1 - NO LONGER AVAILABLE GB
BDE-000000-00.A29372
000000-00
|
-
|
|
|
|
1 - ARMATURE 115V LX
BDE-477225-01.A0
477225-01
|
-
|
|
|
|
2 - FIELD 230V GB
BDE-576690-05.A1
576690-05
|
£30.08
|
£36.10
|
|
|
2 - FIELD 115V LX
BDE-576690-06.A21
576690-06
|
£30.08
|
£36.10
|
|
|
3 - SWITCH 115V LX
BDE-588724-01.A1
588724-01
|
£38.80
|
£46.56
|
|
|
3 - SWITCH 240V GB
BDE-588724-00.A1
588724-00
|
£38.80
|
£46.56
|
|
|
4 - BRUSH HOLDER 115V LX
BDE-577805-04.A0
577805-04
|
£19.90
|
£23.88
|
|
|
4 - BRUSH HOLDER 230V GB
BDE-577805-03.A15
577805-03
|
-
|
|
|
|
5 - BRUSH KIT LX
BDE-584429-01.A1
584429-01
|
£19.90
|
£23.88
|
|
|
5 - BRUSH KIT GB
BDE-584429-00.A14
584429-00
|
£19.90
|
£23.88
|
|
|
6 - CAPACITOR
BDE-320842-19.A14
320842-19
|
£1.50
|
£1.80
|
|
|
7 - CORD PROTECTOR
BDE-584090-00.A11
584090-00
|
£1.50
|
£1.80
|
|
|
8 - CORDSET (M/PLUG) LX
BDE-582319-19.A1
582319-19
|
£38.80
|
£46.56
|
|
|
8 - CORDSET (M/PLUG) GB GB
BDE-582319-18.A1
582319-18
|
£30.08
|
£36.10
|
|
|
12 - LEAD BLUE
BDE-584304-10.A2
584304-10
|
£1.50
|
£1.80
|
|
|
16 - LEAD BLUE
BDE-582064-16.A5
582064-16
|
£1.50
|
£1.80
|
|
|
17 - LEADWIRE
BDE-589456-04.A1
589456-04
|
£1.42
|
£1.70
|
|
|
18 - BUMPER
BDE-930026-01.A22
930026-01
|
£1.50
|
£1.80
|
|
|
19 - SLIDER
BDE-588902-00.A2
588902-00
|
£2.78
|
£3.34
|
|
|
20 - LEVER
BDE-578220-00.A20
578220-00
|
£1.50
|
£1.80
|
|
|
21 - SLEEVE
BDE-870052.A239
870052
|
£1.50
|
£1.80
|
|
|
22 - BUSH
BDE-579720-00.A0
579720-00
|
£1.50
|
£1.80
|
|
|
23 - SCREW
BDE-326519-03.A20
326519-03
|
£1.50
|
£1.80
|
|
|
24 - BEARING
BDE-330003-19.A252
330003-19
|
£2.78
|
£3.34
|
|
|
25 - BEARING
BDE-330003-64.A26
330003-64
|
£4.69
|
£5.63
|
|
|
28 - INSERT
BDE-582877-00.A13
582877-00
|
£1.50
|
£1.80
|
|
|
30 - HOUSING
BDE-577986-20.A0
577986-20
|
£12.17
|
£14.60
|
|
|
31 - BAFFLE FAN
BDE-581808-00.A0
581808-00
|
£1.50
|
£1.80
|
|
|
32 - FIELD CASE
BDE-577993-00.A1
577993-00
|
£10.85
|
£13.02
|
|
|
33 - END CAP SA
BDE-584041-00.A2
584041-00
|
£9.17
|
£11.00
|
|
|
34 - HANDLE COVER
BDE-588675-00.A0
588675-00
|
£12.17
|
£14.60
|
|
|
35 - SCREW
BDE-330065-08.A53
330065-08
|
£1.50
|
£1.80
|
|
|
36 - CORD CLAMP
BDE-821070.A512
821070
|
£1.50
|
£1.80
|
|
|
37 - SCREW
BDE-330065-09.A99
330065-09
|
£1.50
|
£1.80
|
|
|
39 - SCREW
BDE-330065-26.A11
330065-26
|
£1.50
|
£1.80
|
|
|
40 - SCREW
BDE-330065-25.A109
330065-25
|
£1.50
|
£1.80
|
|
|
50 - INTERSHAFT
BDE-1006350-00.A0
1006350-00
|
-
|
|
|
|
51 - O RING
BDE-580908-00.A5
580908-00
|
£1.50
|
£1.80
|
|
|
60 - FILTER
BDE-582865-00.A72
582865-00
|
£1.50
|
£1.80
|
|
|
62 - SCREW
BDE-583981-00.A15
583981-00
|
£1.50
|
£1.80
|
|
|
70 - HOUSING BEARING
