101 - ARMATURE 120V LX
BDE-N030721.A7
N030721
|
-
|
|
|
|
101 - ARMATURE 230V GB
BDE-N079385.A3
N079385
|
-
|
|
|
|
102 - NO LONGER AVAILABLE LX
BDE-000000-00.A91651
000000-00
|
-
|
|
|
|
102 - FIELD 230V GB
BDE-327430-04.A6
327430-04
|
£37.82
|
£45.38
|
|
|
103 - SWITCH
BDE-581070-00.A10
581070-00
|
£19.90
|
£23.88
|
|
|
104 - BRUSH PAIR 230V GB
BDE-N542573.A17
N542573
|
-
|
|
|
|
104 - BRUSH PAIR 120V LX
BDE-582620-00.A1
582620-00
|
£33.13
|
£39.76
|
|
|
106 - CORDSET GB
BDE-582319-02.A2
582319-02
|
£25.70
|
£30.84
|
|
|
106 - CORDSET LX
BDE-324438-72.A8
324438-72
|
£19.90
|
£23.88
|
|
|
107 - ELECTRONIC 230V GB
BDE-582574-00.A3
582574-00
|
-
|
|
|
|
107 - ELECTRONIC 120V LX
BDE-582574-02.A3
582574-02
|
-
|
|
|
|
112 - CORD PROTECTOR
BDE-323091-01.A31
323091-01
|
£1.50
|
£1.80
|
|
|
113 - CORD CLAMP
BDE-821070.A375
821070
|
£1.50
|
£1.80
|
|
|
114 - SCREW
BDE-330065-08.A251
330065-08
|
£1.50
|
£1.80
|
|
|
115 - NO LONGER AVAILABLE
BDE-000000-00.A91654
000000-00
|
-
|
|
|
|
118 - HANDLE COVER
BDE-577712-00.A4
577712-00
|
-
|
|
|
|
120 - NO LONGER AVAILABLE
BDE-000000-00.A91652
000000-00
|
-
|
|
|
|
123 - NO LONGER AVAILABLE
BDE-000000-00.A91653
000000-00
|
-
|
|
|
|
124 - SCREW
BDE-330065-11.A21
330065-11
|
£1.50
|
£1.80
|
|
|
125 - FIELDCASE SA
BDE-582577-00.A8
582577-00
|
£69.63
|
£83.56
|
|
|
126 - BEARING
BDE-577745-00.A7
577745-00
|
£7.85
|
£9.42
|
|
|
127 - SLEEVE
BDE-325279-00.A31
325279-00
|
-
|
|
|
|
129 - FAN
BDE-577736-00.A5
577736-00
|
-
|
|
|
|
130 - SCREW
BDE-324119-02.A70
324119-02
|
£1.50
|
£1.80
|
|
|
131 - SHUTTER
BDE-326579-00.A13
326579-00
|
£2.26
|
£2.71
|
|
|
133 - BRUSH SPRING
BDE-326667-00.A29
326667-00
|
£1.50
|
£1.80
|
|
|
134 - HOLDER
BDE-326933-01.A45
326933-01
|
£3.30
|
£3.96
|
|
|
136 - SCREW TORX
BDE-324007-11.A101
324007-11
|
£1.50
|
£1.80
|
|
|
137 - SCREW TORX
BDE-324007-11.A102
324007-11
|
£1.50
|
£1.80
|
|
|
150 - GEARCASE SA
BDE-578487-02.A9
578487-02
|
£116.32
|
£139.59
|
|
|
151 - BEARING BALL
BDE-577745-01.A38
577745-01
|
£7.85
|
£9.42
|
|
|
152 - BEARING
BDE-330004-33.A10
330004-33
|
-
|
|
|
|
153 - GEARCASE COVER SA
BDE-578486-01.A3
578486-01
|
£29.32
|
£35.18
|
|
|
154 - SEAL
BDE-325936-00.A18
325936-00
|
£3.70
|
£4.44
|
|
|
163 - CLUTCH SA
BDE-496367-00.A9
496367-00
|
£101.69
|
£122.03
|
|
|
163 - REPAIR KIT
BDE-496440-00.A11
496440-00
|
£105.49
|
£126.59
|
|
|
164 - GEAR
BDE-492618-00.A12
492618-00
|
-
|
|
|
|
165 - SEAL
BDE-327141-05.A15
327141-05
|
£7.18
|
£8.62
|
|
|
166 - BUSH
BDE-325616-00.A32
325616-00
|
-
|
|
|
|
167 - SCREW
BDE-918825-02.A46
918825-02
|
£1.50
|
£1.80
|
|
|
169 - CRANKSHAFT
BDE-582431-00.A15
582431-00
|
£60.94
|
£73.13
|
|
|
170 - O RING
BDE-323711-26.A43
323711-26
|
£1.50
|
£1.80
|
|
|
171 - CON ROD
BDE-325002-00.A14
325002-00
|
£3.30
|
£3.96
|
|
|
172 - PISTON
