1 - MOTOR HOUSING
BSD-1615102072.A5
1615102072
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-3614220503.A0
3614220503
|
-
|
|
|
|
2/10 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A257
1901350003
|
£1.75
|
£2.10
|
|
|
2/20 - END SPLICE dia1.3xdia1.6x10 MM
BSD-1610452003.A34
1610452003
|
-
|
|
|
|
3 - SEAL RING
BSD-1610205000.A2
1610205000
|
-
|
|
|
|
4 - NEEDLE-ROLLER BEARING
BSD-1610910052.A35
1610910052
|
£21.68
|
£26.01
|
|
|
5 - ARMATURE WITH FAN 220-230V
BSD-1614011030.A0
1614011030
|
-
|
|
|
|
6 - FLANGED BEARING
BSD-1615805045.A18
1615805045
|
-
|
|
|
|
7 - GROOVE BALL BEARING
BSD-1610905000.A19
1610905000
|
-
|
|
|
|
8 - INTERMEDIATE PLATE
BSD-1611038015.A18
1611038015
|
-
|
|
|
|
9 - FAN
BSD-1616610044.A37
1616610044
|
-
|
|
|
|
10 - HOUSING COVER
BSD-1615500123.A18
1615500123
|
-
|
|
|
|
12 - SPIRAL SPRING
BSD-1614652000.A6
1614652000
|
-
|
|
|
|
13 - SEALING CAP
BSD-3615500502.A18
3615500502
|
-
|
|
|
|
16 - BEARING HOUSING
BSD-1615820050.A5
1615820050
|
-
|
|
|
|
17 - NEEDLE BEARING dia35xdia42x12 MM
BSD-1610910051.A5
1610910051
|
-
|
|
|
|
19 - NEEDLE BEARING
BSD-1610910048.A22
1610910048
|
-
|
|
|
|
20 - ECCENTRIC SHAFT Z=47
BSD-1616110019.A3
1616110019
|
-
|
|
|
|
20/10 - BEARING BOLT
BSD-1613100007.A20
1613100007
|
£5.87
|
£7.04
|
|
|
21 - CYLINDRICAL GEAR Z=18
BSD-1616317013.A36
1616317013
|
-
|
|
|
|
22 - BUSHING
BSD-1610300043.A38
1610300043
|
£12.04
|
£14.45
|
|
|
23 - GEAR HOUSING
BSD-1615806017.A17
1615806017
|
-
|
|
|
|
24 - GUIDE RAIL
BSD-1612317003.A36
1612317003
|
-
|
|
|
|
26 - HAMMER PISTON
BSD-1618700033.A17
1618700033
|
-
|
|
|
|
27 - STRIKER
BSD-1618710030.A37
1618710030
|
-
|
|
|
|
30 - SPACER BUSHING
BSD-1610322004.A37
1610322004
|
-
|
|
|
|
31 - SUPPORTING DISC
BSD-1610114012.A39
1610114012
|
£11.30
|
£13.56
|
|
|
33 - BIT HOLDER
BSD-1618598062.A4
1618598062
|
-
|
|
|
|
34 - RETAINING SNAP RING
BSD-1610224001.A27
1610224001
|
£1.75
|
£2.10
|
|
|
40 - SEALING CAP
BSD-1615500194.A3
1615500194
|
-
|
|
|
|
41 - HANDLE
BSD-1615133019.A2
1615133019
|
-
|
|
|
|
42 - SHIM dia32xdia25x0.3 MM
BSD-2100102016.A38
2100102016
|
-
|
|
|
|
43 - ON-OFF SWITCH
BSD-1617200017.A52
1617200017
|
-
|
|
|
|
43/10 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A35
2603410001
|
£1.75
|
£2.10
|
|
|
44 - SUPPRESSION FILTER
BSD-1617328002.A71
1617328002
|
-
|
|
|
|
44/10 - END SPLICE dia1.3xdia1.6x10 MM
BSD-1610452003.A47
1610452003
|
-
|
|
|
|
45 - THRUST NEEDLE RIM
BSD-1610920000.A1
1610920000
|
£4.26
|
£5.11
|
|
|
46 - THRUST BEARING DISC 1.0 MM
