1 - MOTOR HOUSING
BSD-2605104116.A51
2605104116
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-2604220445.A50
2604220445
|
£27.23
|
£32.68
|
|
|
3 - ARMATURE 220-230V
BSD-2604010612.A0
2604010612
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200137.A93
2607200137
|
-
|
|
|
|
5 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A23
2604460053
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1326
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A313
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-3601110001.A2
3601110001
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329110.A2
2607329110
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A825
1900905018
|
£18.96
|
£22.75
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A458
2600905021
|
£8.67
|
£10.41
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A312
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A203
2603410001
|
£1.75
|
£2.10
|
|
|
19 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1651
2910211019
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601110093.A111
2601110093
|
-
|
|
|
|
25 - DRILLING SPINDLE
BSD-3606135000.A1
3606135000
|
-
|
|
|
|
26 - O-RING 12x2 MM
BSD-1900210009.A9
1900210009
|
-
|
|
|
|
28 - GEAR HOUSING
BSD-3605190091.A3
3605190091
|
-
|
|
|
|
29 - RETAINING RING
BSD-1600224025.A66
1600224025
|
£2.61
|
£3.13
|
|
|
30 - PLAIN WASHER
BSD-2600101513.A55
2600101513
|
£1.75
|
£2.10
|
|
|
31 - COMPRESSION SPRING
BSD-3604616007.A7
3604616007
|
-
|
|
|
|
32 - SHIM
BSD-2600101601.A37
2600101601
|
£1.75
|
£2.10
|
|
|
33 - CYLINDRICAL GEAR Z=42
BSD-3606316019.A3
3606316019
|
-
|
|
|
|
34 - BALL DIN 5401-6 G28
BSD-1903230011.A222
1903230011
|
£2.61
|
£3.13
|
|
|
35 - COMPRESSION SPRING
BSD-3604610018.A1
3604610018
|
£1.95
|
£2.34
|
|
|
36 - CYLINDRICAL GEAR Z=42
BSD-3606316020.A1
3606316020
|
£81.81
|
£98.17
|
|
|
39 - SHIM 0.5 MM
BSD-2600100505.A53
2600100505
|
£1.32
|
£1.58
|
|
|
41 - COVER DISC
BSD-2601328033.A50
2601328033
|
-
|
|
|
|
42 - SUPPRESSION FILTER
BSD-2604465068.A19
2604465068
|
-
|
|
|
|
43 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1209
2603490017
|
£2.16
|
£2.59
|
|
|
44 - SHIM
BSD-2600150004.A91
2600150004
|
£2.16
|
£2.59
|
|
|
45 - SHIM 0.3 MM
BSD-2600101023.A116
2600101023
|
£1.75
|
£2.10
|
|
|
45 - SHIM 0.2 MM
BSD-2600101022.A534
2600101022
|
£1.75
|
£2.10
|
|
|
45 - SHIM 0.5 MM
BSD-2600101020.A116
2600101020
|
£1.75
|
£2.10
|
|
|
46 - CABLE L=130 MM
BSD-2604448005.A362
2604448005
|
£1.75
|
£2.10
|
|
|
47 - HOUSING COVER
BSD-2605132040.A105
2605132040
|
-
|
|
|
|
48 - CABLE
BSD-2604448003.A214
2604448003
|
-
|
|
|
|
50 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A669
2910211021
|
£1.75
|
£2.10
|
|
|
51 - STICKER
BSD-2601110230.A115
2601110230
|
-
|
|
|
|
