1 - POLE HOUSING
BSD-1605108069.A1
1605108069
|
-
|
|
|
2 - POLE SHOE 220V
BSD-1604220048.A21
1604220048
|
-
|
|
|
3 - SOCKET HEAD CAP SCREW
BSD-2910021181.A69
2910021181
|
-
|
|
|
4 - SEALING DISK
BSD-1600108048.A229
1600108048
|
£1.75
|
£2.10
|
|
5 - SHIM 0.05 MM
BSD-1600102608.A4
1600102608
|
-
|
|
|
5 - SHIM 0.15 MM
BSD-1600102625.A16
1600102625
|
-
|
|
|
5 - SHIM 0.1 MM
BSD-1600102626.A2
1600102626
|
£2.16
|
£2.59
|
|
5 - SHIM 0.3 MM
BSD-1600102627.A21
1600102627
|
-
|
|
|
6 - ARMATURE 220V
BSD-1604011057.A0
1604011057
|
-
|
|
|
6/12 - MAGNETO BALL BEARING E 12 TD 615
BSD-1900900109.A10
1900900109
|
-
|
|
|
6/14 - MAGNETO BALL BEARING BO 17 D 615
BSD-1900900115.A3
1900900115
|
-
|
|
|
7 - MOTOR HOUSING
BSD-1605102030.A6
1605102030
|
-
|
|
|
7 - MOTOR HOUSING
BSD-1605102031.A5
1605102031
|
-
|
|
|
9 - SHIM 0.8 MM
BSD-1600102609.A19
1600102609
|
-
|
|
|
10 - SHIM 0.30 MM
BSD-1600102601.A18
1600102601
|
-
|
|
|
10 - SHIM 0.10 MM
BSD-1600102602.A3
1600102602
|
-
|
|
|
10 - SHIM 0.15 MM
BSD-1600102603.A18
1600102603
|
-
|
|
|
11 - INTERMEDIATE BEARING
BSD-1605820131.A5
1605820131
|
-
|
|
|
21 - AIR-DEFLECTOR RING
BSD-1600502001.A32
1600502001
|
-
|
|
|
23 - SCREW PLUG
BSD-1603465003.A51
1603465003
|
-
|
|
|
24 - HANDLE
BSD-1605132068.A8
1605132068
|
-
|
|
|
26 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07RN-F
BSD-1604460447.A66
1604460447
|
£21.68
|
£26.01
|
|
27 - GROMMET
BSD-1600703008.A27
1600703008
|
-
|
|
|
28 - FASTENING CLAMP
BSD-1601302013.A495
1601302013
|
£1.75
|
£2.10
|
|
29 - SEALING PLATE
BSD-1600113003.A377
1600113003
|
£2.80
|
£3.36
|
|
30 - COVER PLATE
BSD-1601037001.A18
1601037001
|
-
|
|
|
31 - GROMMET
BSD-1600306002.A49
1600306002
|
-
|
|
|
32 - SUPPRESSION CAPACITOR
BSD-1607329019.A52
1607329019
|
-
|
|
|
33 - FASTENING CLAMP
BSD-1601302003.A54
1601302003
|
-
|
|
|
34/1 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A55
2916011005
|
£1.75
|
£2.10
|
|
35 - CONTROL LEVER
BSD-1602026030.A365
1602026030
|
£10.10
|
£12.12
|
|
37 - SLEEVE TERMINAL
BSD-1600390006.A31
1600390006
|
-
|
|
|
38 - O-RING 54.0x3.0 MM
BSD-1600210004.A242
1600210004
|
£2.80
|
£3.36
|
|
40 - BEARING HOUSING
BSD-1605820900.A1
1605820900
|
-
|
|
|
41 - MANUFACTURER'S NAMEPLATE
BSD-1601110011.A52
1601110011
|
-
|
|
|
42 - SPINDLE WITH GEAR Z=14
BSD-1606328077.A4
1606328077
|
-
|
|
|
43 - TOOTHED GEAR Z=48
BSD-1606317063.A2
1606317063
|
-
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A171
1601331032
|
-
|
|
|
46 - GEAR HEAD
BSD-1608584004.A5
1608584004
|
-
|
|
|
46/00 - DIE CARRIER
BSD-1608042003.A0
1608042003
|
-
|
|
|
46/01 - THREADED BUSHING
BSD-1600361008.A4
1600361008
|
-
|
|
|
46/02 - TAPPET
BSD-1603104007.A2
1603104007
|
-
|
|
|
46/03 - CONNECTING ROD
BSD-1602001003.A2
1602001003
|
-
|
|
|
46/04 - STRAIGHT PIN
BSD-1603100024.A5
1603100024
|
-
|
|
|
46/05 - HEX NUT
BSD-1603300006.A4
1603300006
|
-
|
|
|
46/06 - ECCENTRIC SHAFT
BSD-1606110002.A2
1606110002
|
-
|
|
|
46/07 - CLAMP RING
BSD-1600224031.A5
1600224031
|
-
|
|
|
46/08 - TRANSVERSE MEMBER
BSD-1603121016.A2
1603121016
|
-
|
|
|
46/09 - THREADED RING
BSD-1603344045.A4
1603344045
|
-
|
|
|
46/11 - GEAR HOUSING
BSD-1605110021.A1
1605110021
|
-
|
|
|
46/12 - GUIDE BUSHING
BSD-1603314008.A2
1603314008
|
-
|
|
|