BSD-1610102015.A0
1610102015
|
£2.80
|
£3.36
|
|
|
47 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A161
1607000227
|
£23.86
|
£28.63
|
|
|
47/10 - END SPLICE dia1.3xdia1.6x10 MM
BSD-1610452003.A48
1610452003
|
-
|
|
|
|
47/20 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A248
1901350003
|
£1.75
|
£2.10
|
|
|
48 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A641
1600703009
|
£5.58
|
£6.70
|
|
|
48 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1129
3600703011
|
£2.80
|
£3.36
|
|
|
49 - FASTENING CLAMP
BSD-1601302013.A192
1601302013
|
£1.75
|
£2.10
|
|
|
50 - RUBBER BUFFER
BSD-1611091004.A18
1611091004
|
-
|
|
|
|
52 - NAMEPLATE
BSD-160111A3H3.A312
160111A3H3
|
£2.61
|
£3.13
|
|
|
54 - SEALING CAP
BSD-1610501031.A0
1610501031
|
-
|
|
|
|
56 - O-RING 35.0x1.5 MM
BSD-1600210010.A157
1600210010
|
£2.80
|
£3.36
|
|
|
56 - RETAINING RING 22 DIN 9045
BSD-2916603012.A45
2916603012
|
-
|
|
|
|
57 - PLAIN WASHER 1.0 MM
BSD-1600102623.A51
1600102623
|
£1.32
|
£1.58
|
|
|
58 - SPRING WASHER DIN 137-A4
BSD-1600150006.A405
1600150006
|
-
|
|
|
|
59 - O-RING 28.0x6.0 MM
BSD-1610210015.A7
1610210015
|
-
|
|
|
|
61 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A424
1602381001
|
-
|
|
|
|
62 - SPRING RETAINING RING DIN 472-28x1.2 MM
BSD-2916660011.A117
2916660011
|
£1.75
|
£2.10
|
|
|
63 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A214
2916680006
|
-
|
|
|
|
64 - ROUND-HEAD GROOVED PIN DIN 1476-2x8-ST
BSD-2917721035.A0
2917721035
|
-
|
|
|
|
65 - RETAINING RING 26 DIN 9045
BSD-2916600014.A7
2916600014
|
-
|
|
|
|
66 - SEALING PLATE
BSD-1611015006.A39
1611015006
|
-
|
|
|
|
67 - SEALING PLATE
BSD-1611015007.A1
1611015007
|
£3.34
|
£4.01
|
|
|
68 - SEALING PLATE 1.5 MM
BSD-1611015015.A13
1611015015
|
£1.95
|
£2.34
|
|
|
70 - HEX NUT DIN 985-M8-8
BSD-2915061005.A106
2915061005
|
£2.61
|
£3.13
|
|
|
74 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A446
2910021116
|
£2.16
|
£2.59
|
|
|
74 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A288
2910211018
|
£1.75
|
£2.10
|
|
|
74 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1017
2910021118
|
£1.75
|
£2.10
|
|
|
75 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-5.8
BSD-2910011120.A276
2910011120
|
£1.75
|
£2.10
|
|
|
77 - SOCKET HEAD CAP SCREW DIN 84-BM5x50-8.8
BSD-2910021174.A6
2910021174
|
£1.32
|
£1.58
|
|
|
80 - HEX SOCKET HEAD CAP SCREW
BSD-3603414028.A46
3603414028
|
£1.75
|
£2.10
|
|
|
80 - HEX SOCKET HEAD CAP SCREW M5x20 MM
BSD-1613414005.A3
1613414005
|
-
|
|
|
|
