1 - MOTOR CASING WITH INDUCTOR
MAF-084563.A0
084563
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088172.A3
088172
|
-
|
|
|
|
3 - GEAR CASING
MAF-203694.A0
203694
|
-
|
|
|
|
6 - BASE PLATE
MAF-203700.A0
203700
|
£205.92
|
£247.10
|
|
|
7 - GEAR CASING COVER
MAF-203025.A5
203025
|
£47.14
|
£56.57
|
|
|
9 - TRAVERSE
MAF-203440.A0
203440
|
£97.61
|
£117.13
|
|
|
10 - TILTING STOP
MAF-203442.A2
203442
|
£91.17
|
£109.40
|
|
|
14 - REVOLVING DEPTH CONTROL TURRET
MAF-203446.A0
203446
|
-
|
|
|
|
15 - BASE PLATE COVER
MAF-203027.A0
203027
|
£20.71
|
£24.85
|
|
|
16 - GUIDE STRIP
MAF-203028.A7
203028
|
£8.08
|
£9.69
|
|
|
17 - DEPTH STOP
MAF-203029.A3
203029
|
£9.32
|
£11.19
|
|
|
18 - INDICATOR
MAF-203030.A2
203030
|
-
|
|
|
|
21 - SIGHT WINDOW
MAF-203443.A3
203443
|
£14.77
|
£17.72
|
|
|
24 - MOTOR COVER
MAF-203695.A1
203695
|
-
|
|
|
|
25 - SLIDING COVER
MAF-203456.A0
203456
|
£3.14
|
£3.77
|
|
|
26 - SWITCH BUTTON
MAF-203045.A8
203045
|
£7.21
|
£8.65
|
|
|
27 - FAN
MAF-203182.A5
203182
|
£10.48
|
£12.57
|
|
|
28 - AIR CONDUCTING RING
MAF-203465.A1
203465
|
-
|
|
|
|
34 - DRIVING SHAFT
MAF-203693.A0
203693
|
£21.51
|
£25.81
|
|
|
36 - ROUE DENTÉE
MAF-203698.A0
203698
|
-
|
|
|
|
37 - IDLER GEAR
MAF-203459.A0
203459
|
-
|
|
|
|
38 - STOP PIN (EACH)
MAF-203037.A7
203037
|
£7.55
|
£9.06
|
|
|
39 - GUIDE COLUMN, LONG
MAF-202434.A1
202434
|
£20.25
|
£24.30
|
|
|
40 - COLUMN
MAF-203447.A1
203447
|
-
|
|
|
|
41 - COLUMN
MAF-203448.A0
203448
|
-
|
|
|
|
42 - SPACER TUBE
MAF-203444.A3
203444
|
-
|
|
|
|
43 - GUARD BOW
MAF-203056.A6
203056
|
£5.82
|
£6.99
|
|
|
44 - CLAMPING DISK
MAF-203071.A9
203071
|
£6.17
|
£7.40
|
|
|
45 - TENSIONING SCREW
MAF-203445.A1
203445
|
-
|
|
|
|
46 - SLEEVE
MAF-203451.A3
203451
|
-
|
|
|
|
47 - SLIDING BEARING (EACH)
MAF-062089.A7
062089
|
£9.73
|
£11.68
|
|
|
48 - MAFELL DOWEL DRILL BIT
MAF-090097.A3
090097
|
£38.49
|
£46.19
|
|
|
51 - SPACER SLEEVE
MAF-203469.A5
203469
|
-
|
|
|
|
52 - WING NUT
MAF-076959.A7
076959
|
£4.65
|
£5.58
|
|
|
53 - WING SCREW
MAF-071008.A0
071008
|
-
|
|
|
|
57 - GROOVED BALL BEARING
MAF-006234.A4
006234
|
£14.68
|
£17.62
|
|
|
58 - GROOVED BALL BEARING
MAF-062010.A13
062010
|
£14.52
|
£17.42
|
|
|
59 - GROOVED BALL BEARING
MAF-062082.A4
062082
|
£17.88
|
£21.45
|
|
|
62 - PRESSURE SPRING
MAF-076911.A1
076911
|
-
|
|
|
|
63 - PRESSURE SPRING (EACH)
MAF-066143.A7
066143
|
£3.35
|
£4.02
|
|
|
64 - RETRACTING SPRING
MAF-006634.A1
006634
|
£3.46
|
£4.15
|
|
|
65 - LEG SPRING
MAF-066142.A3
066142
|
£5.92
|
£7.10
|
|
|
66 - TORSION SPRING
MAF-076211.A1
076211
|
-
|
|
|
|
68 - CARBON BRUSH
MAF-063170.A0
063170
|
£12.81
|
£15.37
|
|
|
69 - BRUSH HOLDER
MAF-063128.A5
063128
|
£2.12
|
£2.55
|
|
|
70 - SNAP-ACTION SWITCH
MAF-087910.A2
087910
|
£14.32
|
£17.19
|
|
|
