2 - SIDE-MILLING CUTTER Z=12
BSD-3608641010.A4
3608641010
|
-
|
|
|
|
3 - BASE PLATE
BSD-3601329005.A1
3601329005
|
-
|
|
|
|
4 - SWIVELLING LEVER
BSD-3602013006.A5
3602013006
|
£41.62
|
£49.95
|
|
|
5 - COVERING HOOD
BSD-3605500101.A14
3605500101
|
-
|
|
|
|
6 - TORSION SPRING
BSD-3604651003.A1
3604651003
|
£4.75
|
£5.70
|
|
|
7 - SWIVELLING AXIS
BSD-3603490009.A4
3603490009
|
-
|
|
|
|
8 - ECCENTRIC DISC
BSD-3602200000.A6
3602200000
|
-
|
|
|
|
9 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A199
2607950004
|
£1.75
|
£2.10
|
|
|
10 - THRUST MEMBER
BSD-3601000002.A1
3601000002
|
£2.33
|
£2.80
|
|
|
11 - PARALLEL-GUIDE
BSD-3601329004.A19
3601329004
|
-
|
|
|
|
12 - ROUND NUT M14
BSD-3603340009.A1
3603340009
|
-
|
|
|
|
13 - CLAMPING-FLANGE
BSD-3600328032.A20
3600328032
|
£8.49
|
£10.19
|
|
|
14 - DETENT PIN
BSD-2602305045.A24
2602305045
|
-
|
|
|
|
15 - STICKER
BSD-3601119024.A3
3601119024
|
£1.95
|
£2.34
|
|
|
16 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A53
1601110481
|
£2.16
|
£2.59
|
|
|
17 - KNURLED THUMBSCREW
BSD-3603490008.A1
3603490008
|
-
|
|
|
|
18 - THREAD-FORMING TAP. SCREW DIN 7500-M5x14MM
BSD-2914455059.A9
2914455059
|
-
|
|
|
|
19 - LOCKING WASHER
BSD-3600190008.A1
3600190008
|
-
|
|
|
|
20 - COMPRESSION SPRING
BSD-2604611008.A30
2604611008
|
-
|
|
|
|
21 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A40
2915011006
|
-
|
|
|
|
22 - PAN HEAD SCREW DIN 85-M6x20-4.8
BSD-2910095201.A7
2910095201
|
-
|
|
|
|
23 - SPACER BUSHING
BSD-1600309010.A38
1600309010
|
£2.61
|
£3.13
|
|
|
24 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-8.8
BSD-2910141154.A62
2910141154
|
£1.75
|
£2.10
|
|
|
25 - SUPPORT CLAMP
BSD-3602012000.A1
3602012000
|
£1.75
|
£2.10
|
|
|
26 - PAN HEAD SCREW DIN 922-M4x3x3-5.8
BSD-2910271900.A16
2910271900
|
£1.32
|
£1.58
|
|
|
27 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-8.8
BSD-2910141154.A63
2910141154
|
£1.75
|
£2.10
|
|
|
28 - HEX NUT DIN 934-M8-8-A
BSD-2915011009.A3
2915011009
|
£2.61
|
£3.13
|
|
|
29 - SHIM 0.5 MM
BSD-2600100577.A168
2600100577
|
£1.75
|
£2.10
|
|
|
30 - STICKER 13.16.19+22 MM
BSD-3601119025.A2
3601119025
|
-
|
|
|
|
31 - VERTEBRAS
BSD-3601251001.A2
3601251001
|
£3.34
|
£4.01
|
|
|
32 - PLAIN WASHER DIN 9021-A10.5-ST
BSD-2916015886.A2
2916015886
|
-
|
|
|
|
33 - SHIM WASHER 0.1 MM
BSD-2600100401.A4
2600100401
|
-
|
|
|
|
201 - MOTOR HOUSING
BSD-16051082CC.A74
16051082CC
|
£13.12
|
£15.75
|
|
|
202 - FIELD 230-240V
BSD-1604220224.A34
1604220224
|
-
|
|
|
|
204 - ON-OFF SWITCH
BSD-1607200086.A351
1607200086
|
£11.30
|
£13.56
|
|
|
204/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A564
2910110048
|
£1.75
|
£2.10
|
|
|
205 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460110.A37
1604460110
|
-
|
|
|
|
206 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1604
2600703012
|
£2.80
|
£3.36
|
|
|
207 - FASTENING CLAMP
BSD-1601302017.A853
1601302017
|
£1.75
|
£2.10
|
|
|
209 - MANUFACTURER'S NAMEPLATE
BSD-3601119022.A2
3601119022
|
-
|
|
|
|
212 - SUPPRESSION FILTER
BSD-1607328029.A75
1607328029
|
-
|
|
|
|
213 - BALL BEARING 7x19x6
BSD-2600905032.A998
2600905032
|
£5.30
|
£6.36
|
|
|
214 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A91
1600905011
|
£5.58
|
£6.70
|
|
|
215 - FAN
BSD-1606610121.A134
1606610121
|
£1.75
|
£2.10
|
|
|
218 - COMPRESSION SPRING
BSD-1604611026.A547
1604611026
|
£1.75
|
£2.10
|
|
|
222 - ADJUSTING SLIDE
BSD-1602319002.A31
1602319002
|
£2.61
|
£3.13
|
|
|
223 - SWITCH HANDLE
BSD-1602026057.A490
1602026057
|
£1.97
|
£2.36
|
|
|
225 - HOUSING COVER
BSD-1600508010.A92
