1 - SCREW
BDE-SC18.A6
SC18
|
£1.50
|
£1.80
|
|
2 - LOCK NUT
BDE-SC15.A0
SC15
|
£1.42
|
£1.70
|
|
3 - WASHER
BDE-SC28.A14
SC28
|
£1.42
|
£1.70
|
|
4 - DEFLECTOR
BDE-B01426.A7
B01426
|
£3.80
|
£4.56
|
|
5 - VALVE SEAT
BDE-B03043.A7
B03043
|
£17.48
|
£20.97
|
|
6 - O RING
BDE-SC09.A19
SC09
|
£7.18
|
£8.62
|
|
7 - SPRING
BDE-B04587.A5
B04587
|
£10.85
|
£13.02
|
|
8 - LOCATOR
BDE-B01420.A2
B01420
|
£9.17
|
£11.00
|
|
9 - SCREW
BDE-SC21.A22
SC21
|
£7.18
|
£8.62
|
|
10 - WASHER
BDE-B01455.A20
B01455
|
£1.50
|
£1.80
|
|
11 - SUPPORT
BDE-B01421.A21
B01421
|
£1.50
|
£1.80
|
|
12 - O RING
BDE-SC08.A7
SC08
|
£1.50
|
£1.80
|
|
13 - SUPPORT
BDE-B01422.A6
B01422
|
£2.71
|
£3.25
|
|
14 - SPACER
BDE-B03044.A17
B03044
|
£9.41
|
£11.29
|
|
15 - BUSHING
BDE-B01417.A18
B01417
|
£9.41
|
£11.29
|
|
16 - STUD
BDE-B01510.A5
B01510
|
£10.57
|
£12.68
|
|
17 - HOUSING SA
BDE-AD02260F2
AD02260F2
|
-
|
|
|
18 - LINER
BDE-C02249
C02249
|
£804.38
|
£965.26
|
|
19 - GRUB SCREW
BDE-SC24.A1
SC24
|
£1.50
|
£1.80
|
|
21 - O RING
BDE-A02398
A02398
|
£1.50
|
£1.80
|
|
22 - O RING
BDE-A02359
A02359
|
-
|
|
|
23 - NUT
BDE-A02356.A1
A02356
|
£2.78
|
£3.34
|
|
24 - PISTON
BDE-C02250
C02250
|
£45.14
|
£54.17
|
|
25 - GASKET
BDE-B02267
B02267
|
-
|
|
|
27 - BUSH
BDE-B02269
B02269
|
£43.02
|
£51.63
|
|
28 - PLATE LH
BDE-C02933F
C02933F
|
£87.82
|
£105.39
|
|
29 - WASHER
BDE-A02361
A02361
|
£1.50
|
£1.80
|
|
30 - SCREW
BDE-A02344
A02344
|
£1.50
|
£1.80
|
|
31 - JAW
BDE-C02256F
C02256F
|
£238.94
|
£286.73
|
|
32 - BUSHING
BDE-B02932.A0
B02932
|
£17.48
|
£20.97
|
|
33 - SPACER
BDE-A02338
A02338
|
£1.50
|
£1.80
|
|
36 - CIRCLIP
BDE-A02345.A0
A02345
|
£1.50
|
£1.80
|
|
37 - SPRING
BDE-B02264F.A0
B02264F
|
£17.48
|
£20.97
|
|
38 - LATCH
BDE-C02259F.A0
C02259F
|
£69.63
|
£83.56
|
|
39 - ROLLER
BDE-B02257
B02257
|
£14.57
|
£17.48
|
|
40 - BLADE
BDE-B02964
B02964
|
£34.00
|
£40.80
|
|
41 - JAW
BDE-C02255F
C02255F
|
£238.94
|
£286.73
|
|
42 - ROLLPIN
BDE-A02346
A02346
|
£1.42
|
£1.70
|
|
43 - PISTON
BDE-B02254
B02254
|
-
|
|
|
44 - TRIGGER
BDE-A02073F.A24
A02073F
|
£7.18
|
£8.62
|
|
45 - ROLL PIN
BDE-A02347
A02347
|
£1.50
|
£1.80
|
|
46 - PIN
BDE-B01439
B01439
|
-
|
|
|
47 - PIN
BDE-B01425F.A26
B01425F
|
£2.26
|
£2.71
|
|
48 - VALVE SEAT
BDE-B03042.A22
B03042
|
£14.57
|
£17.48
|
|
49 - GUARD
BDE-B01435F.A24
B01435F
|
£7.18
|
£8.62
|
|
50 - WASHER LOCK
BDE-SC32.A10
SC32
|
£1.42
|
£1.70
|
|
51 - SCREW
BDE-SC18.A17
SC18
|
£1.50
|
£1.80
|
|
52 - INLET
BDE-AB01473F.A0
AB01473F
|
£18.42
|
£22.10
|
|
55 - PUSHER
BDE-B02286F.A0
B02286F
|
£115.77
|
£138.92
|
|
57 - BOLT
BDE-A02904.A1
A02904
|
£18.91
|
£22.69
|
|
59 - NUT
BDE-TL727200.A15
TL727200
|
£2.71
|
£3.25
|
|
60 - SHIM
BDE-A02265.A1
A02265
|
£9.41
|
£11.29
|
|
61 - BOLT
BDE-A02289.A0
A02289
|
£25.70
|
£30.84
|
|
63 - SPRING
BDE-B02297.A1
B02297
|
£19.90
|
£23.88
|
|
64 - SCREW
BDE-A02368-S.A1
A02368-S
|
£3.30
|
£3.96
|
|
65 - ARM
BDE-C02263F
C02263F
|
£45.14
|
£54.17
|
|
66 - WASHER
BDE-SC29.A0
SC29
|
£1.50
|
£1.80
|
|
67 - SCREW
BDE-A02348
A02348
|
£1.50
|
£1.80
|
|
68 - SUPPORT PLATE
BDE-A02295.A1
A02295
|
£51.90
|
£62.28
|
|
69 - SCREW
BDE-A02362-S.A0
A02362-S
|
£1.42
|
£1.70
|
|
70 - SHOE
BDE-C02261F.A1
C02261F
|
£23.75
|
£28.50
|
|
71 - SPRING
BDE-A02350.A0
A02350
|
£3.30
|
£3.96
|
|
72 - LOCK NUT
BDE-SC13.A17
SC13
|
£1.42
|
£1.70
|
|
73 - PIN
BDE-A02360
A02360
|
£1.50
|
£1.80
|
|
74 - HANDLE
BDE-C02248F
C02248F
|
£226.53
|
£271.84
|
|
76 - BRACKET
BDE-B02900.A1
B02900
|
£44.14
|
£52.97
|
|
128 - PLATE RH
BDE-C02934F
C02934F
|
£87.82
|
£105.39
|
|
861 - TOOLBOX
BDE-SC50TOOLBOX
SC50TOOLBOX
|
£245.11
|
£294.13
|
|
990 - REPAIR KIT
BDE-AB02900
AB02900
|
£258.10
|
£309.72
|
|
991 - REPAIR KIT
BDE-AC02251F
AC02251F
|
£170.23
|
£204.28
|
|
992 - REPAIR KIT
BDE-AC02284F
AC02284F
|
£615.67
|
£738.80
|
|
