3 - GEAR CASING
MAF-203021.A1
203021
|
£99.98
|
£119.97
|
|
|
4 - BASE PLATE
MAF-203023.A1
203023
|
£164.71
|
£197.65
|
|
|
5 - GEAR CASING COVER
MAF-203025.A1
203025
|
£47.14
|
£56.57
|
|
|
6 - POSITIONING STOP
MAF-078400.A1
078400
|
£11.76
|
£14.11
|
|
|
7 - REVOLVING DEPTH CONTROL TURRET
MAF-076912.A2
076912
|
£15.52
|
£18.62
|
|
|
8 - COLUMN GUIDE, LEFT
MAF-078402.A0
078402
|
-
|
|
|
|
9 - COLUMN GUIDE, RIGHT
MAF-078401.A1
078401
|
-
|
|
|
|
10 - TILTING STOP
MAF-203041.A0
203041
|
£83.69
|
£100.43
|
|
|
11 - ADAPTER
MAF-203052.A1
203052
|
£63.44
|
£76.13
|
|
|
15 - BASE PLATE COVER
MAF-203027.A6
203027
|
£20.71
|
£24.85
|
|
|
16 - GUIDE STRIP
MAF-203028.A0
203028
|
£8.08
|
£9.69
|
|
|
17 - DEPTH STOP
MAF-203029.A7
203029
|
£9.32
|
£11.19
|
|
|
18 - INDICATOR
MAF-203030.A3
203030
|
-
|
|
|
|
19 - SLEEVE
MAF-078406.A0
078406
|
-
|
|
|
|
21 - LENS
MAF-203032.A1
203032
|
£16.11
|
£19.33
|
|
|
23 - MOTOR CASING
MAF-203042.A2
203042
|
-
|
|
|
|
24 - MOTOR COVER
MAF-203043.A4
203043
|
-
|
|
|
|
25 - SLIDING COVER
MAF-203044.A4
203044
|
-
|
|
|
|
26 - SWITCH BUTTON
MAF-203045.A6
203045
|
£7.21
|
£8.65
|
|
|
34 - PART NAME NOT AVAILABLE
MAF-203068.A9
203068
|
-
|
|
|
|
36 - PART NAME NOT AVAILABLE
MAF-203068.A8
203068
|
-
|
|
|
|
37 - PART NAME NOT AVAILABLE
MAF-203068.A7
203068
|
-
|
|
|
|
38 - STOP PIN (EACH)
MAF-203037.A5
203037
|
£7.55
|
£9.06
|
|
|
39 - GUIDE COLUMN, LONG
MAF-202434.A2
202434
|
£20.25
|
£24.30
|
|
|
40 - COLUMN
MAF-203031.A1
203031
|
-
|
|
|
|
41 - SPACER TUBE
MAF-078405.A0
078405
|
-
|
|
|
|
42 - HEXAGON-HEAD SCREW
MAF-056022.A2
056022
|
£7.25
|
£8.70
|
|
|
43 - GUARD BOW
MAF-203056.A0
203056
|
£5.82
|
£6.99
|
|
|
47 - SLIDING BEARING (EACH)
MAF-062089.A5
062089
|
£9.73
|
£11.68
|
|
|
48 - MAFELL DOWEL DRILL BIT
MAF-090097.A1
090097
|
£38.49
|
£46.19
|
|
|
49 - TOOTHED BELT
MAF-077003.A1
077003
|
£18.73
|
£22.48
|
|
|
52 - WING NUT
MAF-076959.A6
076959
|
£4.65
|
£5.58
|
|
|
53 - WING SCREW
MAF-071008.A2
071008
|
-
|
|
|
|
57 - PART NAME NOT AVAILABLE
MAF-203068.A3
203068
|
-
|
|
|
|
58 - PART NAME NOT AVAILABLE
MAF-203068.A2
203068
|
-
|
|
|
|
62 - PRESSURE SPRING
MAF-076911.A2
076911
|
-
|
|
|
|
63 - PRESSURE SPRING (EACH)
MAF-066143.A0
066143
|
£3.35
|
£4.02
|
|
|
64 - RETRACTING SPRING
MAF-006634.A5
006634
|
£3.46
|
£4.15
|
|
|
65 - LEG SPRING
MAF-066142.A6
066142
|
£5.92
|
£7.10
|
|
|
67 - MOTOR, CPL.