BDE-N041843.A27
N041843
|
£12.17
|
£14.60
|
|
|
173 - PIN
BDE-330041-22.A48
330041-22
|
£1.50
|
£1.80
|
|
|
174 - RETAINER
BDE-325905-00.A9
325905-00
|
£1.50
|
£1.80
|
|
|
175 - O RING
BDE-576232-01.A12
576232-01
|
£5.88
|
£7.06
|
|
|
176 - CYLINDER
BDE-582576-00.A3
582576-00
|
£45.88
|
£55.06
|
|
|
177 - O RING
BDE-577744-00.A79
577744-00
|
£1.82
|
£2.19
|
|
|
180 - RAM
BDE-582575-00.A16
582575-00
|
£29.32
|
£35.18
|
|
|
181 - REPAIR KIT
BDE-496440-00.A12
496440-00
|
£105.49
|
£126.59
|
|
|
182 - WASHER LARGE
BDE-326085-00.A31
326085-00
|
£5.72
|
£6.87
|
|
|
183 - CIRCLIP
BDE-323763-03.A43
323763-03
|
£1.42
|
£1.70
|
|
|
184 - SPINDLE LOCK
BDE-1005697-00.A35
1005697-00
|
-
|
|
|
|
185 - SHAFT
BDE-325880-02.A13
325880-02
|
£3.80
|
£4.56
|
|
|
186 - SELECTOR FORK
BDE-325160-00.A40
325160-00
|
-
|
|
|
|
187 - SPRING
BDE-323395-08.A37
323395-08
|
£1.82
|
£2.19
|
|
|
188 - SPRING
BDE-323395-09.A11
323395-09
|
-
|
|
|
|
189 - SPACER
BDE-326093-00.A8
326093-00
|
£1.82
|
£2.19
|
|
|
190 - LINK
BDE-577731-00.A6
577731-00
|
£1.50
|
£1.80
|
|
|
191 - ECCENTRIC SA
BDE-577718-00.A6
577718-00
|
£1.50
|
£1.80
|
|
|
192 - O RING
BDE-323711-07.A48
323711-07
|
£1.82
|
£2.19
|
|
|
193 - LEVER SA
BDE-N542443.A2
N542443
|
-
|
|
|
|
196 - HANDLE
BDE-577711-00.A1
577711-00
|
-
|
|
|
|
197 - LENS
BDE-577735-00.A6
577735-00
|
£1.42
|
£1.70
|
|
|
200 - HANDLE SA
BDE-N021271.A3
N021271
|
£55.30
|
£66.36
|
|
|
205 - COVER
BDE-577710-01.A2
577710-01
|
£5.88
|
£7.06
|
|
|
205 - NO LONGER AVAILABLE
BDE-000000-00.A91655
000000-00
|
-
|
|
|
|
206 - O RING
BDE-323711-22.A20
323711-22
|
£1.50
|
£1.80
|
|
|
207 - FILTER
BDE-487229-00.A0
487229-00
|
£1.50
|
£1.80
|
|
|
207 - FILTER
BDE-581578-00.A1
581578-00
|
£1.42
|
£1.70
|
|
|
208 - COVER & SEAL
BDE-491348-01.A2
491348-01
|
£3.22
|
£3.86
|
|
|
251 - COLLAR
BDE-326555-00.A14
326555-00
|
£5.88
|
£7.06
|
|
|
252 - BUSH
BDE-326552-01.A1
326552-01
|
£5.88
|
£7.06
|
|
|
253 - PIN
BDE-N079374.A51
N079374
|
£1.50
|
£1.80
|
|
|
254 - CLAMP
BDE-N021108.A6
N021108
|
£9.41
|
£11.29
|
|
|
255 - LOCKING RING
BDE-326553-00.A45
326553-00
|
£4.69
|
£5.63
|
|
|
256 - NO LONGER AVAILABLE
BDE-000000-00.A91656
000000-00
|
-
|
|
|
|
257 - SCREW WING
BDE-326573-00.A10
326573-00
|
£5.88
|
£7.06
|
|
|
258 - NUT
BDE-326556-00.A29
326556-00
|
£1.50
|
£1.80
|
|
|
259 - NUT
BDE-330021-01.A69
330021-01
|
£1.50
|
£1.80
|
|
|
260 - DEPTH ROD
BDE-326205-00.A14
326205-00
|
£3.70
|
£4.44
|
|
|
261 - WASHER
BDE-323753-11.A24
323753-11
|
£3.80
|
£4.56
|
|
|
262 - O RING
BDE-577744-05.A14
577744-05
|
-
|
|
|
|
263 - WASHER
BDE-323753-14.A25
323753-14
|
£1.42
|
£1.70
|
|
|
264 - SPRING
BDE-323395-07.A19
323395-07
|
£1.50
|
£1.80
|
|
|
265 - BEAT PIECE
BDE-582432-01.A4
582432-01
|
£44.00
|
£52.80
|
|
|
266 - SEAL
BDE-577484-00.A27
577484-00
