1 - ARMATURE 230V GB
BDE-N569794.A2
N569794
|
-
|
|
|
|
1 - ARMATURE 120V LX
BDE-N569792.A0
N569792
|
-
|
|
|
|
2 - FIELD 230V GB
BDE-576690-05.A4
576690-05
|
£30.08
|
£36.10
|
|
|
2 - FIELD 120V LX
BDE-496247-00.A16
496247-00
|
£24.39
|
£29.27
|
|
|
3 - SWITCH LX
BDE-1006749-01.A5
1006749-01
|
£41.24
|
£49.49
|
|
|
3 - SWITCH LOCK-ON GB
BDE-1006749-00.A0
1006749-00
|
£41.24
|
£49.49
|
|
|
4 - BRUSH HOLDER 230V GB
BDE-577805-03.A13
577805-03
|
-
|
|
|
|
4 - BRUSH HOLDER 115V LX
BDE-577805-04.A2
577805-04
|
£19.90
|
£23.88
|
|
|
5 - BRUSH KIT LX
BDE-584429-01.A0
584429-01
|
£19.90
|
£23.88
|
|
|
5 - BRUSH KIT GB
BDE-584429-00.A15
584429-00
|
£19.90
|
£23.88
|
|
|
6 - SCREW
BDE-324119-04.A5
324119-04
|
£1.50
|
£1.80
|
|
|
7 - CORD PROTECTOR LX
BDE-584090-00.A20
584090-00
|
£1.50
|
£1.80
|
|
|
7 - CORD PROTECTOR GB
BDE-584090-00.A21
584090-00
|
£1.50
|
£1.80
|
|
|
8 - CORDSET LX
BDE-582319-40.A7
582319-40
|
£41.24
|
£49.49
|
|
|
8 - CORDSET GB
BDE-582319-39.A0
582319-39
|
£34.00
|
£40.80
|
|
|
9 - PLUG
BDE-578222-00.A8
578222-00
|
£1.50
|
£1.80
|
|
|
10 - TUBE GUIDE
BDE-1005646-00.A2
1005646-00
|
£7.18
|
£8.62
|
|
|
11 - BEARING HOLDER
BDE-1007508-00.A4
1007508-00
|
-
|
|
|
|
12 - GUIDE BUSH
BDE-1007502-00.A4
1007502-00
|
£4.69
|
£5.63
|
|
|
13 - BELLOWS
BDE-1006418-00.A4
1006418-00
|
£1.50
|
£1.80
|
|
|
14 - SCREW
BDE-330065-13.A97
330065-13
|
£1.50
|
£1.80
|
|
|
15 - SPRING
BDE-1006421-00.A4
1006421-00
|
£1.50
|
£1.80
|
|
|
16 - HANDLE SA
BDE-N395636.A5
N395636
|
£37.35
|
£44.82
|
|
|
17 - STOP NUT
BDE-1007503-00.A4
1007503-00
|
£4.69
|
£5.63
|
|
|
18 - BUMPER
BDE-930026-01.A9
930026-01
|
£1.50
|
£1.80
|
|
|
19 - LEVER
BDE-1006423-00.A4
1006423-00
|
£1.50
|
£1.80
|
|
|
20 - SCREW
BDE-N066799-00.A7
N066799-00
|
£1.50
|
£1.80
|
|
|
21 - SLEEVE
BDE-870052.A234
870052
|
£1.50
|
£1.80
|
|
|
22 - BUSH
BDE-579720-00.A2
579720-00
|
£1.50
|
£1.80
|
|
|
23 - SCREW
BDE-326519-03.A24
326519-03
|
£1.50
|
£1.80
|
|
|
24 - BEARING
BDE-330003-19.A261
330003-19
|
£2.78
|
£3.34
|
|
|
25 - BEARING
BDE-330003-64.A23
330003-64
|
£4.69
|
£5.63
|
|
|
29 - INSERT LX
BDE-584551-00.A42
584551-00
|
£2.26
|
£2.71
|
|
|
29 - INSERT GB
BDE-584551-00.A43
584551-00
|
£2.26
|
£2.71
|
|
|
30 - HOUSING
BDE-1006414-00.A3
1006414-00
|
£10.85
|
£13.02
|
|
|
31 - BAFFLE FAN
BDE-581808-00.A2
581808-00
|
£1.50
|
£1.80
|
|
|
32 - FIELD CASE
BDE-577993-00.A2
577993-00
|
£10.85
|
£13.02
|
|
|
33 - END CAP SA
BDE-N039637.A0
N039637
|
£3.80
|
£4.56
|
|
|
34 - HANDLE COVER
BDE-N387348.A4
N387348
|
