Stanley STHR272KS Type 1 Hammer Drill Spare Parts

Home Details Reviews Delivery

An exploded drawing and spare parts listing for the Stanley STHR272KS Type 1 Hammer Drill

	Ex VAT	Inc VAT
1 - BALL BDE-4030304015.A0 4030304015	£1.50	£1.80
2 - PIN BDE-49208014.A0 49208014	£1.50	£1.80
3 - SHAFT BDE-4031104009.A0 4031104009	£14.57	£17.48
4 - SPRING BDE-4031108001.A0 4031108001	£1.50	£1.80
5 - RAM BDE-4031104002.A1 4031104002	£1.82	£2.19
6 - O RING BDE-4030303003.A3 4030303003	£1.50	£1.80
7 - GEAR BDE-4031110001.A1 4031110001	£9.41	£11.29
8 - CIRCLIP BDE-4031104008.A2 4031104008	£1.50	£1.80
9 - O RING BDE-4030303004.A0 4030303004	£1.50	£1.80
10 - PIN BDE-4030304017.A0 4030304017	£1.50	£1.80
11 - PLUNGER BDE-4030302006.A3 4030302006	£2.26	£2.71
12 - CON ROD SA BDE-4030302007.A0 4030302007	£2.78	£3.34
13 - O RING BDE-4030303009.A0 4030303009	£1.50	£1.80
16 - WASHER BDE-4031103003.A1 4031103003	£1.50	£1.80
18 - BUTTON BDE-4031601605.A0 4031601605	£2.78	£3.34
19 - SCREW BDE-49203601.A0 49203601	£1.50	£1.80
20 - CAP BDE-4031601607.A2 4031601607	£1.50	£1.80
21 - O RING BDE-4030303008.A3 4030303008	£1.50	£1.80
23 - NUT BDE-49201601.A2 49201601	£1.50	£1.80
24 - CYLINDER HEAD BDE-4031602005.A3 4031602005	£9.41	£11.29
25 - COLLAR BDE-4030303019.A1 4030303019	£1.50	£1.80
26 - WASHER BDE-4030304007.A0 4030304007	£1.50	£1.80
27 - BEARING BDE-49113003.A2 49113003	£3.30	£3.96
28 - RUBBER SEAL BDE-4030303018.A2 4030303018	£1.50	£1.80
29 - BEAT PIECE BDE-4030301009.A2 4030301009	£1.50	£1.80
30 - STOP BDE-4030304019.A0 4030304019	£2.78	£3.34
31 - RETAINER BDE-4030304027.A2 4030304027	£1.50	£1.80
32 - O RING BDE-4030303002.A0 4030303002	£1.50	£1.80
33 - SLEEVE & BRACKET BDE-4030301601.A2 4030301601	£3.30	£3.96
34 - RETAINER BDE-4030104006.A1 4030104006	£1.50	£1.80
35 - CYLINDER BDE-4031604604.A0 4031604604	£12.17	£14.60
36 - O RING BDE-4030303005.A3 4030303005	£1.50	£1.80
37 - O RING BDE-4030303001.A3 4030303001	£1.50	£1.80
38 - IMPACTOR BDE-4031104016.A2 4031104016	£2.78	£3.34
39 - BALL STEEL BDE-4030304014.A7 4030304014	£1.50	£1.80
40 - SPRING BDE-4031608601.A1 4031608601	£1.50	£1.80
41 - PINION BDE-4031610601.A0 4031610601	£7.18	£8.62
42 - LOCKING RING BDE-4030304016.A3 4030304016	£1.50	£1.80
43 - BEARING BDE-49112002.A2 49112002	£2.26	£2.71
44 - WASHER BDE-4030304006.A3 4030304006	£1.50	£1.80
45 - WASHER LOCK BDE-4030304023.A3 4030304023	£1.50	£1.80
46 - COLLAR BDE-4030304018.A3 4030304018	£1.50	£1.80
