Dewalt DW130 Type 2 Mixer Spare Parts

Dewalt DW130 Type 2 Mixer Spare Parts
Home Details Reviews Delivery
An exploded drawing and spare parts listing for the Dewalt DW130 Type 2 Mixer
Ex VAT Inc VAT
1 - NO LONGER AVAILABLE LX BDE-000000-00.A13852 000000-00 -
1 - NO LONGER AVAILABLE XW BDE-000000-00.A13853 000000-00 -
1 - ARMATURE & FAN GB BDE-450130-05SV.A0 450130-05SV -
2 - FIELD GB BDE-450379-00.A0 450379-00 -
2 - NO LONGER AVAILABLE LX BDE-000000-00.A13854 000000-00 -
2 - NO LONGER AVAILABLE XW BDE-000000-00.A13855 000000-00 -
3 - BRUSH & SPRING GB BDE-450374-12.A17 450374-12 £9.41 £11.29
3 - BRUSH & SPRING LX BDE-450374-12.A18 450374-12 £9.41 £11.29
3 - BRUSH & SPRING XW BDE-450374-12.A19 450374-12 £9.41 £11.29
5 - BRUSHBOX SA BDE-448083-01.A22 448083-01 £5.88 £7.06
6 - BRUSH CAP BDE-448084-01.A52 448084-01 -
7 - SWITCH BDE-88324-05.A1 88324-05 -
8 - CORDSET LX BDE-330061-20.A42 330061-20 £50.60 £60.72
8 - CORDSET XW BDE-330061-20.A43 330061-20 £50.60 £60.72
8 - CORDSET (M/PLUG) GB BDE-330060-44.A57 330060-44 £14.57 £17.48
9 - BEARING BDE-605040-06.A345 605040-06 £3.80 £4.56
10 - BEARING BDE-605040-20.A136 605040-20 £4.69 £5.63
11 - NO LONGER AVAILABLE BDE-000000-00.A13856 000000-00 -
13 - CHUCK & KEY BDE-5140204-44.A1 5140204-44 £19.90 £23.88
15 - SCREW BDE-330019-30.A50 330019-30 £1.50 £1.80
16 - GEARCASE SA BDE-N209034.A4 N209034 £24.39 £29.27
17 - BEARING BDE-700964-00.A0 700964-00 -
18 - SCREW BDE-52819-00.A13 52819-00 £1.50 £1.80
19 - BEARING NEEDLE BDE-330004-02.A55 330004-02 £1.50 £1.80
20 - SPINDLE BDE-147195-00.A3 147195-00 £34.00 £40.80
21 - PINION & GEAR SA BDE-449489-00.A0 449489-00 £30.08 £36.10
22 - PINION & GEAR SA BDE-449486-00.A0 449486-00 £47.08 £56.49
23 - BEARING BDE-135937-00.A8 135937-00 £3.30 £3.96
25 - BEARING BDE-449493-00.A0 449493-00 £1.82 £2.19
26 - GASKET BDE-450485-00.A5 450485-00 £2.26 £2.71
28 - NO LONGER AVAILABLE BDE-000000-00.A13857 000000-00 -
29 - NO LONGER AVAILABLE BDE-000000-00.A13858 000000-00 -
30 - SCREW BDE-330019-50.A85 330019-50 £1.50 £1.80
31 - SLEEVE BDE-445217-02.A28 445217-02 £1.50 £1.80
32 - NO LONGER AVAILABLE LX BDE-000000-00.A13859 000000-00 -
32 - NO LONGER AVAILABLE GB BDE-000000-00.A13860 000000-00 -
32 - NO LONGER AVAILABLE XW BDE-000000-00.A13861 000000-00 -
33 - NO LONGER AVAILABLE LX BDE-000000-00.A13862 000000-00 -
33 - NO LONGER AVAILABLE XW BDE-000000-00.A13863 000000-00 -
33 - NO LONGER AVAILABLE GB BDE-000000-00.A13864 000000-00 -
34 - SCREW BDE-330019-13.A40 330019-13 £1.50 £1.80
36 - NO LONGER AVAILABLE GB BDE-000000-00.A13865 000000-00 -
36 - NO LONGER AVAILABLE LX BDE-000000-00.A13866 000000-00 -
36 - NO LONGER AVAILABLE XW BDE-000000-00.A13867 000000-00 -
37 - CORD CLAMP BDE-380414-00.A24 380414-00 -
38 - SCREW BDE-330019-03.A44 330019-03 £1.50 £1.80
40 - NO LONGER AVAILABLE BDE-000000-00.A13868 000000-00 -
41 - NUT BDE-99371-06.A3 99371-06 £1.50 £1.80
42 - NO LONGER AVAILABLE BDE-000000-00.A13869 000000-00 -