|
£16.03
|
£19.24
|
|
|
267 - WASHER
BDE-582381-00.A32
582381-00
|
£5.88
|
£7.06
|
|
|
268 - O RING
BDE-577744-02.A5
577744-02
|
£1.82
|
£2.19
|
|
|
269 - WASHER
BDE-323753-16.A17
323753-16
|
£3.80
|
£4.56
|
|
|
270 - O RING
BDE-N210233.A38
N210233
|
£1.50
|
£1.80
|
|
|
271 - CAP
BDE-326044-01.A2
326044-01
|
£1.50
|
£1.80
|
|
|
272 - SPINDLE
BDE-493133-00.A32
493133-00
|
£153.22
|
£183.86
|
|
|
273 - ROLLER
BDE-325878-00.A45
325878-00
|
£1.50
|
£1.80
|
|
|
274 - LIP SEAL
BDE-329816-00.A33
329816-00
|
£3.30
|
£3.96
|
|
|
275 - COLLAR
BDE-326575-01.A17
326575-01
|
£5.88
|
£7.06
|
|
|
276 - SLEEVE SA
BDE-479247-00.A34
479247-00
|
£7.18
|
£8.62
|
|
|
277 - PART NLS ORDER SLEEVE SA 479247-00
BDE-000000-03.A12
000000-03
|
-
|
|
|
|
278 - PART NLS ORDER SLEEVE SA 479247-00
BDE-000000-03.A13
000000-03
|
-
|
|
|
|
279 - SPRING
BDE-323395-06.A38
323395-06
|
£1.50
|
£1.80
|
|
|
280 - HALF WASHER
BDE-325929-00.A33
325929-00
|
£1.50
|
£1.80
|
|
|
281 - SPRING
BDE-487118-00.A9
487118-00
|
£1.50
|
£1.80
|
|
|
282 - GUIDE
BDE-N313860.A23
N313860
|
£4.69
|
£5.63
|
|
|
283 - SEAL
BDE-327141-00.A35
327141-00
|
£1.82
|
£2.19
|
|
|
284 - HOUSING SA
BDE-578489-00.A3
578489-00
|
£84.42
|
£101.30
|
|
|
285 - GASKET
BDE-577727-01.A8
577727-01
|
£2.78
|
£3.34
|
|
|
286 - SPINDLE LOCK
BDE-588560-00.A12
588560-00
|
-
|
|
|
|
287 - RING
BDE-323763-04.A8
323763-04
|
-
|
|
|
|
288 - GUIDE
BDE-327208-00.A33
327208-00
|
£1.50
|
£1.80
|
|
|
290 - END CAP
BDE-578493-00.A11
578493-00
|
£16.03
|
£19.24
|
|
|
317 - RING
BDE-577746-00.A45
577746-00
|
£1.50
|
£1.80
|
|
|
318 - COVER-TOP
BDE-577708-00.A1
577708-00
|
£7.85
|
£9.42
|
|
|
319 - HOUSING LOWER
BDE-577709-00.A2
577709-00
|
£11.87
|
£14.24
|
|
|
320 - SCREW
BDE-323924-08.A18
323924-08
|
£1.50
|
£1.80
|
|
|
322 - SCREW
BDE-326619-00.A16
326619-00
|
£1.50
|
£1.80
|
|
|
400 - COVER SA
BDE-493136-01.A1
493136-01
|
-
|
|
|
|
800 - GREASE 100 GMS
BDE-328771-02.A19
328771-02
|
£18.91
|
£22.69
|
|
|
801 - BIT GREASE 50G
BDE-328771-07.A30
328771-07
|
£7.18
|
£8.62
|
|
|
836 - S.T.PULLER
BDE-559632-99.A11
559632-99
|
£34.00
|
£40.80
|
|
|
837 - S.T.MANDREL
BDE-559633-99.A7
559633-99
|
£24.39
|
£29.27
|
|
|
838 - S.T.PULLER
BDE-559631-99.A7
559631-99
|
£80.98
|
£97.18
|
|
|
839 - S.T.SUPPORT JIG
BDE-559656-99.A45
559656-99
|
£71.44
|
£85.73
|
|
|
840 - S.T.ASSEMBLY JIG
BDE-559597-99.A19
559597-99
|
£38.80
|
£46.56
|
|
|
841 - S.T.BLOCK
BDE-559598-99.A27
559598-99
|
-
|
|
|
|
842 - S.T.LIP SEAL REMOVER
BDE-559644-99.A2
559644-99
|
£24.39
|
£29.27
|
|
|
843 - S.T.SEAL FITTING TOOL
BDE-559645-99.A24
559645-99
|
£25.70
|
£30.84
|
|
|
846 - SERVICE KIT 230V GB
BDE-N027353.A4
N027353
|
-
|
|
|
|
847 - SERVICE KIT 230V GB
BDE-589301-00.A3
589301-00
|
-
|
|
|
|
847 - SERVICE KIT 120V LX
BDE-589301-01.A2
589301-01
|
-
|
|
|
