1 - MOTOR HOUSING
BSD-3615102507.A7
3615102507
|
-
|
|
|
|
2 - UN. FLANGE-MTD. MOTOR 220-240V
BSD-1617220073.A10
1617220073
|
-
|
|
|
|
4 - SWITCH
BSD-1617200048.A49
1617200048
|
£18.96
|
£22.75
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A84
2910011088
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07 RN-F
BSD-1604460449.A29
1604460449
|
£27.23
|
£32.68
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A111
1610703053
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A652
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A647
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110695.A2
1611110695
|
-
|
|
|
|
13 - GROOVE BALL BEARING
BSD-2610909310.A31
2610909310
|
£16.41
|
£19.69
|
|
|
14 - NEEDLE-ROLLER BEARING
BSD-1610910089.A46
1610910089
|
-
|
|
|
|
15 - FAN
BSD-1616610078.A1
1616610078
|
-
|
|
|
|
20 - TOOLHOLDER
BSD-1618597068.A0
1618597068
|
£93.88
|
£112.65
|
|
|
21 - PROTECTIVE CAP
BSD-1610508023.A3
1610508023
|
£8.67
|
£10.41
|
|
|
22 - PROTECTION SLEEVE
BSD-1610591014.A3
1610591014
|
£5.30
|
£6.36
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A89
1610520001
|
£12.04
|
£14.45
|
|
|
24 - SPACER TUBE
BSD-1610590006.A1
1610590006
|
£8.67
|
£10.41
|
|
|
25 - STOPPING DEVICE
BSD-1612300027.A103
1612300027
|
£11.30
|
£13.56
|
|
|
26 - INDEXING DISK
BSD-1610290025.A56
1610290025
|
£6.52
|
£7.83
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A27
1614621000
|
£2.80
|
£3.36
|
|
|
31 - DAMPING RING
BSD-1610290030.A2
1610290030
|
£2.61
|
£3.13
|
|
|
35 - HAMMER PIPE
BSD-1615806113.A10
1615806113
|
£88.07
|
£105.68
|
|
|
38 - COVERING HOOD
BSD-1615190056.A5
1615190056
|
-
|
|
|
|
39 - COVERING HOOD
BSD-1615190057.A1
1615190057
|
-
|
|
|
|
41 - STRIKER PIN
BSD-1613124046.A4
1613124046
|
£16.74
|
£20.09
|
|
|
43 - BEARING COVER
BSD-1615808083.A7
1615808083
|
£27.31
|
£32.77
|
|
|
45 - INTERMEDIATE RING
BSD-1610290032.A2
1610290032
|
£3.72
|
£4.47
|
|
|
47 - NOTCHED PLATE
BSD-1611329016.A3
1611329016
|
£9.49
|
£11.39
|
|
|
48 - GEAR SLEEVE
BSD-1616334011.A10
1616334011
|
£27.23
|
£32.68
|
|
|
51 - CROWN GEAR Z=49
BSD-1616333031.A3
1616333031
|
£70.24
|
£84.29
|
|
|
53 - STOP DISC
BSD-1610190026.A13
1610190026
|
£5.58
|
£6.70
|
|
|
54 - CONTROL DISC
BSD-1610190024.A0
1610190024
|
£21.52
|
£25.83
|
|
|
56 - HAMMER PISTON
BSD-1618700066.A13
1618700066
|
£18.96
|
£22.75
|
|
|
57 - STRIKER
BSD-1618710066.A3
1618710066
|
£21.68
|
£26.01
|
|
|
70 - CONNECTING ROD
BSD-1612001034.A10
1612001034
|
£27.23
|
£32.68
|
|
|
71 - STRAIGHT PIN
BSD-1613100020.A2
1613100020
|
£2.16
|
£2.59
|
|
|
73 - HOUSING COVER
BSD-1615500291.A3
1615500291
|
£11.30
|
£13.56
|
|
|
74 - RETAINING BRACKET
BSD-1612386004.A1
1612386004
|
£14.91
|
£17.89
|
|
|
75 - HANDLE
BSD-1615132055.A2
1615132055
|
£33.74