44 - HANDLE BDE-628037-00.A2 628037-00 £14.57 £17.48
45 - KNOB BDE-382531-00.A2 382531-00 £16.03 £19.24
46 - HANDLE LX BDE-130814-06.A0 130814-06 -
46 - HANDLE GB BDE-130814-06.A1 130814-06 -
46 - HANDLE XW BDE-130814-06.A2 130814-06 -
47 - CORD PROTECTOR XW BDE-401751-00.A21 401751-00 £1.50 £1.80
47 - CORD PROTECTOR GB BDE-401751-00.A22 401751-00 £1.50 £1.80
47 - CORD PROTECTOR LX BDE-401751-00.A23 401751-00 £1.50 £1.80
50 - NO LONGER AVAILABLE BDE-000000-00.A13870 000000-00 -
51 - NO LONGER AVAILABLE BDE-000000-00.A13871 000000-00 -
53 - GEAR BDE-400147-00.A2 400147-00 £3.80 £4.56
54 - KEY BDE-7027-00.A3 7027-00 £1.50 £1.80
55 - NO LONGER AVAILABLE BDE-000000-00.A13872 000000-00 -
56 - WASHER BDE-147196-00.A3 147196-00 £3.80 £4.56
57 - NO LONGER AVAILABLE LX BDE-000000-00.A13873 000000-00 -
57 - NO LONGER AVAILABLE XW BDE-000000-00.A13874 000000-00 -
57 - NO LONGER AVAILABLE GB BDE-000000-00.A13875 000000-00 -
58 - NO LONGER AVAILABLE GB BDE-000000-00.A13876 000000-00 -
59 - NO LONGER AVAILABLE GB BDE-000000-00.A13877 000000-00 -
60 - NO LONGER AVAILABLE GB BDE-000000-00.A13878 000000-00 -
61 - CAPACITOR LX BDE-135107-05.A2 135107-05 -
61 - CAPACITOR GB BDE-135107-05.A3 135107-05 -
61 - CAPACITOR XW BDE-135107-05.A4 135107-05 -
63 - PIN BDE-91286-00.A12 91286-00 £1.42 £1.70
64 - NO LONGER AVAILABLE XW BDE-000000-00.A13879 000000-00 -
64 - NO LONGER AVAILABLE LX BDE-000000-00.A13880 000000-00 -
64 - NO LONGER AVAILABLE GB BDE-000000-00.A13881 000000-00 -
68 - NO LONGER AVAILABLE XW BDE-000000-00.A13882 000000-00 -
68 - NO LONGER AVAILABLE LX BDE-000000-00.A13883 000000-00 -
68 - NO LONGER AVAILABLE GB BDE-000000-00.A13884 000000-00 -
70 - NO LONGER AVAILABLE LX BDE-000000-00.A13885 000000-00 -
70 - NO LONGER AVAILABLE XW BDE-000000-00.A13886 000000-00 -
70 - NO LONGER AVAILABLE GB BDE-000000-00.A13887 000000-00 -
71 - CHUCK KEY BDE-330034-03.A0 330034-03 £7.85 £9.42
72 - SCREW BDE-447735-02.A3 447735-02 £1.50 £1.80
73 - NO LONGER AVAILABLE LX BDE-000000-00.A13888 000000-00 -
73 - NO LONGER AVAILABLE XW BDE-000000-00.A13889 000000-00 -
73 - NO LONGER AVAILABLE GB BDE-000000-00.A13890 000000-00 -
75 - NO LONGER AVAILABLE XW BDE-000000-00.A13891 000000-00 -
75 - NO LONGER AVAILABLE LX BDE-000000-00.A13892 000000-00 -
75 - NO LONGER AVAILABLE GB BDE-000000-00.A13893 000000-00 -
76 - NO LONGER AVAILABLE XW BDE-000000-00.A13894 000000-00 -
76 - NO LONGER AVAILABLE LX BDE-000000-00.A13895 000000-00 -
77 - NO LONGER AVAILABLE LX BDE-000000-00.A13896 000000-00 -
77 - NO LONGER AVAILABLE XW BDE-000000-00.A13897 000000-00 -
78 - WASHER GB BDE-98197-03.A0 98197-03 £1.50 £1.80
78 - WASHER LX BDE-98197-03.A1 98197-03 £1.50 £1.80
78 - WASHER XW BDE-98197-03.A2 98197-03 £1.50 £1.80
79 - TIE LX BDE-71025-00.A6 71025-00 £1.42 £1.70
79 - TIE GB BDE-71025-00.A7 71025-00 £1.42 £1.70
79 - TIE XW BDE-71025-00.A8 71025-00 £1.42 £1.70
800 - GREASE BDE-429698-00.A19 429698-00 £84.42 £101.30
