1 - MOTOR HOUSING
BSD-3605108224.A11
3605108224
|
£10.10
|
£12.12
|
|
|
3/13 - BALL BEARING 7x19x6
BSD-2600905032.A1804
2600905032
|
£5.30
|
£6.36
|
|
|
4 - SWITCH
BSD-1607200199.A31
1607200199
|
£16.41
|
£19.69
|
|
|
6 - GROMMET
BSD-1600703040.A0
1600703040
|
£2.16
|
£2.59
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A228
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601110538.A3
3601110538
|
£4.26
|
£5.11
|
|
|
16 - BRUSH HOLDER
BSD-1601323025.A10
1601323025
|
£3.72
|
£4.47
|
|
|
16/17 - SPIRAL SPRING
BSD-1604652013.A443
1604652013
|
£1.75
|
£2.10
|
|
|
18 - SWITCH HANDLE
BSD-1602026088.A7
1602026088
|
£1.75
|
£2.10
|
|
|
19 - COMPRESSION SPRING
BSD-1604611026.A137
1604611026
|
£1.75
|
£2.10
|
|
|
20 - ADJUSTING SLIDE
BSD-1602319010.A10
1602319010
|
£1.75
|
£2.10
|
|
|
24 - COVER
BSD-1605500227.A18
1605500227
|
£2.16
|
£2.59
|
|
|
25 - HOUSING COVER
BSD-1605500251.A61
1605500251
|
£7.36
|
£8.83
|
|
|
26 - RUBBER RING
BSD-1600206036.A378
1600206036
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A303
1600591025
|
£2.61
|
£3.13
|
|
|
47 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A24
2603490021
|
£1.75
|
£2.10
|
|
|
48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A524
1613435034
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A61
2603490023
|
£1.75
|
£2.10
|
|
|
51 - SPEED GOVERNOR
BSD-1607233495.A0
1607233495
|
£48.38
|
£58.06
|
|
|
53 - LENS HEAD SCREW 4x32
BSD-2603490026.A226
2603490026
|
£1.75
|
£2.10
|
|
|
62 - RETAINING CLIP
BSD-1600119011.A14
1600119011
|
£2.16
|
£2.59
|
|
|
63 - RUBBER RING
BSD-1600206025.A208
1600206025
|
£2.16
|
£2.59
|
|
|
64 - O-RING 26.0x2.0 MM
BSD-1610210101.A42
1610210101
|
£2.80
|
£3.36
|
|
|
66 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A480
1600290016
|
£2.61
|
£3.13
|
|
|
68 - O-RING 33.0x2.0 MM
BSD-2600210019.A3
2600210019
|
£1.75
|
£2.10
|
|
|
72 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A128
1600905032
|
£5.58
|
£6.70
|
|
|
74 - GROOVE BALL BEARING 10x26x8
BSD-3600905156.A3
3600905156
|
£12.04
|
£14.45
|
|
|
75 - GROOVE BALL BEARING
BSD-3600905157.A11
3600905157
|
£12.04
|
£14.45
|
|
|
76 - PROTECTIVE SLEEVE
BSD-3605500194.A7
3605500194
|
£12.04
|
£14.45
|
|
|
81 - SLEEVE
BSD-3600400035.A0
3600400035
|
£5.30
|
£6.36
|
|
|
82 - SEALING DISK
BSD-3600103020.A2
3600103020
|
£5.30
|
£6.36
|
|
|
90 - CLAMPING UNIT dia6 MM
BSD-3607030474.A1
3607030474
|
£21.68
|
£26.01
|
|
|
93 - CYLINDRICAL GEAR
BSD-3606312004.A0
3606312004
|
£16.41
|
£19.69
|
|
|
94 - HEX NUT M7. SW10
BSD-1603300016.A702
1603300016
|
£1.75
|
£2.10
|
|
|
95 - FLANGE
BSD-3600328043.A1
3600328043
|
£23.86
|
£28.63
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A159
1601008005
|
£4.26
|
£5.11
|
|
|
107 - INSULATING PART
BSD-1600712030.A5
1600712030
|
£1.75
|
£2.10
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW19
BSD-3607950024.A7
3607950024
|
£8.67
|
£10.41
|
|
|
654 - SINGLE-HEAD ENG. WRENCH SW13
BSD-3607950025.A7
3607950025
|
£7.36
|
£8.83
|
|
|
802 - FIELD 230V
BSD-3607031669.A0
3607031669
|
£48.38
|
£58.06
|
|
|
803 - ARMATURE ASSEMBLY 230V
BSD-3607031670.A2
3607031670
|
£81.81
|
£98.17
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000392.A12
1607000392
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2908
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A136
1607014176
|
£13.12
|
£15.75
|
|
|
810 - CARBON-BRUSH SET 10 x 1 607 014 176
BSD-1607000482.A3
1607000482
|
£93.88
|
£112.65
|
|
|
815 - PARTS SET
BSD-1607000378.A74
1607000378
|
£6.52
|
£7.83
|
|
|
818 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A145
2910110048
|
£1.75
|
£2.10
|
|
|
835 - FAN
BSD-1606610132.A254
1606610132
|
£2.16
|
£2.59
|
|
|
860 - CONNECTING CABLE
BSD-1604448023.A44
1604448023
|
£1.75
|
£2.10
|
|
|
861 - SPINDLE HOUSING
BSD-3607031673.A0
3607031673
|
£68.42
|
£82.10
|
|
|
870 - INTERMEDIATE FLANGE
BSD-3607031672.A3
3607031672
|
£45.67
|
£54.80
|
|
|
880 - GRINDING SPINDLE
BSD-3607031671.A1
3607031671
|
£102.57
|
£123.08
|
|
|
890 - ROUND NUT
BSD-3603313006.A19
3603313006
|
£10.10
|
£12.12
|
|
