2 - POLE SHOE 110-115V
BSD-1609201078.A2
1609201078
|
-
|
|
|
|
3 - ARMATURE 110-115V
BSD-1609201079.A1
1609201079
|
-
|
|
|
|
3/10 - GROOVE BALL BEARING 6 001 LLU C 3/3K DIN 625
BSD-1609200715.A43
1609200715
|
-
|
|
|
|
3/20 - GROOVE BALL BEARING 607 LLB C3/3K DIN 625
BSD-1609200716.A25
1609200716
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1609200748.A34
1609200748
|
-
|
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A773
1607000227
|
£23.86
|
£28.63
|
|
|
6 - GROMMET dia9x90 MM
BSD-1609207001.A181
1609207001
|
-
|
|
|
|
8 - NAMEPLATE
BSD-160111A3H3.A4876
160111A3H3
|
£2.61
|
£3.13
|
|
|
9 - REFERENCE PLATE
BSD-1601110044.A3
1601110044
|
-
|
|
|
|
10 - CARBON-BRUSH SET
BSD-1609202417.A19
1609202417
|
-
|
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-1609200887.A6
1609200887
|
-
|
|
|
|
15 - GEAR COVER
BSD-1609201550.A3
1609201550
|
-
|
|
|
|
16 - INTERMEDIATE PLATE
BSD-1609201077.A6
1609201077
|
-
|
|
|
|
17 - SEALING CAP
BSD-1609200026.A7
1609200026
|
-
|
|
|
|
18 - BRUSH HOLDER
BSD-1609200032.A22
1609200032
|
-
|
|
|
|
19 - PULLEY Z=13
BSD-1609200016.A6
1609200016
|
-
|
|
|
|
20 - TOOTHED BELT
BSD-1609200894.A0
1609200894
|
£21.68
|
£26.01
|
|
|
21 - DRIVER DISC
BSD-1609200052.A0
1609200052
|
-
|
|
|
|
22 - PULLEY
BSD-1609200015.A7
1609200015
|
-
|
|
|
|
23 - CLAMPING PLATE
BSD-1609200039.A13
1609200039
|
-
|
|
|
|
24 - FLAP
BSD-1609200031.A9
1609200031
|
-
|
|
|
|
25 - ROTARY HANDLE
BSD-1609200038.A0
1609200038
|
-
|
|
|
|
26 - THREADED SPINDLE
BSD-1609200045.A13
1609200045
|
-
|
|
|
|
27 - GRADUATED DIAL
BSD-1609200042.A0
1609200042
|
-
|
|
|
|
28 - SEALING PLATE
BSD-1609200043.A13
1609200043
|
-
|
|
|
|
29 - ADJUSTING SLIDE
BSD-1609201076.A0
1609201076
|
-
|
|
|
|
30 - CUTTER HEAD
BSD-1609201085.A3
1609201085
|
-
|
|
|
|
30/1 - HEX SOCKET HEAD CAP SCREW
BSD-1609201086.A25
1609201086
|
-
|
|
|
|
30/2 - PLAIN WASHER DIN 126-9-A2
BSD-2918660004.A4
2918660004
|
£1.75
|
£2.10
|
|
|
30/3 - PLANING KNIFE
BSD-1609200978.A15
1609200978
|
-
|
|
|
|
30/4 - RECEIVER RAIL
BSD-1609201129.A25
1609201129
|
-
|
|
|
|
31 - BASE PLATE
BSD-1609200019.A7
1609200019
|
-
|
|
|
|
37 - FLAP
BSD-1609200021.A6
1609200021
|
-
|
|
|
|
38 - SEAL RING
BSD-1609202009.A25
1609202009
|
-
|
|
|
|
40 - COMPRESSION SPRING
BSD-1604619017.A27
1604619017
|
£2.16
|
£2.59
|
|
|
41 - COILED SPRING
BSD-1609200044.A9
1609200044
|
-
|
|
|
|
45 - GROOVE BALL BEARING 6 001 LLU C 3/3K DIN 625
BSD-1609200715.A38
1609200715
|
-
|
|
|
|
46 - NEEDLE BEARING
BSD-1609209006.A5
1609209006
|
-
|
|
|
|
47 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A200
2910141158
|
£1.75
|
£2.10
|
|
|
48 - HEX SOCKET HEAD CAP SCREW M 5x16 MM
BSD-1609234023.A32
1609234023
|
-
|
|
|
|
49 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A668
2603490017
|
£2.16
|
£2.59
|
|
|
50 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A453
2912401020
|
£2.16
|
£2.59
|
|
|
51 - TAPPING SCREW B 3.9x32 DIN 7981
BSD-2910611082.A46
2910611082
|
£1.75
|
£2.10
|
|
|
52 - SET SCREW M 4x16 DIN 915-45H
BSD-2912081126.A10
2912081126
|
-
|
|
|
|
53 - HEX NUT DIN 934-M 10-m-8
BSD-2915011010.A20
2915011010
|
-
|
|
|
|
54 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A233
2916060006
|
£1.32
|
£1.58
|
|
|
55 - PLAIN WASHER 5.3 DIN 7349
BSD-2916201003.A24
2916201003
|
-
|
|
|
|
62 - ADHESIVE TAPE
BSD-1609200550.A6
1609200550
|
-
|
|
|
|
63 - FASTENING CLAMP
BSD-1609213000.A1
1609213000
|
-
|
|
|
|
65 - HEX NUT DIN 439-BM10-04
BSD-2915051108.A8
2915051108
|
£1.32
|
£1.58
|
|
|
66 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A40
2916011011
|
£1.75
|
£2.10
|
|
|
650 - SCREWDRIVER SW5
BSD-1609201069.A29
1609201069
|
-
|
|
|
|
651 - WIDTH STOP
BSD-1609200054.A30
1609200054
|
-
|
|
|
|
651/1 - STOP BRACKET
BSD-1609200029.A6
1609200029
|
-
|
|
|
|
651/2 - RUBBER RING G 9x13x3 MM
BSD-1609200056.A0
1609200056
|
-
|
|
|
|
651/3 - WING SCREW M6x20 MM
BSD-1609234016.A42
1609234016
|
-
|
|
|
|
651/4 - WING NUT M6
BSD-1609233000.A81
1609233000
|
-
|
|
|
|
651/5 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A142
2910281203
|
£2.61
|
£3.13
|
|
|
651/6 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A189
2910281196
|
-
|
|
|
|
651/7 - PLAIN WASHER dia6.4xdia16x2 MM
BSD-1609201082.A68
1609201082
|
-
|
|
|
|
651/8 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A500
2916011014
|
£1.75
|
£2.10
|
|
|
652 - DEPTH-GAUGE
BSD-1608132006.A36
1608132006
|
£3.49
|
£4.19
|
|
|
652/1 - STOP BRACKET
BSD-1601331039.A4
1601331039
|
-
|
|
|
|
652/2 - WING SCREW
BSD-1609234017.A10
1609234017
|
-
|
|
|
|
652/3 - RUBBER RING G 9x13x3 MM
BSD-1609200056.A1
1609200056
|
-
|
|
|
|
652/4 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A501
2916011014
|
£1.75
|
£2.10
|
|
|
710 - BASE
BSD-1609200980.A0
1609200980
|
-
|
|
|
