1 - ARMATURE 230V GB
BDE-496250-00.A2
496250-00
|
-
|
|
|
|
1 - ARMATURE 120V LX
BDE-496251-00.A0
496251-00
|
-
|
|
|
|
2 - FIELD 120V LX
BDE-496247-00.A13
496247-00
|
£24.39
|
£29.27
|
|
|
2 - FIELD 230V GB
BDE-576690-05.A2
576690-05
|
£30.08
|
£36.10
|
|
|
3 - SWITCH 115V LX
BDE-583748-04.A1
583748-04
|
£51.90
|
£62.28
|
|
|
3 - SWITCH GB
BDE-583748-08.A0
583748-08
|
£30.08
|
£36.10
|
|
|
4 - BRUSH HOLDER 230V GB
BDE-577805-03.A14
577805-03
|
-
|
|
|
|
4 - BRUSH HOLDER 115V LX
BDE-577805-04.A1
577805-04
|
£19.90
|
£23.88
|
|
|
5 - BRUSH KIT GB
BDE-584429-00.A13
584429-00
|
£19.90
|
£23.88
|
|
|
5 - BRUSH KIT LX
BDE-584429-01.A2
584429-01
|
£19.90
|
£23.88
|
|
|
6 - LEAD GREY LX
BDE-487505-00.A0
487505-00
|
£9.41
|
£11.29
|
|
|
6 - LEAD GREY GB
BDE-487505-00.A1
487505-00
|
£9.41
|
£11.29
|
|
|
7 - CORD PROTECTOR
BDE-584090-00.A12
584090-00
|
£1.50
|
£1.80
|
|
|
8 - CORDSET (M/PLUG) LX
BDE-582319-05.A17
582319-05
|
£36.42
|
£43.70
|
|
|
8 - CORDSET (M/PLUG) GB GB
BDE-582319-04.A5
582319-04
|
£29.32
|
£35.18
|
|
|
9 - PLUG
BDE-578222-00.A7
578222-00
|
£1.50
|
£1.80
|
|
|
10 - LEAD RED
BDE-582064-23.A1
582064-23
|
£1.82
|
£2.19
|
|
|
11 - LEAD WHITE
BDE-582064-24.A10
582064-24
|
£1.82
|
£2.19
|
|
|
12 - LEAD VIOLET
BDE-582064-15.A10
582064-15
|
£1.50
|
£1.80
|
|
|
13 - LEAD WHITE
BDE-582064-19.A1
582064-19
|
£1.78
|
£2.13
|
|
|
14 - LEAD BLUE
BDE-582064-16.A4
582064-16
|
£1.50
|
£1.80
|
|
|
15 - LEAD BLACK
BDE-582064-20.A12
582064-20
|
£1.50
|
£1.80
|
|
|
16 - NO LONGER AVAILABLE LX
BDE-000000-00.A29367
000000-00
|
-
|
|
|
|
16 - LEAD RED GB
BDE-582064-14.A3
582064-14
|
£5.88
|
£7.06
|
|
|
17 - NO LONGER AVAILABLE LX
BDE-000000-00.A29368
000000-00
|
-
|
|
|
|
17 - LEAD YELLOW GB
BDE-582064-13.A6
582064-13
|
£5.88
|
£7.06
|
|
|
18 - BUMPER
BDE-930026-01.A23
930026-01
|
£1.50
|
£1.80
|
|
|
19 - SLIDER
BDE-578218-00.A24
578218-00
|
£2.78
|
£3.34
|
|
|
20 - LEVER
BDE-578220-00.A19
578220-00
|
£1.50
|
£1.80
|
|
|
21 - SLEEVE
BDE-870052.A238
870052
|
£1.50
|
£1.80
|
|
|
22 - BUSH
BDE-579720-00.A1
579720-00
|
£1.50
|
£1.80
|
|
|
23 - SCREW
BDE-326519-03.A21
326519-03
|
£1.50
|
£1.80
|
|
|
24 - BEARING
BDE-330003-19.A253
330003-19
|
£2.78
|
£3.34
|
|
|
25 - BEARING
BDE-330003-64.A25
330003-64
|
£4.69
|
£5.63
|
|
|
26 - CONNECTOR
BDE-323534-00.A37
323534-00
|
£1.50
|
£1.80
|
|
|
28 - INSERT
BDE-582877-00.A12
582877-00
|
£1.50
|
£1.80
|
|
|
29 - INSERT LX
BDE-584551-00.A34
584551-00
|
£2.26
|
£2.71
|
|
|
29 - INSERT GB
BDE-584551-00.A35
584551-00
|
£2.26
|
£2.71
|
|
|
30 - HOUSING
BDE-577986-20.A1
577986-20
|
£12.17
|
£14.60
|
|
|
31 - BAFFLE FAN
