An exploded drawing and listing for the Bosch GOP 55-36 / 3601B31130 / CH 230 Volt
Ex VAT Inc VAT
4 - ELECTRONICS MODULE BSD-2609125028.A16 2609125028 £18.96 £22.75
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H05 RN-F BSD-1604460400.A30 1604460400 £16.41 £19.69
6 - GROMMET dia6.5-dia6.9x95 MM BSD-2600703012.A495 2600703012 £2.80 £3.36
7 - CABLE CLIP BSD-2601035001.A3082 2601035001 £1.75 £2.10
9 - MANUFACTURER'S NAMEPLATE GOP 55-36 BSD-2601113576.A4 2601113576 £2.61 £3.13
10 - BALL JOINT BSD-2609100929.A20 2609100929 £1.75 £2.10
12 - SPEED GOVERNOR BSD-16072335BM.A0 16072335BM £63.50 £76.20
15 - BRUSH HOLDER BSD-2604337120.A5 2604337120 £3.72 £4.47
15/2 - SPIRAL SPRING BSD-1619P02809.A53 1619P02809 £1.75 £2.10
16 - SWITCH SLIDE BSD-2609100914.A21 2609100914 £1.75 £2.10
17 - SWITCH BUTTON BSD-2609100915.A11 2609100915 £2.80 £3.36
18 - BRUSH-COVER BSD-2605132079.A6 2605132079 £2.16 £2.59
19 - BRUSH-COVER BSD-2605132080.A1 2605132080 £2.16 £2.59
20 - HOUSING COVER BSD-2609100909.A18 2609100909 £12.04 £14.45
24 - AIR-DEFLECTOR RING BSD-2601328101.A0 2601328101 £2.16 £2.59
29 - SEALING CAP BSD-2601020017.A13 2601020017 -
38 - TORX OVAL-HEAD SCREW 3x8 BSD-2603490016.A29 2603490016 £1.75 £2.10
39 - TORX OVAL-HEAD SCREW 4x8 BSD-2603490020.A112 2603490020 £1.75 £2.10
40 - SCREW 4x16 BSD-2603490022.A3096 2603490022 £1.75 £2.10
41 - TORX OVAL-HEAD SCREW BSD-2603415225.A4 2603415225 £3.72 £4.47
55 - LEVER BSD-2601901025.A1 2601901025 £12.04 £14.45
57 - INSULATING FERRULE BSD-2600114083.A11 2600114083 £2.16 £2.59
59 - SAFETY COVER BSD-2601099300.A1 2601099300 £1.75 £2.10
200 - REFERENCE PLATE BSD-2601113577.A1 2601113577 £4.26 £5.11
691 - BOX BSD-16054381CV.A25 16054381CV £18.96 £22.75
801 - HOUSING ASSEMBLY BSD-2605190933.A1 2605190933 £54.42 £65.30
803 - ARMATURE BSD-2604011962.A0 2604011962 £120.11 £144.13
803/58 - GASKET BSD-2600206032.A5 2600206032 £2.61 £3.13
808 - NAMEPLATE BSD-2601113570.A0 2601113570 -
811 - CARBON-BRUSH SET BSD-160701417X.A14 160701417X £7.36 £8.83
845 - GEAR HEAD BSD-2605806851.A0 2605806851 £135.25 £162.30
845/54 - TORSION SPRING BSD-2604690068.A9 2604690068 £1.75 £2.10
845/56 - INSULATING CAP BSD-2600114091.A2 2600114091 £1.75 £2.10
847 - CAP BSD-2605105972.A0 2605105972 £21.52 £25.83