1600508010
|
£7.36
|
£8.83
|
|
|
226 - RUBBER BUSHING
BSD-1600502020.A136
1600502020
|
£2.61
|
£3.13
|
|
|
227 - RUBBER RING
BSD-1600206025.A1067
1600206025
|
£2.16
|
£2.59
|
|
|
228 - ASSEMBLY OF SERVICE PARTS
BSD-1607000937.A3
1607000937
|
-
|
|
|
|
229 - AIR-DEFLECTOR RING
BSD-1601328005.A185
1601328005
|
£2.61
|
£3.13
|
|
|
231 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A168
2916660013
|
£2.16
|
£2.59
|
|
|
235 - SHIM 0.2 MM
BSD-1600136010.A100
1600136010
|
£2.61
|
£3.13
|
|
|
235 - SHIM 0.7 MM
BSD-1600136008.A1
1600136008
|
-
|
|
|
|
235 - SHIM 0.8 MM
BSD-1600136009.A4
1600136009
|
-
|
|
|
|
236 - SPRING WASHER
BSD-1600150011.A206
1600150011
|
£1.75
|
£2.10
|
|
|
237 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A232
1600290016
|
£2.61
|
£3.13
|
|
|
238 - CROWN GEAR Z=36
BSD-1606333601.A150
1606333601
|
£8.49
|
£10.19
|
|
|
239 - SPIRAL SPRING
BSD-1604652013.A814
1604652013
|
£1.75
|
£2.10
|
|
|
240 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A106
2916660009
|
£2.16
|
£2.59
|
|
|
241 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A385
1600910018
|
£5.30
|
£6.36
|
|
|
242 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A55
1600905006
|
£12.04
|
£14.45
|
|
|
243 - BEVEL GEAR Z=11
BSD-1606333242.A119
1606333242
|
£48.38
|
£58.06
|
|
|
245 - HEX NUT M7. SW10
BSD-1603300016.A541
1603300016
|
£1.75
|
£2.10
|
|
|
247 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A45
2910211018
|
£1.75
|
£2.10
|
|
|
248 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A451
1613435034
|
£1.75
|
£2.10
|
|
|
249 - SOCKET HEAD CAP SCREW M4x15 MM
BSD-1603412008.A1
1603412008
|
-
|
|
|
|
250 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A1088
2910211021
|
£1.75
|
£2.10
|
|
|
253 - CONNECTING CABLE L=95 MM
BSD-1604448005.A87
1604448005
|
£2.80
|
£3.36
|
|
|
254 - CONNECTING CABLE L=40 MM
BSD-1604448006.A33
1604448006
|
£2.61
|
£3.13
|
|
|
255 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A68
2912401021
|
£1.75
|
£2.10
|
|
|
305 - STICKER
BSD-1601110240.A41
1601110240
|
-
|
|
|
|
650 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A514
160202509T
|
£3.72
|
£4.47
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A336
1607950052
|
£3.72
|
£4.47
|
|
|
652 - DUST BAG
BSD-1605411028.A9
1605411028
|
£15.74
|
£18.89
|
|
|
653 - PARALLEL-GUIDE
BSD-3601329013.A10
3601329013
|
£93.88
|
£112.65
|
|
|
653/40 - WING NUT M6
BSD-1603339006.A175
1603339006
|
£2.52
|
£3.02
|
|
|
653/50 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A176
2910281201
|
£1.75
|
£2.10
|
|
|
653/60 - COUNTERSUNK-HEAD SCREW DIN 7991-M6x12-8.8
BSD-2910545193.A16
2910545193
|
£1.75
|
£2.10
|
|
|
653/70 - O-RING 4.0x1.5 MM
BSD-1610210043.A75
1610210043
|
£1.75
|
£2.10
|
|
|
700 - SIDE-MILLING CUTTER dia 105x20x2.2 MM. Z=12
BSD-3608641001.A12
3608641001
|
£26.66
|
£31.99
|
|
|
700 - SIDE-MILLING CUTTER Z=10. 2.8 MM
BSD-3608641009.A2
3608641009
|
-
|
|
|
|
701 - SIDE-MILLING CUTTER Z=8
BSD-3608641008.A18
3608641008
|
£44.69
|
£53.63
|
|
|
702 - FITTING dia 25x35 MM
BSD-1600499005.A136
1600499005
|
£3.49
|
£4.19
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A157
1607014116
|
£11.30
|
£13.56
|
|
|
813 - PUSH-BUTTON
BSD-1607000253.A194
1607000253
|
£2.49
|
£2.99
|
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A411
1600A003G4
|
£3.72
|
£4.47
|
|
|
821 - GEAR HOUSING
BSD-1605806480.A147
1605806480
|
£48.38
|
£58.06
|
|
|
830 - ARMATURE WITH FAN 230-240V
BSD-1604010259.A54
1604010259
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1628
160111A3H3
|
£2.61
|
£3.13
|
|