BDE-581808-00.A1
581808-00
|
£1.50
|
£1.80
|
|
|
32 - FIELD CASE
BDE-577993-00.A0
577993-00
|
£10.85
|
£13.02
|
|
|
33 - END CAP SA
BDE-584041-00.A1
584041-00
|
£9.17
|
£11.00
|
|
|
34 - HANDLE COVER
BDE-577987-10.A9
577987-10
|
£12.17
|
£14.60
|
|
|
35 - SCREW
BDE-330065-08.A52
330065-08
|
£1.50
|
£1.80
|
|
|
36 - CORD CLAMP
BDE-821070.A513
821070
|
£1.50
|
£1.80
|
|
|
37 - SCREW
BDE-330065-13.A99
330065-13
|
£1.50
|
£1.80
|
|
|
39 - SCREW
BDE-330065-26.A12
330065-26
|
£1.50
|
£1.80
|
|
|
40 - SCREW
BDE-330065-25.A108
330065-25
|
£1.50
|
£1.80
|
|
|
50 - NO LONGER AVAILABLE
BDE-000000-00.A29369
000000-00
|
-
|
|
|
|
51 - O RING
BDE-580908-00.A6
580908-00
|
£1.50
|
£1.80
|
|
|
52 - PLATE
BDE-578271-00.A36
578271-00
|
£3.80
|
£4.56
|
|
|
53 - HOLDER
BDE-579564-00.A30
579564-00
|
£1.50
|
£1.80
|
|
|
54 - SELECTOR
BDE-579552-00.A10
579552-00
|
£4.69
|
£5.63
|
|
|
55 - O RING
BDE-584638-00.A38
584638-00
|
£1.50
|
£1.80
|
|
|
56 - LEVER
BDE-587269-00.A13
587269-00
|
£1.50
|
£1.80
|
|
|
57 - SCREW
BDE-324007-14.A25
324007-14
|
-
|
|
|
|
58 - LOCK BUTTON
BDE-579184-00.A9
579184-00
|
£1.50
|
£1.80
|
|
|
59 - SPRING
BDE-579179-00.A25
579179-00
|
£1.50
|
£1.80
|
|
|
60 - FILTER
BDE-582865-00.A73
582865-00
|
£1.50
|
£1.80
|
|
|
61 - COVER
BDE-579185-00.A22
579185-00
|
£1.82
|
£2.19
|
|
|
62 - SCREW
BDE-583981-00.A16
583981-00
|
£1.50
|
£1.80
|
|
|
70 - GEARCASE SA
BDE-584432-00.A9
584432-00
|
-
|
|
|
|
71 - BEARING
BDE-330003-81.A13
330003-81
|
£4.69
|
£5.63
|
|
|
72 - SEAL
BDE-578229-00.A49
578229-00
|
£1.50
|
£1.80
|
|
|
73 - BEARING BLOCK
BDE-577801-00.A74
577801-00
|
£5.88
|
£7.06
|
|
|
74 - WASHER SHIM
BDE-577802-00.A6
577802-00
|
£2.21
|
£2.65
|
|
|
75 - PISTON
BDE-496246-00.A21
496246-00
|
£18.91
|
£22.69
|
|
|
76 - O RING
BDE-579699-00.A77
579699-00
|
£1.50
|
£1.80
|
|
|
77 - RAM
BDE-496245-00.A17
496245-00
|
£17.48
|
£20.97
|
|
|
78 - BEARING BUSH
BDE-N042808.A39
N042808
|
£5.88
|
£7.06
|
|
|
79 - SCREW
BDE-324006-15.A75
324006-15
|
£1.50
|
£1.80
|
|
|
80 - FILTER
BDE-587252-00.A17
587252-00
|
£1.50
|
£1.80
|
|
|
90 - CLIP
BDE-577793-00.A2
577793-00
|
£1.50
|
£1.80
|
|
|
91 - BUSH
BDE-584426-00.A13
584426-00
|
£16.03
|
£19.24
|
|
|
92 - O RING
BDE-580990-00.A79
580990-00
|
£1.50
|
£1.80
|
|
|
93 - O RING
BDE-577135-00.A59
577135-00
|
£3.30
|
£3.96
|
|
|
94 - DAMPER
BDE-584425-00.A53
584425-00
|
£16.03
|
£19.24
|
|
|
95 - BEAT PIECE
BDE-584424-01.A1
584424-01
|
£10.85
|
£13.02
|
|
|
96 - BEARING & SEAL
BDE-584423-01.A1
584423-01
|
£19.90
|
£23.88
|
|
|
97 - SEAL
BDE-577139-00.A27
577139-00
|
£1.50
|
£1.80
|
|
|
100 - LEVER KIT