82 - HEX SOCKET HEAD CAP SCREW M5x25 DIN 912-10.9
BSD-2910151164.A64
2910151164
|
£1.75
|
£2.10
|
|
|
83 - PARTS SET
BSD-1617000120.A26
1617000120
|
-
|
|
|
|
84 - HEX SOCKET HEAD CAP SCREW
BSD-1617000121.A27
1617000121
|
-
|
|
|
|
85 - TAPPING SCREW DIN 7971-BZ2.9x16
BSD-2910211007.A87
2910211007
|
£1.75
|
£2.10
|
|
|
86 - TAPPING SCREW DIN 7972-B3.9x13
BSD-2910601118.A94
2910601118
|
£1.75
|
£2.10
|
|
|
87 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A139
2910211011
|
£1.75
|
£2.10
|
|
|
88 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A861
2910211021
|
£1.75
|
£2.10
|
|
|
89 - CYLINDRICAL GEAR Z=43
BSD-1616309006.A6
1616309006
|
-
|
|
|
|
91 - KICK-OUT COUPLING
BSD-1616490004.A4
1616490004
|
-
|
|
|
|
92 - O-RING 25x2.5 MM
BSD-1900210125.A17
1900210125
|
£7.36
|
£8.83
|
|
|
94 - BALL DIN 5401-5 G28
BSD-1903230009.A354
1903230009
|
£1.75
|
£2.10
|
|
|
95 - KICK-OUT COUPLING
BSD-1616490004.A3
1616490004
|
-
|
|
|
|
97 - COUPLING HALF
BSD-1616432004.A1
1616432004
|
-
|
|
|
|
98 - COMPRESSION SPRING
BSD-1614612001.A6
1614612001
|
-
|
|
|
|
99/10 - END SPLICE dia1.3xdia1.6x10 MM
BSD-1610452003.A49
1610452003
|
-
|
|
|
|
103 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x18-8.8
BSD-2910141199.A74
2910141199
|
£3.72
|
£4.47
|
|
|
103 - HEX SOCKET HEAD CAP SCREW M5x20 MM
BSD-1613414005.A2
1613414005
|
-
|
|
|
|
106 - MANUFACTURER'S NAMEPLATE
BSD-1611110194.A9
1611110194
|
-
|
|
|
|
650 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A66
1613001003
|
£4.25
|
£5.10
|
|
|
651 - CARRYING CASE
BSD-1615438142.A13
1615438142
|
-
|
|
|
|
651 - CARRYING CASE
BSD-1615438065.A1
1615438065
|
-
|
|
|
|
654 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A7
2607950004
|
£1.75
|
£2.10
|
|
|
700 - SEALING CAP
BSD-2600508018.A30
2600508018
|
£2.61
|
£3.13
|
|
|
701 - BIT HOLDER
BSD-1618598006.A2
1618598006
|
-
|
|
|
|
800 - PARTS SET
BSD-1617000022.A14
1617000022
|
-
|
|
|
|
801 - KICK-OUT COUPLING
BSD-1616490004.A5
1616490004
|
-
|
|
|
|
805 - WEAR AND TEAR PART SET
BSD-1617000018.A46
1617000018
|
-
|
|
|
|
806 - TOOL HOLDER SET
BSD-1617000016.A1
1617000016
|
-
|
|
|
|
807 - LOCKING BOLT SET
BSD-1617000014.A116
1617000014
|
£24.45
|
£29.34
|
|
|
808 - CARBON-BRUSH SET
BSD-1617014110.A20
1617014110
|
£18.96
|
£22.75
|
|
|
809 - PARTS SET
BSD-1617010004.A0
1617010004
|
-
|
|
|
|
810 - BEVEL GEAR Z=29
BSD-1616333001.A1
1616333001
|
-
|
|
|
|
811 - TOOTHED SHAFT Z=8
BSD-1616333004.A6
1616333004
|
-
|
|
|
|
813 - WEAR AND TEAR PART SET
BSD-1617000018.A45
1617000018
|
-
|
|
|