46/13 - GUIDE BUSHING
BSD-1609203000.A2
1609203000
|
-
|
|
|
46/14 - BUSHING
BSD-1600322030.A2
1600322030
|
-
|
|
|
46/16 - SUPPORT PIN
BSD-1603052009.A1
1603052009
|
-
|
|
|
46/17 - LOWER DIE
BSD-1608635021.A2
1608635021
|
-
|
|
|
46/18 - LOWER DIE
BSD-1608635022.A4
1608635022
|
-
|
|
|
46/19 - PLANING KNIFE
BSD-1608635023.A2
1608635023
|
-
|
|
|
46/20 - STRAIGHT PIN DIN 7-5m 6x16-St
BSD-2917510120.A3
2917510120
|
-
|
|
|
46/21 - NEEDLE BEARING
BSD-1609202006.A2
1609202006
|
-
|
|
|
46/22 - LUBRICATING NIPPLE
BSD-1609274002.A7
1609274002
|
-
|
|
|
46/23 - SET SCREW DIN 913-8.8-M8x35MM
BSD-1609234015.A1
1609234015
|
-
|
|
|
46/24 - HEX SOCKET HEAD CAP SCREW M 8x40 DIN 912-8.8
BSD-2910141250.A0
2910141250
|
-
|
|
|
46/25 - GROOVE BALL BEARING 6303 ZY DIN 625
BSD-1900905302.A0
1900905302
|
-
|
|
|
46/26 - NEEDLE-ROLLER CAGE
BSD-1609209003.A2
1609209003
|
-
|
|
|
46/27 - GROOVE BALL BEARING 6303 ZY DIN 625
BSD-1900905303.A6
1900905303
|
-
|
|
|
46/28 - SPRING RETAINING RING 47x1.75MM. DIN 472
BSD-2916660021.A4
2916660021
|
£4.26
|
£5.11
|
|
46/29 - GROOVE BALL BEARING 6200-Z DIN 625
BSD-1900905200.A29
1900905200
|
-
|
|
|
46/30 - PARALLEL KEY A 5x5x14 DIN 6885
BSD-1902300263.A10
1902300263
|
-
|
|
|
46/31 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A64
2916640006
|
£1.75
|
£2.10
|
|
46/32 - STRAIGHT PIN 4 M 6x32 DIN 7
BSD-2917510106.A3
2917510106
|
-
|
|
|
46/33 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A163
2910141242
|
£1.75
|
£2.10
|
|
46/650 - SEAL
BSD-1601015005.A15
1601015005
|
-
|
|
|
49 - GROOVE BALL BEARING 12x32x10
BSD-1900900302.A43
1900900302
|
-
|
|
|
52 - SOCKET HEAD CAP SCREW DIN 84-BM5x30-5.8
BSD-2910011166.A3
2910011166
|
£1.75
|
£2.10
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A209
2910021122
|
£2.16
|
£2.59
|
|
55 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x45-8.8
BSD-2910141172.A79
2910141172
|
£1.75
|
£2.10
|
|
56 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x50-8.8
BSD-2910141213.A66
2910141213
|
£2.61
|
£3.13
|
|
57 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A13
2910211006
|
£1.75
|
£2.10
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A107
2910021050
|
£1.75
|
£2.10
|
|
60 - SELF-CUTTING SCREW dia 3.9x13 MM
BSD-1603435000.A28
1603435000
|
-
|
|
|
70 - ROUND-HEAD GROOVED PIN DIN 1476-2x3-St
BSD-2917721031.A73
2917721031
|
£1.75
|
£2.10
|
|
71 - SEALING CORD
BSD-1601014002.A13
1601014002
|
-
|
|
|
76 - FELT WASHER
BSD-1600205008.A305
1600205008
|
£1.75
|
£2.10
|
|
650 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A549
2607950004
|
£1.75
|
£2.10
|
|
652 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A341
1907950007
|
£5.30
|
£6.36
|
|
653 - SINGLE-HEAD ENG. WRENCH SW30
BSD-1607950519.A3
1607950519
|
-
|
|
|
655 - AUXILIARY HANDLE M14
BSD-1602025022.A1428
1602025022
|
£13.41
|
£16.09
|
|
655 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1353
1602025030
|
£18.96
|
£22.75
|
|
803 - HANDLE
BSD-1605132060.A33
1605132060
|
-
|
|
|
804 - CARBON-BRUSH SET
BSD-1607014100.A19
1607014100
|
-
|
|
|
805 - CONTROL LEVER
BSD-1602026030.A363
1602026030
|
£10.10
|
£12.12
|
|
806 - SWITCH KIT
BSD-1607000034.A273
1607000034
|
-
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3975
160111A3H3
|
£2.61
|
£3.13
|
|
