7 - CORD PROTECTOR
BDE-584090-00.A69
584090-00
|
£1.50
|
£1.80
|
|
|
12 - LEAD WHITE LX
BDE-584304-00.A1
584304-00
|
£1.50
|
£1.80
|
|
|
13 - LEAD BLUE LX
BDE-584304-10.A38
584304-10
|
£1.50
|
£1.80
|
|
|
14 - LEAD BLACK LX
BDE-584304-04.A36
584304-04
|
£1.50
|
£1.80
|
|
|
15 - LEAD VIOLET LX
BDE-584304-05.A1
584304-05
|
£1.50
|
£1.80
|
|
|
16 - CHOKE LEAD RED LX
BDE-584304-02.A20
584304-02
|
£4.58
|
£5.49
|
|
|
17 - CHOKE LEAD LX
BDE-584304-03.A1
584304-03
|
£4.58
|
£5.49
|
|
|
18 - BUMPER
BDE-930026-01.A224
930026-01
|
£1.50
|
£1.80
|
|
|
19 - REPAIR KIT
BDE-479833-00.A10
479833-00
|
-
|
|
|
|
21 - SLEEVE
BDE-870052.A40
870052
|
£1.50
|
£1.80
|
|
|
22 - SCREW
BDE-324006-14.A31
324006-14
|
£1.50
|
£1.80
|
|
|
23 - SCREW
BDE-326519-03.A33
326519-03
|
£1.50
|
£1.80
|
|
|
25 - BEARING
BDE-330003-19.A6
330003-19
|
£2.78
|
£3.34
|
|
|
31 - BAFFLE FAN
BDE-577826-00.A32
577826-00
|
£2.78
|
£3.34
|
|
|
32 - FIELDCASE
BDE-577810-00.A7
577810-00
|
£14.57
|
£17.48
|
|
|
34 - REPAIR KIT
BDE-479833-00.A11
479833-00
|
-
|
|
|
|
35 - SCREW
BDE-330065-06.A341
330065-06
|
£1.50
|
£1.80
|
|
|
36 - CORD CLAMP
BDE-821070.A62
821070
|
£1.50
|
£1.80
|
|
|
37 - SCREW
BDE-330065-09.A11
330065-09
|
£1.50
|
£1.80
|
|
|
40 - SCREW
BDE-330065-25.A19
330065-25
|
£1.50
|
£1.80
|
|
|
45 - O RING
BDE-577791-00.A15
577791-00
|
£1.50
|
£1.80
|
|
|
50 - INTERSHAFT SA
BDE-585480-00.A20
585480-00
|
£84.42
|
£101.30
|
|
|
51 - O RING
BDE-580907-00.A2
580907-00
|
£1.42
|
£1.70
|
|
|
60 - FILTER
BDE-582865-00.A39
582865-00
|
£1.50
|
£1.80
|
|
|
62 - SCREW
BDE-583981-00.A55
583981-00
|
£1.50
|
£1.80
|
|
|
70 - HOUSING SA
BDE-586502-00.A0
586502-00
|
£29.32
|
£35.18
|
|
|
71 - BEARING
BDE-330003-31.A98
330003-31
|
£2.78
|
£3.34
|
|
|
72 - SEAL
BDE-578229-00.A26
578229-00
|
£1.50
|
£1.80
|
|
|
73 - BEARING BLOCK
BDE-577801-00.A25
577801-00
|
£5.88
|
£7.06
|
|
|
74 - WASHER SHIM
BDE-577802-00.A66
577802-00
|
£2.21
|
£2.65
|
|
|
75 - PISTON
BDE-584420-00.A25
584420-00
|
£30.08
|
£36.10
|
|
|
76 - O RING
BDE-579699-00.A3
579699-00
|
£1.50
|
£1.80
|
|
|
77 - NO LONGER AVAILABLE
BDE-000000-00.A125436
000000-00
|
-
|
|
|
|
78 - BEARING BUSH
BDE-N042808.A9
N042808
|
£5.88
|
£7.06
|
|
|
79 - SCREW
BDE-324006-15.A57
324006-15
|
£1.50
|
£1.80
|
|
|
90 - CLIP
BDE-577793-00.A51
577793-00
|
£1.50
|
£1.80
|
|
|
91 - BUSH
BDE-584426-00.A64
584426-00
|
£16.03
|
£19.24
|
|
|
92 - O RING
BDE-580990-00.A4
580990-00
|
£1.50
|
£1.80
|
|
|
93 - O RING
BDE-577135-00.A43
577135-00
|
£3.30
|
£3.96
|
|
|
94 - DAMPER
BDE-584425-00.A2
584425-00
|
£16.03
|
£19.24
|
|
|
95 - BEAT PIECE
BDE-584424-00.A2
584424-00
|
£17.48
|
£20.97
|
|
|
96 - BEARING & SEAL
BDE-584423-00.A0
584423-00
|
£18.91
|
£22.69
|
|
|
97 - SEAL
BDE-577139-00.A49
577139-00
|
£1.50
|
£1.80
|
|
|
110 - WASHER
BDE-577797-00.A39
577797-00
|
£1.50
|
£1.80
|
|
|
111 - O RING
BDE-577744-00.A50
577744-00
|
£1.82
|
£2.19
|
|
|
112 - CLUTCH SA
BDE-587482-00.A3
587482-00
|
£41.24
|
£49.49
|
|
|
113 - SPRING
BDE-579178-00.A32
579178-00
|
£1.50
|
£1.80
|
|
|
114 - CYLINDER SA
BDE-584422-00.A2
584422-00
|
£108.20
|
£129.84
|
|
|
115 - WASHER
BDE-577814-00.A57
577814-00
|
£2.26
|
£2.71
|
|
|
118 - NO LONGER AVAILABLE
BDE-000000-00.A125437
000000-00
|
-
|
|
|
|
121 - SCREW
BDE-330065-28.A56
330065-28
|
£1.50
|
£1.80
|
|
|
132 - SPRING
BDE-871690.A160
871690
|
£1.66
|
£1.99
|
|
|
133 - WASHER
BDE-578387-00.A139
578387-00
|
£1.66
|
£1.99
|
|
|
134 - BALL 7MM
BDE-583890-00.A84
583890-00
|
£1.66
|
£1.99
|
|
|
135 - TUBE
BDE-N504215.A35
N504215
|
£7.18
|
£8.62
|
|
|
136 - CAP
BDE-323489-00.A214
323489-00
|
£1.66
|
£1.99
|
|
|
160 - SIDE HANDLE
BDE-589467-00.A22
589467-00
|
£7.85
|
£9.42
|
|
|
170 - DEPTH STOP
BDE-798846-02.A4
798846-02
|
£1.50
|
£1.80
|
|
|
800 - GREASE 90 GMS
BDE-870889-02.A633
870889-02
|
£7.85
|
£9.42
|
|
|
801 - GREASE 10 GMS
BDE-487130-04.A15
487130-04
|
£3.80
|
£4.56
|
|