£12.17
|
£14.60
|
|
|
35 - SCREW
BDE-330065-08.A55
330065-08
|
£1.50
|
£1.80
|
|
|
36 - CORD CLAMP
BDE-821070.A535
821070
|
£1.50
|
£1.80
|
|
|
37 - SCREW
BDE-330065-08.A56
330065-08
|
£1.50
|
£1.80
|
|
|
38 - SCREW
BDE-330065-06.A50
330065-06
|
£1.50
|
£1.80
|
|
|
39 - SCREW
BDE-330065-26.A13
330065-26
|
£1.50
|
£1.80
|
|
|
40 - SCREW
BDE-330065-25.A91
330065-25
|
£1.50
|
£1.80
|
|
|
41 - AXLE
BDE-1006419-00.A3
1006419-00
|
£1.50
|
£1.80
|
|
|
42 - DAMPER
BDE-1006429-00.A4
1006429-00
|
£3.80
|
£4.56
|
|
|
46 - SET OF LEAD WIRES GB
BDE-N020436.A3
N020436
|
£30.08
|
£36.10
|
|
|
46 - SET OF LEAD WIRES LX
BDE-N031248.A2
N031248
|
£38.80
|
£46.56
|
|
|
50 - NO LONGER AVAILABLE
BDE-000000-00.A30013
000000-00
|
-
|
|
|
|
52 - PLATE
BDE-578271-00.A42
578271-00
|
£3.80
|
£4.56
|
|
|
53 - HOLDER
BDE-579564-00.A32
579564-00
|
£1.50
|
£1.80
|
|
|
54 - SELECTOR
BDE-1006437-00.A7
1006437-00
|
£3.80
|
£4.56
|
|
|
55 - O RING
BDE-584638-00.A31
584638-00
|
£1.50
|
£1.80
|
|
|
56 - KNOB
BDE-1006434-00.A9
1006434-00
|
£2.78
|
£3.34
|
|
|
57 - SCREW
BDE-324007-15.A12
324007-15
|
£1.50
|
£1.80
|
|
|
58 - TRIGGER
BDE-1006435-00.A9
1006435-00
|
£2.78
|
£3.34
|
|
|
59 - SPRING
BDE-1008957-00.A26
1008957-00
|
£1.50
|
£1.80
|
|
|
60 - FILTER
BDE-582865-00.A79
582865-00
|
£1.50
|
£1.80
|
|
|
62 - SCREW
BDE-583981-00.A20
583981-00
|
£1.50
|
£1.80
|
|
|
70 - GEARCASE SA
BDE-N031252.A1
N031252
|
£44.14
|
£52.97
|
|
|
71 - BEARING
BDE-330003-81.A10
330003-81
|
£4.69
|
£5.63
|
|
|
72 - SEAL
BDE-578229-00.A38
578229-00
|
£1.50
|
£1.80
|
|
|
73 - BEARING BLOCK
BDE-577801-00.A64
577801-00
|
£5.88
|
£7.06
|
|
|
74 - WASHER SHIM
BDE-577802-00.A18
577802-00
|
£2.21
|
£2.65
|
|
|
75 - PISTON
BDE-496246-00.A16
496246-00
|
£18.91
|
£22.69
|
|
|
76 - O RING
BDE-579699-00.A70
579699-00
|
£1.50
|
£1.80
|
|
|
77 - RAM
BDE-496245-00.A22
496245-00
|
£17.48
|
£20.97
|
|
|
78 - BEARING BUSH
BDE-N042808.A32
N042808
|
£5.88
|
£7.06
|
|
|
79 - SCREW
BDE-324006-15.A84
324006-15
|
£1.50
|
£1.80
|
|
|
90 - CLIP
BDE-577793-00.A12
577793-00
|
£1.50
|
£1.80
|
|
|
91 - BUSH
BDE-584426-00.A7
584426-00
|
£16.03
|
£19.24
|
|
|
92 - O RING
BDE-580990-00.A83
580990-00
|
£1.50
|
£1.80
|
|
|
93 - O RING
BDE-577135-00.A65
577135-00
|
£3.30
|
£3.96
|
|
|
94 - DAMPER
BDE-584425-00.A59
584425-00
|
£16.03
|
£19.24
|
|
|
95 - BEAT PIECE
BDE-584424-01.A0
584424-01
|
£10.85
|
£13.02
|
|
|
96 - BEARING & SEAL
BDE-584423-01.A0
584423-01
|
£19.90
|
£23.88
|
|
|
97 - SEAL
BDE-577139-00.A20
577139-00
|
£1.50
|
£1.80
|
|
|