71 - ANTI-INTERFERENCE MODULE
MAF-203471.A2
203471
|
£24.84
|
£29.81
|
|
|
72 - CABLE PROTECTING SLEEVE
MAF-086064.A14
086064
|
£3.37
|
£4.04
|
|
|
73 - MAINS CABLE 4 M (13.1 FT)
MAF-077017.A6
077017
|
£31.90
|
£38.28
|
|
|
79 - HEXAGON-HEAD SCREW
MAF-056024.A2
056024
|
£5.22
|
£6.26
|
|
|
80 - CYLINDER-HEAD SCREW
MAF-055245.A4
055245
|
-
|
|
|
|
81 - THREADED PIN
MAF-005248.A4
005248
|
-
|
|
|
|
82 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A2
055233
|
£1.71
|
£2.05
|
|
|
83 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055137.A7
055137
|
-
|
|
|
|
84 - OVAL-HEAD SCREW
MAF-055068.A1
055068
|
-
|
|
|
|
85 - SELF-TAPPING SCREW
MAF-055230.A5
055230
|
-
|
|
|
|
86 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055243.A14
055243
|
-
|
|
|
|
87 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A11
055061
|
£1.71
|
£2.05
|
|
|
88 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A0
055058
|
-
|
|
|
|
89 - FLAT-HEAD SCREW
MAF-005390.A7
005390
|
-
|
|
|
|
90 - FLAT-HEAD SCREW
MAF-005399.A3
005399
|
£1.27
|
£1.52
|
|
|
91 - CYLINDER-HEAD SCREW
MAF-055029.A1
055029
|
-
|
|
|
|
92 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055111.A8
055111
|
-
|
|
|
|
93 - THREADED PIN
MAF-052010.A9
052010
|
£3.38
|
£4.05
|
|
|
95 - THREADED PIN
MAF-052012.A4
052012
|
-
|
|
|
|
96 - SLIDING BAR
MAF-203066.A7
203066
|
-
|
|
|
|
99 - HEXAGONAL NUT
MAF-005911.A14
005911
|
-
|
|
|
|
100 - LOCKING NUT
MAF-005999.A9
005999
|
-
|
|
|
|
101 - STEEL BALL
MAF-062077.A11
062077
|
-
|
|
|
|
104 - WASHER
MAF-006100.A15
006100
|
£2.01
|
£2.41
|
|
|
105 - WASHER
MAF-006101.A10
006101
|
£1.54
|
£1.85
|
|
|
106 - SNAP RING
MAF-076918.A2
076918
|
£1.58
|
£1.89
|
|
|
107 - RETAINING RING
MAF-007102.A14
007102
|
£2.59
|
£3.11
|
|
|
108 - CYLINDRICAL PIN
MAF-058156.A4
058156
|
£3.46
|
£4.15
|
|
|
109 - WASHER
MAF-061015.A4
061015
|
-
|
|
|
|
110 - RETAINING RING
MAF-061009.A1
061009
|
-
|
|
|
|
501 - ALLEN KEY
MAF-093095.A1
093095
|
-
|
|
|
|
503 - CARRYING CASE MAFELL-MAX
MAF-095042.A2
095042
|
-
|
|
|
|
504 - PLASTIC TRAY
MAF-095055.A1
095055
|
-
|
|
|
|
508 - PLASTIC TRAY FOR DOWELS
MAF-095056.A2
095056
|
-
|
|
|
|
511 - ALLEN KEY WITH HANDLE
MAF-093282.A2
093282
|
£9.72
|
£11.66
|
|
|
512 - BOTTLE FOR GLUE
MAF-095059.A3
095059
|
-
|
|
|
|
514 - ANTI-SLIP MATS
MAF-095063.A6
095063
|
-
|
|
|
|
515 - MAFELL SPECIAL DOWELS
MAF-802010.A2
802010
|
-
|
|
|
|
517 - AUXILIARY STOP
MAF-203473.A4
203473
|
£13.97
|
£16.76
|
|
|
550 - MAFELL DOWEL DRILL BIT
MAF-090096.A1
090096
|
£31.16
|
£37.39
|
|
|
551 - MAFELL DOWEL DRILL BIT
MAF-090098.A5
090098
|
£46.74
|
£56.09
|
|
|
553 - MAFELL SPECIAL DOWELS
MAF-802000.A1
802000
|
-
|
|
|
|
554 - MAFELL SPECIAL DOWELS
MAF-802020.A0
802020
|
-
|
|
|
|
555 - DOWEL NOZZLE Ø 8
MAF-095060.A3
095060
|
-
|
|
|