MAF-078132.A0
078132
|
-
|
|
|
|
67.5 - CARBON BRUSH
MAF-076949.A3
076949
|
£7.09
|
£8.51
|
|
|
70 - SNAP-ACTION SWITCH
MAF-087839.A1
087839
|
£12.98
|
£15.57
|
|
|
71 - ANTI-INTERFERENCE MODULE
MAF-078127.A2
078127
|
-
|
|
|
|
72 - CABLE PROTECTING SLEEVE
MAF-086064.A19
086064
|
£3.37
|
£4.04
|
|
|
73 - MAINS CABLE 4 M (13.1 FT)
MAF-077015.A4
077015
|
£31.90
|
£38.28
|
|
|
78 - HEXAGON-HEAD SCREW
MAF-056020.A4
056020
|
-
|
|
|
|
79 - HEXAGON-HEAD SCREW
MAF-056020.A6
056020
|
-
|
|
|
|
80 - HEXAGON-HEAD SCREW
MAF-056021.A2
056021
|
-
|
|
|
|
81 - OVAL-HEAD SCREW
MAF-053030.A1
053030
|
-
|
|
|
|
82 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A23
055233
|
£1.71
|
£2.05
|
|
|
83 - OVAL-HEAD SCREW
MAF-055226.A3
055226
|
£1.72
|
£2.06
|
|
|
84 - OVAL-HEAD SCREW
MAF-055068.A3
055068
|
-
|
|
|
|
85 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A15
055086
|
-
|
|
|
|
86 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055243.A1
055243
|
-
|
|
|
|
87 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A17
055061
|
£1.71
|
£2.05
|
|
|
88 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A2
055058
|
-
|
|
|
|
89 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A0
055091
|
-
|
|
|
|
90 - FLAT-HEAD SCREW
MAF-005399.A11
005399
|
£1.27
|
£1.52
|
|
|
91 - CHEESE-HEAD SCREW
MAF-203047.A0
203047
|
-
|
|
|
|
93 - THREADED PIN
MAF-052010.A2
052010
|
£3.38
|
£4.05
|
|
|
94 - SPRING DOWEL SLEEVE
MAF-058167.A0
058167
|
-
|
|
|
|
96 - SLIDING BAR
MAF-203066.A6
203066
|
-
|
|
|
|
97 - PART NAME NOT AVAILABLE
MAF-203068.A1
203068
|
-
|
|
|
|
98 - HEXAGONAL NUT
MAF-005900.A2
005900
|
-
|
|
|
|
101 - STEEL BALL
MAF-062077.A4
062077
|
-
|
|
|
|
102 - WASHER
MAF-006103.A1
006103
|
-
|
|
|
|
103 - WASHER
MAF-006100.A11
006100
|
£2.01
|
£2.41
|
|
|
104 - CLAMPING DISK
MAF-203071.A3
203071
|
£6.17
|
£7.40
|
|
|
105 - WASHER
MAF-061013.A4
061013
|
-
|
|
|
|
106 - SNAP RING
MAF-076918.A9
076918
|
£1.58
|
£1.89
|
|
|
107 - SEALING RING
MAF-065045.A1
065045
|
-
|
|
|
|
108 - CYLINDRICAL PIN
MAF-058156.A2
058156
|
£3.46
|
£4.15
|
|
|
109 - WASHER
MAF-061015.A21
061015
|
-
|
|
|
|
110 - SHIM RING
MAF-061178.A1
061178
|
£2.12
|
£2.54
|
|
|
501 - ALLEN KEY
MAF-093095.A7
093095
|
-
|
|
|
|
503 - CARRYING CASE MAFELL-MAX
MAF-095042.A6
095042
|
-
|
|
|
|
504 - PLASTIC TRAY
MAF-095055.A7
095055
|
-
|
|
|
|
508 - BOX
MAF-203348.A1
203348
|
-
|
|
|
|
511 - ALLEN KEY WITH HANDLE
MAF-093282.A6
093282
|
£9.72
|
£11.66
|
|
|
512 - BOTTLE FOR GLUE
MAF-095059.A7
095059
|
-
|
|
|
|
514 - ANTI-SLIP MATS
MAF-095063.A4
095063
|
-
|
|
|
|
515 - MAFELL SPECIAL DOWELS
MAF-802010.A7
802010
|
-
|
|
|