100 - LEVER KIT
BDE-N031251.A11
N031251
|
£12.17
|
£14.60
|
|
|
110 - WASHER
BDE-577797-00.A7
577797-00
|
£1.50
|
£1.80
|
|
|
111 - O RING
BDE-577744-00.A8
577744-00
|
£1.82
|
£2.19
|
|
|
112 - CLUTCH SA
BDE-587482-00.A49
587482-00
|
£41.24
|
£49.49
|
|
|
113 - SPRING
BDE-579178-00.A14
579178-00
|
£1.50
|
£1.80
|
|
|
114 - CYLINDER SA
BDE-584422-01.A0
584422-01
|
£110.62
|
£132.74
|
|
|
115 - WASHER
BDE-577814-00.A15
577814-00
|
£2.26
|
£2.71
|
|
|
116 - SCREW
BDE-330065-05.A127
330065-05
|
£1.50
|
£1.80
|
|
|
117 - LOCKING DEVICE
BDE-580291-00.A41
580291-00
|
£2.26
|
£2.71
|
|
|
118 - COVER GEARCASE
BDE-584433-01.A5
584433-01
|
£30.08
|
£36.10
|
|
|
119 - RING
BDE-577795-00.A42
577795-00
|
£1.50
|
£1.80
|
|
|
121 - SCREW
BDE-N066799-00.A6
N066799-00
|
£1.50
|
£1.80
|
|
|
130 - SPINDLE
BDE-N031254.A0
N031254
|
£25.05
|
£30.06
|
|
|
131 - SLEEVE SA
BDE-584431-00.A5
584431-00
|
£37.35
|
£44.82
|
|
|
132 - SPRING
BDE-871690.A100
871690
|
£1.66
|
£1.99
|
|
|
133 - WASHER
BDE-578387-00.A70
578387-00
|
£1.66
|
£1.99
|
|
|
134 - BALL 7MM
BDE-583890-00.A171
583890-00
|
£1.66
|
£1.99
|
|
|
135 - TUBE
BDE-N774198.A24
N774198
|
£12.17
|
£14.60
|
|
|
136 - CAP
BDE-323489-00.A70
323489-00
|
£1.66
|
£1.99
|
|
|
137 - RING
BDE-579212-00.A59
579212-00
|
£1.66
|
£1.99
|
|
|
138 - RING
BDE-579212-00.A60
579212-00
|
£1.66
|
£1.99
|
|
|
140 - HOLDER TOOL
BDE-N591846.A25
N591846
|
£60.94
|
£73.13
|
|
|
145 - SPINDLE
BDE-584676-00.A15
584676-00
|
£34.00
|
£40.80
|
|
|
146 - SPINDLE SA
BDE-584556-00.A7
584556-00
|
£55.30
|
£66.36
|
|
|
147 - CHUCK KEYLESS
BDE-582512-02.A32
582512-02
|
£24.39
|
£29.27
|
|
|
148 - SCREW
BDE-605256-02.A17
605256-02
|
£1.50
|
£1.80
|
|
|
150 - CHUCK & SPINDLE SA
BDE-N591847.A15
N591847
|
£51.90
|
£62.28
|
|
|
160 - HANDLE SIDE SA
BDE-1008956-00.A13
1008956-00
|
£24.39
|
£29.27
|
|
|
170 - DEPTH STOP
BDE-495699-00.A13
495699-00
|
£7.85
|
£9.42
|
|
|
800 - GREASE 90 GMS
BDE-870889-02.A31
870889-02
|
£7.85
|
£9.42
|
|
|
801 - GREASE 10 GMS
BDE-487130-04.A108
487130-04
|
£3.80
|
£4.56
|
|
|
817 - LABEL
BDE-496620-00.A11
496620-00
|
£1.50
|
£1.80
|
|
|
821 - RATING PLATE GB
BDE-N018749
N018749
|
-
|
|
|
|
821 - RATING PLATE LX
BDE-N018750
N018750
|
£3.70
|
£4.44
|
|
|
836 - S.T.TERMINAL EXTRACTOR
BDE-559638-99.A13
559638-99
|
£24.39
|
£29.27
|
|
|
846 - SERVICE KIT 115V LX
BDE-N031540.A2
N031540
|
£58.69
|
£70.43
|
|
|
846 - SERVICE KIT 230V GB
BDE-N031539.A1
N031539
|
£58.69
|
£70.43
|
|
|
861 - KITBOX
BDE-578005-04.A7
578005-04
|
£44.14
|
£52.97
|
|