BDE-477212-00.A1
477212-00
|
£34.00
|
£40.80
|
|
|
71 - BEARING
BDE-330003-81.A12
330003-81
|
£4.69
|
£5.63
|
|
|
72 - SEAL
BDE-578229-00.A50
578229-00
|
£1.50
|
£1.80
|
|
|
73 - BEARING BLOCK
BDE-577801-00.A75
577801-00
|
£5.88
|
£7.06
|
|
|
74 - WASHER SHIM
BDE-577802-00.A5
577802-00
|
£2.21
|
£2.65
|
|
|
75 - PISTON
BDE-496246-00.A22
496246-00
|
£18.91
|
£22.69
|
|
|
76 - O RING
BDE-579699-00.A78
579699-00
|
£1.50
|
£1.80
|
|
|
77 - RAM
BDE-496245-00.A16
496245-00
|
£17.48
|
£20.97
|
|
|
78 - BEARING BUSH
BDE-N042808.A38
N042808
|
£5.88
|
£7.06
|
|
|
79 - SCREW
BDE-324006-15.A74
324006-15
|
£1.50
|
£1.80
|
|
|
90 - CLIP
BDE-577793-00.A3
577793-00
|
£1.50
|
£1.80
|
|
|
92 - O RING
BDE-580990-00.A80
580990-00
|
£1.50
|
£1.80
|
|
|
93 - O RING
BDE-577135-00.A58
577135-00
|
£3.30
|
£3.96
|
|
|
94 - BUSH
BDE-477215-00.A1
477215-00
|
£16.03
|
£19.24
|
|
|
95 - BEAT PIECE
BDE-584424-01.A2
584424-01
|
£10.85
|
£13.02
|
|
|
96 - BEARING & SEAL
BDE-477216-00.A1
477216-00
|
£24.39
|
£29.27
|
|
|
97 - SEAL
BDE-577139-00.A28
577139-00
|
£1.50
|
£1.80
|
|
|
110 - WASHER
BDE-577797-00.A0
577797-00
|
£1.50
|
£1.80
|
|
|
114 - SPINDLE SA
BDE-477217-00.A1
477217-00
|
£125.16
|
£150.19
|
|
|
115 - WASHER
BDE-577814-00.A20
577814-00
|
£2.26
|
£2.71
|
|
|
117 - O RING
BDE-589186-00.A1
589186-00
|
£5.88
|
£7.06
|
|
|
118 - GEARCASE SA
BDE-477218-00.A1
477218-00
|
£24.39
|
£29.27
|
|
|
121 - SCREW
BDE-330065-28.A16
330065-28
|
£1.50
|
£1.80
|
|
|
132 - SPRING
BDE-871690.A86
871690
|
£1.66
|
£1.99
|
|
|
133 - WASHER
BDE-578387-00.A84
578387-00
|
£1.66
|
£1.99
|
|
|
134 - BALL 7MM
BDE-583890-00.A158
583890-00
|
£1.66
|
£1.99
|
|
|
135 - TUBE
BDE-N774198.A27
N774198
|
£12.17
|
£14.60
|
|
|
136 - CAP
BDE-323489-00.A74
323489-00
|
£1.66
|
£1.99
|
|
|
137 - RING
BDE-579212-00.A46
579212-00
|
£1.66
|
£1.99
|
|
|
140 - SLEEVE
BDE-586892-00.A1
586892-00
|
£17.48
|
£20.97
|
|
|
145 - SPRING
BDE-586893-00.A1
586893-00
|
£3.30
|
£3.96
|
|
|
147 - LOCKING RING
BDE-586894-00.A1
586894-00
|
£3.80
|
£4.56
|
|
|
150 - SLEEVE
BDE-586891-00.A1
586891-00
|
£7.18
|
£8.62
|
|
|
160 - HANDLE SIDE SA
BDE-494661-00.A2
494661-00
|
£18.91
|
£22.69
|
|
|
800 - GREASE 90 GMS
BDE-870889-02.A462
870889-02
|
£7.85
|
£9.42
|
|
|
801 - GREASE 10 GMS
BDE-487130-04.A70
487130-04
|
£3.80
|
£4.56
|
|
|
821 - RATING PLATE GB
BDE-N043142
N043142
|
-
|
|
|
|
821 - RATING PLATE LX
BDE-495161-17
495161-17
|
£1.42
|
£1.70
|
|
|
846 - SERVICE KIT 230V GB
BDE-477245-00.A1
477245-00
|
£58.69
|
£70.43
|
|
|
846 - SERVICE KIT 115V LX
BDE-477246-00.A1
477246-00
|
£40.21
|
£48.25
|
|
|
861 - KITBOX `
BDE-578005-00.A8
578005-00
|
£34.00
|
£40.80
|
|
