1 - HOUSING SECTION
BSD-2605105964.A12
2605105964
|
£37.27
|
£44.72
|
|
2 - FIELD 110V
BSD-2604220751.A3
2604220751
|
£33.74
|
£40.49
|
|
4 - SWITCH
BSD-2607200688.A19
2607200688
|
£16.41
|
£19.69
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460204.A5
2604460204
|
£31.64
|
£37.97
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A187
2600703017
|
£2.61
|
£3.13
|
|
8 - NAMEPLATE
BSD-2601112262.A0
2601112262
|
£2.61
|
£3.13
|
|
9 - MANUFACTURER'S NAMEPLATE GSS 230 AVE
BSD-2601112337.A3
2601112337
|
£2.61
|
£3.13
|
|
14 - GROOVE BALL BEARING
BSD-1619P00290.A0
1619P00290
|
£6.52
|
£7.83
|
|
16 - BRUSH HOLDER
BSD-2604337003.A120
2604337003
|
£2.16
|
£2.59
|
|
19 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A28
2603490017
|
£2.16
|
£2.59
|
|
20 - REFERENCE PLATE
BSD-2601111477.A14
2601111477
|
£2.61
|
£3.13
|
|
22 - SUCTION PIECE
BSD-2601328094.A1
2601328094
|
£3.72
|
£4.47
|
|
23 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A86
2916640006
|
£1.75
|
£2.10
|
|
24 - SEALING DISK
BSD-2600590013.A18
2600590013
|
£2.16
|
£2.59
|
|
25 - V-RING
BSD-2600290030.A41
2600290030
|
£2.80
|
£3.36
|
|
26 - NEEDLE BEARING
BSD-2600910012.A0
2600910012
|
£5.30
|
£6.36
|
|
27 - INNER RING
BSD-2600400035.A5
2600400035
|
£10.10
|
£12.12
|
|
28 - ECCENTRIC
BSD-2602210045.A5
2602210045
|
£21.52
|
£25.83
|
|
29 - FAN
BSD-2606610085.A23
2606610085
|
£8.67
|
£10.41
|
|
30 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A198
2603410048
|
£1.75
|
£2.10
|
|
31 - SHAFT SEAL
BSD-2600290031.A6
2600290031
|
£2.80
|
£3.36
|
|
32 - SEALING COVER
BSD-2600500019.A0
2600500019
|
£1.75
|
£2.10
|
|
34 - SANDER PLATE
BSD-2600009019.A2
2600009019
|
£33.74
|
£40.49
|
|
35 - HEX NUT DIN 439-BM8-04
BSD-2915051107.A45
2915051107
|
£1.75
|
£2.10
|
|
37 - TAPPING SCREW
BSD-2603435086.A103
2603435086
|
£1.75
|
£2.10
|
|
40 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A75
2603435042
|
£1.75
|
£2.10
|
|
41 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A27
2603490017
|
£2.16
|
£2.59
|
|
42 - SUPPRESSOR BOX
BSD-2604465115.A7
2604465115
|
£7.36
|
£8.83
|
|
43 - DAMPING ELEMENT
BSD-2603203041.A11
2603203041
|
£1.75
|
£2.10
|
|
44 - SPEED GOVERNOR 110-127V
BSD-1607233557.A3
1607233557
|
£40.80
|
£48.96
|
|
45 - SQUARE NUT DIN 562-M6-04
BSD-2915121006.A64
2915121006
|
£2.61
|
£3.13
|
|
46 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A27
2603490023
|
£1.75
|
£2.10
|
|
47 - HOUSING COVER
BSD-2605500208.A9
2605500208
|
£12.04
|
£14.45
|
|
48 - SCREW 4x16
BSD-2603490022.A3191
2603490022
|
£1.75
|
£2.10
|
|
49 - PUSHER
BSD-2601035002.A24
2601035002
|
£2.16
|
£2.59
|
|
50 - SUCTION SOCKET
BSD-2601328054.A17
2601328054
|
£3.72
|
£4.47
|
|
51 - FELT STRIP
BSD-2601005017.A16
2601005017
|
£1.75
|
£2.10
|
|
54 - TENSIONING BRACKET
BSD-2609200378.A3
2609200378
|
£16.41
|
£19.69
|
|
56 - LEVER
BSD-2601901020.A3
2601901020
|
£5.87
|
£7.04
|
|
57 - THREAD-FORMING TAP. SCREW
BSD-2603410051.A30
2603410051
|
£1.75
|
£2.10
|
|
58 - SPRING WASHER
BSD-2600100713.A3
2600100713
|
£1.75
|
£2.10
|
|
59 - GUIDE BUSHING
BSD-2600499078.A13
2600499078
|
£2.16
|
£2.59
|
|
61 - PRESSURE BAR
BSD-2601014020.A1
2601014020
|
£4.26
|
£5.11
|
|
62 - COILED SPRING
BSD-2604651029.A12
2604651029
|
£2.80
|
£3.36
|
|
655 - DUST CHAMBER
BSD-2605411228.A8
2605411228
|
£45.67
|
£54.80
|
|
656 - AUXILIARY HANDLE
BSD-2602026175.A6
2602026175
|
£16.41
|
£19.69
|
|
680 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A897
1907950006
|
£4.26
|
£5.11
|
|
803 - ARMATURE 110V
BSD-2604011953.A2
2604011953
|
£72.18
|
£86.62
|
|
803/3/6 - FAN
BSD-2606610076.A29
2606610076
|
£3.72
|
£4.47
|
|
803/13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A439
1610905025
|
£6.52
|
£7.83
|
|
810 - CARBON BRUSH
BSD-1607014117.A209
1607014117
|
£10.10
|
£12.12
|
|
821 - SUCTION HOOD
BSD-2605510903.A3
2605510903
|
£68.42
|
£82.10
|
|
833 - SPRING
BSD-2608005902.A40
2608005902
|
£16.41
|
£19.69
|
|
836 - MOTOR HOUSING
BSD-2605105966.A13
2605105966
|
£23.86
|
£28.63
|
|
852 - SWING-PLATE
BSD-2601099901.A4
2601099901
|
£72.18
|
£86.62
|
|
