2 - FIELD 220-240V
BSD-2604220663.A1
2604220663
|
£23.86
|
£28.63
|
|
3 - ARMATURE 230-240V
BSD-2604011322.A8
2604011322
|
£54.42
|
£65.30
|
|
3/9 - FAN
BSD-2606610116.A10
2606610116
|
£2.61
|
£3.13
|
|
4 - SWITCH
BSD-2607200615.A2
2607200615
|
£8.67
|
£10.41
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460403.A188
1604460403
|
£16.41
|
£19.69
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A891
2600703017
|
£2.61
|
£3.13
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116746.A1
2601116746
|
£2.61
|
£3.13
|
|
12 - SUPPRESSION FILTER
BSD-2607329148.A11
2607329148
|
£7.36
|
£8.83
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A499
1610905025
|
£6.52
|
£7.83
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A201
2600905052
|
£7.36
|
£8.83
|
|
16 - BRUSH HOLDER
BSD-2604449026.A89
2604449026
|
£1.75
|
£2.10
|
|
17 - BRUSH HOLDER
BSD-2604449027.A2
2604449027
|
£1.75
|
£2.10
|
|
19 - SCREW 4x16
BSD-2603490022.A203
2603490022
|
£1.75
|
£2.10
|
|
20 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A54
2603410049
|
£1.75
|
£2.10
|
|
25 - BEARING FLANGE
BSD-2605719033.A1
2605719033
|
£27.23
|
£32.68
|
|
26 - ADJUSTING ECCENTRIC
BSD-2606110001.A38
2606110001
|
£3.72
|
£4.47
|
|
28 - PULLEY WHEEL
BSD-2600324010.A3
2600324010
|
£4.26
|
£5.11
|
|
29 - PULLEY WHEEL
BSD-2600324012.A8
2600324012
|
£7.36
|
£8.83
|
|
30 - ROTARY HANDLE
BSD-2602026136.A0
2602026136
|
£5.58
|
£6.70
|
|
31 - V-BELT
BSD-2604736013.A5
2604736013
|
£10.10
|
£12.12
|
|
32 - GEAR COVER
BSD-2605510220.A2
2605510220
|
£7.36
|
£8.83
|
|
33 - SCALE PLATE
BSD-2601120009.A6
2601120009
|
£11.30
|
£13.56
|
|
34 - CAP-HANDLE
BSD-2605500184.A0
2605500184
|
£1.75
|
£2.10
|
|
35 - BRUSH-COVER
BSD-2605510208.A5
2605510208
|
£7.36
|
£8.83
|
|
38 - SHEET METAL COVER
BSD-2601098036.A30
2601098036
|
£2.16
|
£2.59
|
|
39 - GUIDE BUSHING
BSD-2600324008.A45
2600324008
|
£1.75
|
£2.10
|
|
40 - AIR-DEFLECTOR RING
BSD-2600290009.A36
2600290009
|
£3.72
|
£4.47
|
|
41 - SPRING PLATE
BSD-2601290016.A58
2601290016
|
£2.16
|
£2.59
|
|
42 - THREAD-FORMING TAP. SCREW M 5x12 MM
BSD-2603435027.A8
2603435027
|
£1.75
|
£2.10
|
|
44 - SQUARE NUT M6
BSD-2603320004.A90
2603320004
|
£1.75
|
£2.10
|
|
45 - TORSION SPRING
BSD-2604651007.A45
2604651007
|
£1.75
|
£2.10
|
|
47 - RATCHET CAP
BSD-2600590006.A1264
2600590006
|
£1.75
|
£2.10
|
|
48 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A67
2603433000
|
£1.75
|
£2.10
|
|
49 - HANDLE PLATE
BSD-2605409030.A0
2605409030
|
£21.68
|
£26.01
|
|
53 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A60
2916011010
|
£1.75
|
£2.10
|
|
54 - OFFSET SCREWDRIVER
BSD-2607950045.A15
2607950045
|
£2.16
|
£2.59
|
|
55 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A76
2600905064
|
£11.30
|
£13.56
|
|
57 - CONNECTING CABLE
BSD-2604448059.A24
2604448059
|
-
|
|
|
58 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1592
2603490023
|
£1.75
|
£2.10
|
|
60 - DEFLECTOR PIPE
BSD-2600409028.A9
2600409028
|
£10.10
|
£12.12
|
|
61 - PLUG-IN MODULE
BSD-2605500185.A2
2605500185
|
£4.26
|
£5.11
|
|
62 - SQUARE NUT M8
BSD-2603320003.A30
2603320003
|
£1.75
|
£2.10
|
|
63 - ROUND NUT M6
BSD-2603342006.A80
2603342006
|
£1.75
|
£2.10
|
|
70 - PLANER HEAD
BSD-2608584683.A3
2608584683
|
£68.42
|
£82.10
|
|
70/2 - PLANING KNIFE
BSD-2608635341.A44
2608635341
|
£16.41
|
£19.69
|
|
70/3 - GRIPPING WEDGE
BSD-2603111001.A18
2603111001
|
£13.12
|
£15.75
|
|
70/4 - SET SCREW
BSD-2603400016.A7
2603400016
|
£1.75
|
£2.10
|
|
70/6 - BEARING BRACKET
BSD-2605819012.A9
2605819012
|
£21.52
|
£25.83
|
|
70/7 - NEEDLE BEARING
BSD-2600914025.A7
2600914025
|
-
|
|
|
70/8 - COILED SPRING PIN DIN 7343-3.5x8 MM
BSD-2917800303.A47
2917800303
|
£1.75
|
£2.10
|
|
71 - PLANING KNIFE
BSD-2608635341.A45
2608635341
|
£16.41
|
£19.69
|
|
76 - KNIFE GUARD
BSD-2601329112.A2
2601329112
|
£2.61
|
£3.13
|
|
77 - TORSION SPRING
BSD-2604651016.A8
2604651016
|
£1.75
|
£2.10
|
|
80 - SPEED GOVERNOR 230-240V
BSD-2607233064.A5
2607233064
|
£59.53
|
£71.44
|
|
81 - CONTACT STRAP
BSD-2601329110.A8
2601329110
|
£1.75
|
£2.10
|
|
210 - NAMEPLATE
BSD-2601116497.A1
2601116497
|
-
|
|
|
801 - HOUSING
BSD-2605190918.A2
2605190918
|
£81.81
|
£98.17
|
|
808 - NAMEPLATE
BSD-2601116763.A0
2601116763
|
-
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014016.A7
2607014016
|
£11.30
|
£13.56
|
|