52 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A9
2603435015
|
£2.16
|
£2.59
|
|
|
53 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A544
2916660008
|
£2.16
|
£2.59
|
|
|
54 - CUPPED WASHER
BSD-2600500002.A298
2600500002
|
£1.75
|
£2.10
|
|
|
55 - FELT WASHER
BSD-2600108077.A214
2600108077
|
£1.75
|
£2.10
|
|
|
56 - RECEPTACLE
BSD-2600400008.A58
2600400008
|
£1.75
|
£2.10
|
|
|
57 - CYLINDRICAL GEAR Z=33/56
BSD-3606328000.A5
3606328000
|
£102.57
|
£123.08
|
|
|
58 - CONNECTING CABLE L=98 MM
BSD-2604448074.A56
2604448074
|
£2.16
|
£2.59
|
|
|
59 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A102
2604465086
|
£5.58
|
£6.70
|
|
|
60 - TAPPING SCREW BZ 4.8x78 MM
BSD-1603435019.A1
1603435019
|
-
|
|
|
|
61 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A249
2916650003
|
£1.75
|
£2.10
|
|
|
62 - AXLE
BSD-3603124000.A10
3603124000
|
£48.38
|
£58.06
|
|
|
63 - GRIPPING WEDGE dia 5x18 MM/3.6 MM
BSD-1603110000.A26
1603110000
|
-
|
|
|
|
63 - GRIPPING WEDGE dia 5x18 MM/3.0 MM
BSD-1603110003.A6
1603110003
|
-
|
|
|
|
63 - GRIPPING WEDGE dia 5x18 MM/3.3 MM
BSD-1603110004.A10
1603110004
|
-
|
|
|
|
64 - TWO-JAW DRILL JUCK M4-M12
BSD-2608573000.A3
2608573000
|
£134.16
|
£160.99
|
|
|
64/10 - CARRIER
BSD-1600328021.A13
1600328021
|
£68.42
|
£82.10
|
|
|
64/20 - COMPRESSION SPRING
BSD-1604617002.A16
1604617002
|
£2.80
|
£3.36
|
|
|
64/30 - SPRING RETAINER
BSD-1600506000.A12
1600506000
|
£8.49
|
£10.19
|
|
|
64/40 - CARRIER
BSD-1603219006.A15
1603219006
|
£116.15
|
£139.38
|
|
|
64/50 - STRAIGHT PIN
BSD-1613100012.A264
1613100012
|
£2.61
|
£3.13
|
|
|
64/60 - STUD BOLT
BSD-1603502000.A5
1603502000
|
£21.52
|
£25.83
|
|
|
64/70 - CLAMPING JAWS M 12x1.5
BSD-1600390002.A13
1600390002
|
-
|
|
|
|
64/71 - CLAMPING JAWS M 12x1.5
BSD-1600390003.A20
1600390003
|
-
|
|
|
|
64/650 - CHUCK WRENCH
BSD-2607950012.A5
2607950012
|
£16.41
|
£19.69
|
|
|
64/700 - CLAMPING JAWS M 12x1.5
BSD-1600390004.A1
1600390004
|
-
|
|
|
|
64/701 - CLAMPING JAWS M 12x1.5
BSD-1600390005.A20
1600390005
|
-
|
|
|
|
65 - CYLINDRICAL GEAR Z=28
BSD-3606316021.A10
3606316021
|
£48.38
|
£58.06
|
|
|
66 - SPINDLE WITH GEAR Z=11
BSD-3606337062.A5
3606337062
|
£48.38
|
£58.06
|
|
|
67 - TAPPING SCREW 79 MM
BSD-2603435012.A134
2603435012
|
-
|
|
|
|
68 - SHIM 0.50 MM
BSD-2600100613.A166
2600100613
|
£1.75
|
£2.10
|
|
|
69 - NEEDLE BEARING
BSD-9001140359.A59
9001140359
|
£6.52
|
£7.83
|
|
|
90 - TAPPING SCREW DIN 7971-BZ3.9x25
BSD-2910211022.A34
2910211022
|
£1.75
|
£2.10
|
|
|
180 - NAMEPLATE
BSD-1601110449.A6
1601110449
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-2604321905.A544
2604321905
|
£11.30
|
£13.56
|
|
|
840 - INTERMEDIATE FLANGE
BSD-3605700054.A5
3605700054
|
£134.16
|
£160.99
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1101
160111A3H3
|
£2.61
|
£3.13
|
|