|
£40.49
|
|
|
76 - CLAMP HANDLE
BSD-1612026057.A8
1612026057
|
£10.10
|
£12.12
|
|
|
81 - SWITCH-PAWL
BSD-1612026056.A2
1612026056
|
£10.82
|
£12.99
|
|
|
82 - LIGHT CONDUCTOR
BSD-1615510000.A77
1615510000
|
£2.16
|
£2.59
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A231
160202507H
|
£11.30
|
£13.56
|
|
|
85 - SUPPORT CLAMP
BSD-1618040059.A4
1618040059
|
£8.67
|
£10.41
|
|
|
97 - SUPPORTING DISC 2.0 MM
BSD-1610102032.A3
1610102032
|
£5.30
|
£6.36
|
|
|
99 - SUPPORTING DISC
BSD-1610114020.A3
1610114020
|
£5.30
|
£6.36
|
|
|
102 - SHIM 0.2 MM
BSD-1610102036.A10
1610102036
|
£2.80
|
£3.36
|
|
|
103 - THRUST RING
BSD-1610290034.A11
1610290034
|
£7.36
|
£8.83
|
|
|
111 - BUSHING
BSD-3610501500.A3
3610501500
|
£21.68
|
£26.01
|
|
|
112 - THREADED RING
BSD-3613461500.A23
3613461500
|
£12.04
|
£14.45
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A41
1613435009
|
£1.75
|
£2.10
|
|
|
114 - O-RING 30x2 MM
BSD-1900210130.A62
1900210130
|
£3.72
|
£4.47
|
|
|
115 - PROTECTIVE CAP
BSD-1610508027.A1
1610508027
|
£2.80
|
£3.36
|
|
|
116 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A102
1610913029
|
£4.26
|
£5.11
|
|
|
117 - NEEDLE-ROLLER ASSEMBLY dia10 MM
BSD-1610913011.A17
1610913011
|
£6.52
|
£7.83
|
|
|
119 - NEEDLE-ROLLER BEARING
BSD-1610910081.A20
1610910081
|
£14.91
|
£17.89
|
|
|
120 - INNER RING
BSD-1610290037.A2
1610290037
|
£16.41
|
£19.69
|
|
|
121 - BEARING RING
BSD-1610290035.A2
1610290035
|
£18.96
|
£22.75
|
|
|
124 - THRUST BEARING DISC
BSD-1610190029.A4
1610190029
|
£14.91
|
£17.89
|
|
|
125 - TORX OVAL-HEAD SCREW 5.5x25
BSD-1613435010.A54
1613435010
|
£2.16
|
£2.59
|
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A534
2910211019
|
£1.75
|
£2.10
|
|
|
129 - NEEDLE-ROLLER BEARING
BSD-1610910085.A23
1610910085
|
£14.91
|
£17.89
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110696.A2
1611110696
|
-
|
|
|
|
137 - PLUG
BSD-1610591015.A12
1610591015
|
£3.72
|
£4.47
|
|
|
138 - SEALING FRAME
BSD-1611015043.A13
1611015043
|
£5.30
|
£6.36
|
|
|
139 - SEALING DISK
BSD-1610290036.A11
1610290036
|
£4.26
|
£5.11
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290028.A31
1610290028
|
£3.72
|
£4.47
|
|
|
142 - OIL RETURN RING
BSD-3613344500.A31
3613344500
|
£10.10
|
£12.12
|
|
|
143 - RETAINING RING DIN 7993-28x2
BSD-1614601021.A39
1614601021
|
£7.36
|
£8.83
|
|
|
144 - SUPPORTING DISC
BSD-1610190028.A9
1610190028
|
-
|
|
|
|
153 - SPRING RETAINING RING DIN 472-22x1MM
BSD-2916660007.A40
2916660007
|
£1.75
|
£2.10
|
|
|
154 - SPRING RETAINING RING DIN 472-68x2.5MM
BSD-2916660040.A15
2916660040
|
£2.16
|
£2.59
|
|
|
155 - RETAINING RING
BSD-1614601020.A15
1614601020
|
£1.75
|
£2.10
|
|
|
156 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A81
2916650003
|
£1.75
|
£2.10
|
