2 - GEAR HOUSING
BSD-2605806082.A11
2605806082
|
£72.18
|
£86.62
|
|
|
3 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A215
3600905039
|
£12.04
|
£14.45
|
|
|
4 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A939
2910021122
|
£2.16
|
£2.59
|
|
|
6 - GUIDE RAIL
BSD-2601038001.A11
2601038001
|
£3.72
|
£4.47
|
|
|
7 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A358
2916690003
|
£1.75
|
£2.10
|
|
|
9 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-5.8
BSD-2910011128.A203
2910011128
|
£1.75
|
£2.10
|
|
|
10 - SHIM 0.10 MM
BSD-2600100611.A10
2600100611
|
£1.75
|
£2.10
|
|
|
10 - SHIM 0.50 MM
BSD-2600100613.A195
2600100613
|
£1.75
|
£2.10
|
|
|
11 - ECCENTRIC COG WHEEL Z=49
BSD-2606319007.A12
2606319007
|
£59.53
|
£71.44
|
|
|
12 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A45
3600910000
|
£4.26
|
£5.11
|
|
|
13 - SHIM 0.20 MM
BSD-2600100586.A25
2600100586
|
£1.75
|
£2.10
|
|
|
13 - SHIM 0.30 MM
BSD-2600100587.A10
2600100587
|
£1.75
|
£2.10
|
|
|
13 - SHIM 0.5 MM
BSD-2600100588.A89
2600100588
|
£1.75
|
£2.10
|
|
|
14 - ROLLER
BSD-2600300005.A13
2600300005
|
£8.67
|
£10.41
|
|
|
15 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A106
2603201037
|
£2.61
|
£3.13
|
|
|
16 - RETAINING BRACKET
BSD-2601320018.A1
2601320018
|
£2.80
|
£3.36
|
|
|
17 - SLOTTED ROUND NUT
BSD-2603341007.A1
2603341007
|
£1.75
|
£2.10
|
|
|
18 - LIFTING ROD
BSD-2602305016.A16
2602305016
|
£54.42
|
£65.30
|
|
|
19 - LIFTING ROD
BSD-2602305014.A1
2602305014
|
£54.42
|
£65.30
|
|
|
20 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1504
2910021118
|
£1.75
|
£2.10
|
|
|
22 - BEARING BOLT
BSD-2603520010.A14
2603520010
|
£16.41
|
£19.69
|
|
|
23 - PRESSURE PLATE
BSD-2601034010.A4
2601034010
|
£6.52
|
£7.83
|
|
|
24 - ROUND NUT
BSD-3603345016.A14
3603345016
|
£13.12
|
£15.75
|
|
|
25 - SPRING LOCK WASHER DIN128-A5-FST
BSD-2916690002.A12
2916690002
|
£1.75
|
£2.10
|
|
|
26 - SEAL BUSHING
BSD-2600300047.A89
2600300047
|
£2.61
|
£3.13
|
|
|
27 - FELT WASHER
BSD-2600108026.A24
2600108026
|
£1.75
|
£2.10
|
|
|
28 - CUPPED WASHER
BSD-2600500017.A19
2600500017
|
£1.75
|
£2.10
|
|
|
29 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A95
2910011082
|
£1.75
|
£2.10
|
|
|
30 - SUPPORT PLATE
BSD-3602307009.A2
3602307009
|
£81.81
|
£98.17
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x8-5.8
BSD-2910011084.A0
2910011084
|
£1.75
|
£2.10
|
|
|
32 - STUD
BSD-2603502015.A13
2603502015
|
£3.72
|
£4.47
|
|
|
33 - STRAIGHT PIN 4H8x8 DIN 7
BSD-2917500093.A1
2917500093
|
£1.75
|
£2.10
|
|
|
35 - REFERENCE PLATE
BSD-3601110100.A2
3601110100
|
-
|
|
|
|
37 - ROLLER
BSD-2600300011.A1
2600300011
|
£1.75
|
£2.10
|
|
|
38 - NEEDLE ROLLER
BSD-1903201521.A1
1903201521
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A28
2910021132
|
£1.75
|
£2.10
|
|
|
103 - SPIRAL SPRING
BSD-2604652000.A72
2604652000
|
-
|
|
|
|
104 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A657
2916011005
|
£1.75
|
£2.10
|
|
|
105 - CLAMPING SADDLE
BSD-2601321005.A41
2601321005
|
-
|
|
|
|
106 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A101
2914501011
|
£1.75
|
£2.10
|
|
|
107 - FIELD 220-230V
BSD-2604220269.A1
2604220269
|
-
|
|
|
|
108 - HEX NUT DIN 934-M 3-m-8
BSD-2915011003.A56
2915011003
|
£1.75
|
£2.10
|
|
|
109 - SOCKET HEAD CAP SCREW DIN 84-BM3x50-5.8
BSD-2910011074.A7
2910011074
|
£1.75
|
£2.10
|
|
|
110 - SPRING LOCK WASHER A3-FSt
BSD-2916690001.A99
2916690001
|
-
|
|
|
|
111 - BRUSH HOLDER
BSD-2601323016.A20
2601323016
|
£2.80
|
£3.36
|
|
|
112 - PLAIN WASHER dia 2.6 MM-ST
BSD-2916021007.A7
2916021007
|
-
|
|
