1 - MOTOR HOUSING
BSD-2605104538.A28
2605104538
|
£16.41
|
£19.69
|
|
2 - FIELD 230-240V
BSD-2604220529.A32
2604220529
|
£23.86
|
£28.63
|
|
3 - ARMATURE 230-240V
BSD-2604011110.A0
2604011110
|
£33.74
|
£40.49
|
|
3/13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A539
1610905025
|
£6.52
|
£7.83
|
|
3/60 - FAN
BSD-2606610076.A100
2606610076
|
£3.72
|
£4.47
|
|
4 - SWITCH
BSD-2607200260.A1
2607200260
|
£11.30
|
£13.56
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460403.A157
1604460403
|
£16.41
|
£19.69
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A781
2600703017
|
£2.61
|
£3.13
|
|
7 - CABLE CLIP
BSD-2601035001.A73
2601035001
|
£1.75
|
£2.10
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601119322.A4
2601119322
|
-
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328026.A5
1617328026
|
£7.36
|
£8.83
|
|
14 - GROOVE BALL BEARING
BSD-1619P00290.A23
1619P00290
|
£6.52
|
£7.83
|
|
16 - BRUSH HOLDER
BSD-2604337016.A1
2604337016
|
£1.75
|
£2.10
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A274
2603410001
|
£1.75
|
£2.10
|
|
19 - SCREW 4x16
BSD-2603490022.A1499
2603490022
|
£1.75
|
£2.10
|
|
21 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1228
2603490017
|
£2.16
|
£2.59
|
|
22 - INNER RING
BSD-2600400035.A29
2600400035
|
£10.10
|
£12.12
|
|
25 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A179
2916640006
|
£1.75
|
£2.10
|
|
26 - FAN
BSD-2606610085.A0
2606610085
|
£8.67
|
£10.41
|
|
28 - ECCENTRIC
BSD-2600499041.A1
2600499041
|
£21.52
|
£25.83
|
|
29 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A236
2603410048
|
£1.75
|
£2.10
|
|
30 - NEEDLE BEARING
BSD-2600910012.A11
2600910012
|
£5.30
|
£6.36
|
|
32 - CONTACT STRAP
BSD-2601329053.A20
2601329053
|
£1.75
|
£2.10
|
|
34 - TENSIONING LEVER
BSD-2608045022.A3
2608045022
|
£8.67
|
£10.41
|
|
35 - V-RING
BSD-2600290030.A2
2600290030
|
£2.80
|
£3.36
|
|
36 - HOUSING COVER
BSD-2605500125.A12
2605500125
|
£10.10
|
£12.12
|
|
37 - SQUARE NUT DIN 562-M6-04
BSD-2915121006.A88
2915121006
|
£2.61
|
£3.13
|
|
38 - SEALING COVER
BSD-2600500019.A19
2600500019
|
£1.75
|
£2.10
|
|
39 - SANDER PLATE
BSD-2608000165.A5
2608000165
|
£33.74
|
£40.49
|
|
40 - SHAFT SEAL
BSD-2600290031.A27
2600290031
|
£2.80
|
£3.36
|
|
41 - SEALING DISK
BSD-2600590013.A24
2600590013
|
£2.16
|
£2.59
|
|
43 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A154
2603435042
|
£1.75
|
£2.10
|
|
44 - SUCTION HOOD
BSD-2600282017.A21
2600282017
|
£37.27
|
£44.72
|
|
45 - AIR GUIDE PLATE
BSD-2601328055.A40
2601328055
|
£2.61
|
£3.13
|
|
46 - SUCTION SOCKET
BSD-2601328053.A21
2601328053
|
£2.61
|
£3.13
|
|
47 - FELT STRIP
BSD-2601005017.A55
2601005017
|
£1.75
|
£2.10
|
|
48 - AIR-DEFLECTOR RING
BSD-2600034006.A4
2600034006
|
£8.67
|
£10.41
|
|
49 - PUSHER
BSD-2601035002.A85
2601035002
|
£2.16
|
£2.59
|
|
50 - SWING-PLATE
BSD-2608000166.A18
2608000166
|
£21.52
|
£25.83
|
|
51 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A473
1907950006
|
£4.26
|
£5.11
|
|
52 - HEX NUT DIN 439-BM8-04
BSD-2915051107.A71
2915051107
|
£1.75
|
£2.10
|
|
53 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A204
2603410049
|
£1.75
|
£2.10
|
|
55 - CONNECTING CABLE L=110 MM
BSD-2604448146.A54
2604448146
|
£1.75
|
£2.10
|
|
57 - SUPPRESSION FILTER
BSD-2604465090.A44
2604465090
|
£7.36
|
£8.83
|
|
754 - DUST BAG
BSD-2605411112.A28
2605411112
|
£8.74
|
£10.49
|
|
754/1 - DUST BAG
BSD-2605411113.A1
2605411113
|
£6.12
|
£7.34
|
|
754/2 - DUST BAG
BSD-2605411114.A28
2605411114
|
£17.49
|
£20.99
|
|
755 - AUXILIARY HANDLE
BSD-2602026069.A30
2602026069
|
£5.30
|
£6.36
|
|
768 - CARRYING CASE
BSD-2605438368.A1
2605438368
|
£23.49
|
£28.19
|
|
808 - NAMEPLATE
BSD-2601119348.A0
2601119348
|
-
|
|
|
811 - CARBON BRUSH
BSD-1607014117.A64
1607014117
|
£10.10
|
£12.12
|
|
833 - SPRING
BSD-2608005902.A0
2608005902
|
£16.41
|
£19.69
|
|