BDE-495665-00.A3
495665-00
|
£7.64
|
£9.17
|
|
|
110 - WASHER
BDE-577797-00.A1
577797-00
|
£1.50
|
£1.80
|
|
|
111 - O RING
BDE-577744-00.A11
577744-00
|
£1.82
|
£2.19
|
|
|
112 - CLUTCH SA
BDE-587482-00.A37
587482-00
|
£41.24
|
£49.49
|
|
|
113 - SPRING
BDE-579178-00.A13
579178-00
|
£1.50
|
£1.80
|
|
|
114 - CYLINDER SA
BDE-584422-01.A1
584422-01
|
£110.62
|
£132.74
|
|
|
115 - WASHER
BDE-577814-00.A19
577814-00
|
£2.26
|
£2.71
|
|
|
116 - SCREW
BDE-330065-05.A136
330065-05
|
£1.50
|
£1.80
|
|
|
117 - LOCKING DEVICE
BDE-580291-00.A33
580291-00
|
£2.26
|
£2.71
|
|
|
118 - COVER GEARCASE
BDE-584433-01.A6
584433-01
|
£30.08
|
£36.10
|
|
|
119 - RING
BDE-577795-00.A44
577795-00
|
£1.50
|
£1.80
|
|
|
121 - SCREW
BDE-330065-28.A15
330065-28
|
£1.50
|
£1.80
|
|
|
130 - SPINDLE
BDE-N031254.A3
N031254
|
£25.05
|
£30.06
|
|
|
131 - SLEEVE SA
BDE-584431-00.A2
584431-00
|
£37.35
|
£44.82
|
|
|
132 - SPRING
BDE-871690.A87
871690
|
£1.66
|
£1.99
|
|
|
133 - WASHER
BDE-578387-00.A85
578387-00
|
£1.66
|
£1.99
|
|
|
134 - BALL 7MM
BDE-583890-00.A157
583890-00
|
£1.66
|
£1.99
|
|
|
135 - TUBE
BDE-N774198.A28
N774198
|
£12.17
|
£14.60
|
|
|
136 - CAP
BDE-323489-00.A75
323489-00
|
£1.66
|
£1.99
|
|
|
137 - RING
BDE-579212-00.A44
579212-00
|
£1.66
|
£1.99
|
|
|
138 - RING
BDE-579212-00.A45
579212-00
|
£1.66
|
£1.99
|
|
|
140 - HOLDER TOOL
BDE-N591846.A26
N591846
|
£60.94
|
£73.13
|
|
|
145 - SPINDLE
BDE-584676-00.A12
584676-00
|
£34.00
|
£40.80
|
|
|
146 - SPINDLE SA
BDE-584556-00.A8
584556-00
|
£55.30
|
£66.36
|
|
|
147 - CHUCK KEYLESS
BDE-582512-02.A35
582512-02
|
£24.39
|
£29.27
|
|
|
148 - SCREW
BDE-605256-02.A45
605256-02
|
£1.50
|
£1.80
|
|
|
150 - CHUCK & SPINDLE SA
BDE-N591847.A13
N591847
|
£51.90
|
£62.28
|
|
|
160 - HANDLE SIDE SA
BDE-494661-00.A1
494661-00
|
£18.91
|
£22.69
|
|
|
170 - DEPTH STOP
BDE-495699-00.A2
495699-00
|
£7.85
|
£9.42
|
|
|
800 - GREASE 90 GMS
BDE-870889-02.A2
870889-02
|
£7.85
|
£9.42
|
|
|
801 - GREASE 10 GMS
BDE-487130-04.A87
487130-04
|
£3.80
|
£4.56
|
|
|
817 - LABEL
BDE-496620-00.A17
496620-00
|
£1.50
|
£1.80
|
|
|
821 - NO LONGER AVAILABLE GB
BDE-000000-00.A29370
000000-00
|
-
|
|
|
|
821 - NO LONGER AVAILABLE LX
BDE-000000-00.A29371
000000-00
|
-
|
|
|
|
836 - S.T.TERMINAL EXTRACTOR
BDE-559638-99.A27
559638-99
|
£24.39
|
£29.27
|
|
|
846 - SERVICE KIT 115V LX
BDE-585149-00.A2
585149-00
|
£55.30
|
£66.36
|
|
|
846 - SERVICE KIT 230V GB
BDE-585146-00.A8
585146-00
|
£55.30
|
£66.36
|
|
|
861 - KITBOX
BDE-381297-85.A3
381297-85
|
£125.16
|
£150.19
|
|
|
861 - KITBOX
BDE-578005-00.A0
578005-00
|
£34.00
|
£40.80
|
|