|
|
113 - HEX NUT DIN 439-BM 3
BSD-2915051103.A46
2915051103
|
£1.75
|
£2.10
|
|
|
114 - SHIM
BSD-2600100699.A53
2600100699
|
£1.75
|
£2.10
|
|
|
115 - SHIM
BSD-2600150002.A51
2600150002
|
-
|
|
|
|
116 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A380
1900905015
|
£30.42
|
£36.51
|
|
|
117 - SHIM 0.3 MM
BSD-2600100612.A2
2600100612
|
£2.61
|
£3.13
|
|
|
118 - SEAL RING
BSD-2600113019.A47
2600113019
|
£2.80
|
£3.36
|
|
|
119 - ARMATURE 220V
BSD-2604010281.A2
2604010281
|
-
|
|
|
|
120 - INSULATING PART
BSD-2601322002.A43
2601322002
|
£1.75
|
£2.10
|
|
|
121 - FAN
BSD-2606610038.A6
2606610038
|
-
|
|
|
|
122 - SWITCH
BSD-2607200045.A95
2607200045
|
-
|
|
|
|
123 - COUNTERSUNK-HEAD SCREW M 3x6 DIN 63-5.8
BSD-2910501048.A45
2910501048
|
-
|
|
|
|
124 - HEX NUT M 2.6 DIN 934-M-6
BSD-2915011002.A64
2915011002
|
-
|
|
|
|
125 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1584
2600703012
|
£2.80
|
£3.36
|
|
|
125 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A34
2600703013
|
£2.61
|
£3.13
|
|
|
126 - CABLE CLIP
BSD-2601035005.A54
2601035005
|
£1.75
|
£2.10
|
|
|
127 - SOCKET HEAD CAP SCREW DIN 84-AM2.6x15-5.8
BSD-2910011033.A54
2910011033
|
-
|
|
|
|
128 - TUBULAR RIVET A2.5x0.3x4DIN7340-MS
BSD-2917170554.A26
2917170554
|
£1.75
|
£2.10
|
|
|
129 - SUPPRESSION FILTER
BSD-2607329048.A39
2607329048
|
-
|
|
|
|
130 - FASTENING CLAMP
BSD-2601301002.A51
2601301002
|
£2.16
|
£2.59
|
|
|
131 - HEX SCREW
BSD-2603527004.A43
2603527004
|
£1.75
|
£2.10
|
|
|
132 - CONNECTING TERMINAL
BSD-2604490005.A9
2604490005
|
£1.75
|
£2.10
|
|
|
133 - SOCKET HEAD CAP SCREW
BSD-2603410009.A36
2603410009
|
£1.32
|
£1.58
|
|
|
135 - HOUSING COVER
BSD-3600508023.A42
3600508023
|
£13.41
|
£16.09
|
|
|
136 - COUNTERSUNK-HEAD SCREW DIN 63-AM3.5x8-5.8
BSD-2910501084.A44
2910501084
|
-
|
|
|
|
138 - STICKER
BSD-3601007011.A1
3601007011
|
-
|
|
|
|
140 - GROOVED NAIL
BSD-3603133000.A209
3603133000
|
£2.61
|
£3.13
|
|
|
142 - CABLE CLIP
BSD-2601099015.A88
2601099015
|
£1.75
|
£2.10
|
|
|
143 - CABLE
BSD-2604411061.A95
2604411061
|
-
|
|
|
|
147 - RETAINING PIN
BSD-2603123013.A25
2603123013
|
-
|
|
|
|
160 - PRESS-IN NUT
BSD-2603349039.A4
2603349039
|
£1.75
|
£2.10
|
|
|
161 - PRESS-IN NUT
BSD-2603349038.A22
2603349038
|
-
|
|
|
|
652 - SCRAPER
BSD-2601030010.A0
2601030010
|
£2.61
|
£3.13
|
|
|
700 - GUIDE 70 MM. T42D
BSD-2608135023.A14
2608135023
|
£62.99
|
£75.59
|
|
|
700 - GUIDE 130 MM. T42A
BSD-2608135020.A3
2608135020
|
£63.87
|
£76.64
|
|
|
700 - GUIDE 220 MM. T42B
BSD-2608135021.A14
2608135021
|
£69.99
|
£83.99
|
|
|
700 - GUIDE 300 MM. T42C
BSD-2608135022.A3
2608135022
|
£76.12
|
£91.34
|
|
|
701 - SAW BLADE SET 70 MM. T 43D
BSD-2607018013.A0
2607018013
|
£20.99
|
£25.19
|
|
|
701 - SAW BLADE SET 130 MM. T43A
BSD-2607018010.A17
2607018010
|
£27.12
|
£32.54
|
|
|
701 - SAW BLADE SET 220 MM. T43B
BSD-2607018011.A0
2607018011
|
£27.12
|
£32.54
|
|
|
701 - SAW BLADE SET 300 MM. T43C
BSD-2607018012.A17
2607018012
|
£29.74
|
£35.69
|
|
|
710 - SHARPENING SET
BSD-2608133000.A0
2608133000
|
-
|
|
|
|
710/10 - WHETSTONE
BSD-3607950012.A6
3607950012
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-2605108032.A4
2605108032
|
-
|
|
|
|
801 - GEAR COVER
BSD-2605500905.A17
2605500905
|
£120.11
|
£144.13
|
|
|
802 - BASE PLATE
BSD-2608000908.A3
2608000908
|
£72.38
|
£86.86
|
|
|
805 - CARBON-BRUSH SET
BSD-2604320905.A8
2604320905
|
-
|
|
|
|
841 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A262
1607000227
|
£23.86
|
£28.63
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1701
160111A3H3
|
£2.61
|
£3.13
|
|