|
|
160 - O-RING 45.0x6.0 MM
BSD-1610210132.A2
1610210132
|
£2.80
|
£3.36
|
|
|
161 - DAMPING RING
BSD-1610290031.A10
1610290031
|
£2.61
|
£3.13
|
|
|
162 - O-RING 28.0x5.0 MM
BSD-1610210133.A11
1610210133
|
£5.30
|
£6.36
|
|
|
163 - O-RING 62.0x3.0 MM
BSD-1610210134.A2
1610210134
|
£4.26
|
£5.11
|
|
|
164 - O-RING 18x3 MM
BSD-1900210117.A77
1900210117
|
£3.72
|
£4.47
|
|
|
165 - O-RING 21.0x3.5 MM
BSD-1610210096.A49
1610210096
|
£2.80
|
£3.36
|
|
|
166 - O-RING 34.0x2.0 MM
BSD-1610210084.A8
1610210084
|
£1.75
|
£2.10
|
|
|
167 - ROTARY SHAFT LIP SEAL
BSD-1610283026.A4
1610283026
|
£5.58
|
£6.70
|
|
|
170 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A91
2914551117
|
£1.75
|
£2.10
|
|
|
171 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A138
2910141158
|
£1.75
|
£2.10
|
|
|
172 - MICROENCAPSULATED SCREW
BSD-1613414021.A33
1613414021
|
£2.16
|
£2.59
|
|
|
173 - SCREW AND WASHER ASSEMBLY 6.3x32
BSD-1613433001.A2
1613433001
|
£1.75
|
£2.10
|
|
|
174 - TORX OVAL-HEAD SCREW 5.5x25
BSD-1613435010.A53
1613435010
|
£2.16
|
£2.59
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A119
1615430010
|
£6.52
|
£7.83
|
|
|
750 - CARRYING CASE
BSD-2605438322.A3
2605438322
|
-
|
|
|
|
784 - AUXILIARY HANDLE
BSD-1612025043.A3
1612025043
|
£33.74
|
£40.49
|
|
|
792 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A51
1613001003
|
£4.25
|
£5.10
|
|
|
801 - UN. FLANGE-MTD. MOTOR 220-240V
BSD-1617220073.A5
1617220073
|
-
|
|
|
|
803 - UN. FLANGE-MTD. MOTOR 220-240V
BSD-1617220073.A6
1617220073
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3213
160111A3H3
|
£2.61
|
£3.13
|
|
|
837 - CONTROL BUSHING
BSD-1617000294.A10
1617000294
|
£31.64
|
£37.97
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000992.A2
1617000992
|
£187.56
|
£225.07
|
|
|
842 - BRUSH HOLDER
BSD-1614336016.A12
1614336016
|
-
|
|
|
|
842/030 - SPIRAL SPRING
BSD-1604652015.A316
1604652015
|
£2.80
|
£3.36
|
|
|
842/050 - CARBON-BRUSH SET
BSD-1617014126.A11
1617014126
|
£14.91
|
£17.89
|
|
|
842/080 - TAPPING SCREW DIN 7981-ST3.5x16-C-H
BSD-2910611012.A35
2910611012
|
-
|
|
|
|
846 - CYLINDRICAL ROLLER
BSD-1617000241.A3
1617000241
|
£5.58
|
£6.70
|
|
|
849 - CONTROL FORK
BSD-1617000991.A11
1617000991
|
£18.96
|
£22.75
|
|
|
860 - SPUR WHEEL CLUTCH Z=53
BSD-1617000993.A11
1617000993
|
£114.88
|
£137.86
|
|
|
872 - ECCENTRIC COG WHEEL Z=50
BSD-1617000994.A2
1617000994
|
£93.88
|
£112.65
|
|
|
880 - SPEED GOVERNOR 220-240V
BSD-1617233026.A10
1617233026
|
£46.82
|
£56.18
|
|
|
887 - CLAMPING BAND dia87 MM
BSD-1617000807.A11
1617000807
|
£18.96
|
£22.75
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000224.A12
1617000224
|
£72.18
|
£86.62
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000225.A1
1617000225
|
£81.81
|
£98.17
|
|
