SUPPRESSION CAPACITOR
BSD-2607329076.A21
2607329076
|
-
|
|
|
124 - ON-OFF SWITCH
BSD-2607200076.A6
2607200076
|
-
|
|
|
125 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A219
2603410001
|
£1.75
|
£2.10
|
|
126 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460427.A15
1604460427
|
£12.04
|
£14.45
|
|
127 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A214
2600703011
|
£2.80
|
£3.36
|
|
127 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1308
2600703012
|
£2.80
|
£3.36
|
|
127 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A159
2600703013
|
£2.61
|
£3.13
|
|
128 - CABLE CLIP
BSD-2601035001.A342
2601035001
|
£1.75
|
£2.10
|
|
129 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1620
2910211019
|
£1.75
|
£2.10
|
|
130 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A88
1601110013
|
-
|
|
|
131 - HOUSING COVER
BSD-2600508001.A27
2600508001
|
-
|
|
|
132 - REC CT-SUNK TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601020.A84
2910601020
|
-
|
|
|
135 - SWITCH HANDLE
BSD-2602026015.A128
2602026015
|
£1.75
|
£2.10
|
|
136 - ADJUSTING SLIDE
BSD-2602319004.A21
2602319004
|
-
|
|
|
138 - INTERMEDIATE PIECE
BSD-1600026000.A79
1600026000
|
£1.75
|
£2.10
|
|
139 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A24
2910211005
|
£1.75
|
£2.10
|
|
801 - MOTOR HOUSING
BSD-2605108902.A21
2605108902
|
-
|
|
|
802 - COMMUTATOR END SHIELD
BSD-2605808910.A5
2605808910
|
-
|
|
|
803 - ECCENTRIC SHAFT
BSD-2606122900.A0
2606122900
|
-
|
|
|
804 - LOWER DIE
BSD-2608639900.A16
2608639900
|
£83.12
|
£99.74
|
|
805 - CARBON-BRUSH SET
BSD-2604320902.A202
2604320902
|
-
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1090
160111A3H3
|
£2.61
|
£3.13
|
|
