1 - MOTOR HOUSING
BSD-1605108170.A5
1605108170
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-1604220321.A0
1604220321
|
-
|
|
|
|
3/50 - FAN
BSD-3606610002.A69
3606610002
|
£2.33
|
£2.80
|
|
|
4 - ON-OFF SWITCH
BSD-1607200144.A0
1607200144
|
-
|
|
|
|
5 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H05VV-F
BSD-2604460102.A29
2604460102
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A699
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A528
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2405
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118308.A9
1601118308
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-1607328046.A2
1607328046
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A295
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A53
3600905131
|
£11.30
|
£13.56
|
|
|
16 - BRUSH HOLDER
BSD-1604336038.A5
1604336038
|
-
|
|
|
|
24 - INTERMEDIATE RING
BSD-1600221003.A145
1600221003
|
£2.61
|
£3.13
|
|
|
25 - SEALING CAP
BSD-1605500186.A5
1605500186
|
-
|
|
|
|
26 - SPEED GOVERNOR 230-240V
BSD-1607233106.A3
1607233106
|
-
|
|
|
|
27 - HANDLE
BSD-1605133044.A3
1605133044
|
-
|
|
|
|
28 - AIR-DEFLECTOR RING
BSD-1600591017.A3
1600591017
|
-
|
|
|
|
31 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A50
1600910018
|
£5.30
|
£6.36
|
|
|
34 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A787
2603490024
|
£1.75
|
£2.10
|
|
|
42 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2415
2603410001
|
£1.75
|
£2.10
|
|
|
43 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A193
2912401019
|
£1.75
|
£2.10
|
|
|
48 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A486
1600290016
|
£2.61
|
£3.13
|
|
|
49 - LOCKING RING
BSD-1600390017.A3
1600390017
|
-
|
|
|
|
53 - THREAD-FORMING TAP. SCREW B5 x 75 MM
BSD-1603435049.A6
1603435049
|
-
|
|
|
|
57 - INTERMEDIATE RING
BSD-1600502023.A33
1600502023
|
£2.16
|
£2.59
|
|
|
63 - CONNECTING CABLE L=52 MM
BSD-1604448011.A4
1604448011
|
-
|
|
|
|
68 - LOCKING ELEMENT
BSD-1603231014.A3
1603231014
|
£2.16
|
£2.59
|
|
|
74 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A37
2603435042
|
£1.75
|
£2.10
|
|
|
80 - STOP SPRING
BSD-1601329025.A0
1601329025
|
-
|
|
|
|
81 - LOCKING BOLT
BSD-1603231015.A2
1603231015
|
-
|
|
|
|
82 - PLUG
BSD-1605500205.A2
1605500205
|
-
|
|
|
|
83 - REFERENCE PLATE
BSD-1601110470.A163
1601110470
|
£1.75
|
£2.10
|
|
|
85 - O-RING 38.0x1.5 MM
BSD-1600210038.A10
1600210038
|
£2.61
|
£3.13
|
|
|
160 - PROTECTIVE COVER
BSD-1609203316.A0
1609203316
|
-
|
|
|
|
161 - GROOVED NAIL
BSD-1609203716.A0
1609203716
|
-
|
|
|
|
169 - CHASSIS
BSD-1609203317.A5
1609203317
|
-
|
|
|
|
175 - SEALING CAP
BSD-1609203495.A5
1609203495
|
-
|
|
|
|
176 - ROLLER
BSD-1609203321.A5
1609203321
|
-
|
|
|
|
177 - SPACER TUBE
BSD-1609203496.A0
1609203496
|
-
|
|
|
|
178 - SPACER TUBE
BSD-1609203497.A5
1609203497
|
-
|
|
|
|
179 - AXLE
BSD-1609203498.A0
1609203498
|
-
|
|
|
|
180 - AXLE
BSD-1609203323.A0
1609203323
|
-
|
|
|
|
181 - SHIM WASHER dia 10.5 MM
BSD-1609203500.A5
1609203500
|
-
|
|
|
|
182/84 - STRAP-SHAPED HANDLE
BSD-1615132044.A22
1615132044
|
£14.91
|
£17.89
|
|
|
182/86 - HEX SCREW DIN 931-M8x130-8.8
BSD-2911011270.A22
2911011270
|
£4.26
|
£5.11
|
|
|
182/88 - STAR KNOB M8
BSD-1619P16922.A45
1619P16922
|
£6.45
|
£7.74
|
|
|
183 - SUCTION SOCKET
BSD-1609203318.A0
1609203318
|
-
|
|
|
|
184 - THREAD-FORMING TAP. SCREW B5 x 75 MM
BSD-1603435049.A7
1603435049
|
-
|
|
|
|
187 - COILED SPRING
BSD-1609203501.A0
1609203501
|
-
|
|
|
|
189 - PLAIN WASHER dia 42X22.2X4 MM
BSD-3609202041.A4
3609202041
|
£5.58
|
£6.70
|
|
|
190 - PLAIN WASHER dia 42X22.2X6 MM
BSD-3609202042.A9
3609202042
|
£3.80
|
£4.56
|
|
|
192 - O-RING 6x3 MM
BSD-1609203504.A5
1609203504
|
-
|
|
|
|
193 - CONICAL SPRING WASHER dia42xdia22.3 MM
BSD-1609203505.A0
1609203505
|
-
|
|
|
|
194 - HEX SOCKET HEAD CAP SCREW M 8x25 MM
BSD-1609203506.A5
1609203506
|
-
|
|
|
|
195 - MANUFACTURER'S NAMEPLATE
BSD-1609203507.A0
1609203507
|
-
|
|
|
|
651 - SPLITTING TOOL
BSD-3607959005.A23
3607959005
|
£21.68
|
£26.01
|
|
|
654 - HEXAGON-SOCKET KEY SW6
BSD-1609203508.A5
1609203508
|
-
|
|
|
|
753 - CARRYING CASE
BSD-2605438362.A0
2605438362
|
-
|
|
|
|
783 - AIR HOSE dia 35 MM. L=5 M
BSD-1609202230.A152
1609202230
|
£85.74
|
£102.89
|
|
|
784 - AUXILIARY HANDLE dia 43 MM
BSD-2602025063.A26
2602025063
|
£35.92
|
£43.10
|
|
|
803 - ARMATURE WITH FAN 230-240V
BSD-1604010657.A0
1604010657
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3675
160111A3H3
|
£2.61
|
£3.13
|
|
|
816/02 - SPIRAL SPRING
BSD-2604652008.A157
2604652008
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-1607014149.A0
1607014149
|
-
|
|
|
|
817 - GEAR HOUSING
BSD-1609203513.A0
1609203513
|
-
|
|
|
|
817/01 - DRIVE SHAFT M8
BSD-1609203514.A5
1609203514
|
-
|
|
|
|
867 - DEPTH-GAUGE
BSD-1609203510.A0
1609203510
|
-
|
|
|
|
872 - DETENT PIN
BSD-1609203511.A5
1609203511
|
-
|
|
|
|
887 - CLAMPING BAND dia 43 MM
BSD-1617000171.A42
1617000171
|
-
|
|
|