47 - GEAR BDE-4030310001.A2 4030310001	£12.17	£14.60
48 - WASHER SPECIAL BDE-4031604601.A3 4031604601	£1.50	£1.80
49 - CIRCLIP BDE-4031604602.A0 4031604602	£1.50	£1.80
50 - BEARING BDE-49112005.A2 49112005	£1.50	£1.80
51 - CRANKSHAFT BDE-4030304020.A3 4030304020	£4.69	£5.63
52 - KEY BDE-49208015.A3 49208015	£1.50	£1.80
53 - BEARING BDE-49112004.A1 49112004	£2.78	£3.34
54 - WASHER BDE-4030304003.A2 4030304003	£1.50	£1.80
55 - BEARING PLATE BDE-4030304024.A0 4030304024	£1.50	£1.80
56 - SCREW M5X16 BDE-49201033.A3 49201033	£1.50	£1.80
57 - GEAR BDE-4030310004.A3 4030310004	£10.85	£13.02
58 - CIRCLIP BDE-49207027.A11 49207027	£1.50	£1.80
59 - BEARING BDE-49113001.A1 49113001	£1.50	£1.80
60 - BEARING NEEDLE BDE-49101011.A0 49101011	£1.50	£1.80
61 - COVER & SEAL BDE-4030303015.A1 4030303015	£1.50	£1.80
62 - COVER BDE-4031602006.A0 4031602006	£7.18	£8.62
63 - O RING BDE-4030303006.A0 4030303006	£1.50	£1.80
64 - BEARING BDE-49111003.A1 49111003	£2.78	£3.34
65 - RETAINER BDE-4090104001.A0 4090104001	£1.50	£1.80
67 - BAFFLE FAN BDE-4031601604.A1 4031601604	£1.50	£1.80
68 - SCREW BDE-49206039.A7 49206039	£1.50	£1.80
70 - WASHER BDE-4090104003.A17 4090104003	£1.50	£1.80
71 - BEARING BDE-49111013.A20 49111013	£1.50	£1.80
72 - HOUSING MOTOR BDE-4031601606.A1 4031601606	£10.85	£13.02
73 - NUT BDE-49201603.A3 49201603	£1.50	£1.80
74 - BRUSH HOLDER SA BDE-4031607001.A1 4031607001	£3.30	£3.96
75 - BRUSH PAIR BDE-4031606001.A1 4031606001	£1.82	£2.19
80 - DEPTH ROD BDE-4030304021.A2 4030304021	£1.50	£1.80
83 - HANDLE SWITCH BDE-4031601608.A2 4031601608	£7.85	£9.42
86 - SWITCH BDE-4030305003.A0 4030305003	£5.88	£7.06
87 - SCREW BDE-49203602.A2 49203602	£1.50	£1.80
88 - SCREW BDE-49206605.A1 49206605	£1.50	£1.80
90 - CORD CLAMP BDE-4240201013.A4 4240201013	£1.50	£1.80
91 - SCREW BDE-49206606.A2 49206606	£1.50	£1.80
94 - SCREW BDE-49206607.A1 49206607	£1.50	£1.80
96 - OILER BDE-4030301013.A5 4030301013	£1.50	£1.80
98 - CIRCLIP BDE-4031104007.A3 4031104007	£1.50	£1.80
99 - END CAP BDE-4031601602.A0 4031601602	£2.78	£3.34
101 - WASHER BDE-4031604603.A2 4031604603	£1.50	£1.80
300 - GEARCASE SA BDE-4031650004.A0 4031650004	£24.39	£29.27
301 - CLUTCH SA BDE-4031650002.A2 4031650002	£24.39	£29.27
302 - ARMATURE SA BDE-4031650003.A0 4031650003	£37.35	£44.82
500 - HANDLE SIDE SA BDE-4030331001.A3 4030331001	£4.69	£5.63
800 - GREASE 0.08Kg needed BDE-901186.A15 901186	£44.14	£52.97
