1 - MOTOR HOUSING
BSD-3605108092.A12
3605108092
|
£27.23
|
£32.68
|
|
|
3 - ARMATURE
BSD-1619P13611.A1
1619P13611
|
£40.80
|
£48.96
|
|
|
3/5 - FAN
BSD-1606610122.A164
1606610122
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia 10.5-dia11.0x100 MM
BSD-1600703023.A57
1600703023
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A627
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601110600.A1
3601110600
|
£2.61
|
£3.13
|
|
|
15 - CLAMPING FLANGE dia 65x16 MM
BSD-1605703065.A8
1605703065
|
-
|
|
|
|
16 - THREADED RING
BSD-1603344005.A75
1603344005
|
£27.23
|
£32.68
|
|
|
17 - GROOVE BALL BEARING 17x47x14
BSD-1900900352.A57
1900900352
|
£27.23
|
£32.68
|
|
|
18 - SPINDLE BEARING
BSD-3605806084.A9
3605806084
|
£156.22
|
£187.46
|
|
|
19 - GRINDING SPINDLE M14
BSD-3603160000.A7
3603160000
|
£68.42
|
£82.10
|
|
|
21 - RUBBER RING dia41xdia37x7.5 MM
BSD-1600206029.A26
1600206029
|
£2.61
|
£3.13
|
|
|
22 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A474
1600290016
|
£2.61
|
£3.13
|
|
|
23 - O-RING 57.0x1.5 MM
BSD-1600210031.A0
1600210031
|
£1.75
|
£2.10
|
|
|
24 - INTERMEDIATE RING
BSD-1600221003.A161
1600221003
|
£2.61
|
£3.13
|
|
|
27 - OVAL-HEAD SCREW 4x18 MM.TORX T20
BSD-2914201506.A86
2914201506
|
£1.75
|
£2.10
|
|
|
27/1 - SCREW 4x16
BSD-2603490022.A3130
2603490022
|
£1.75
|
£2.10
|
|
|
28 - FAST LOCKING FLANGE
BSD-3603301010.A1
3603301010
|
£135.25
|
£162.30
|
|
|
31 - INTERMEDIATE RING
BSD-1600502011.A570
1600502011
|
£2.61
|
£3.13
|
|
|
33 - RETAINING RING 16 DIN 9045
BSD-2916600009.A17
2916600009
|
£1.75
|
£2.10
|
|
|
35 - HANDLE
BSD-3605132079.A2
3605132079
|
£45.67
|
£54.80
|
|
|
36 - CYLINDRICAL GEAR Z=25
BSD-3606320015.A9
3606320015
|
£63.50
|
£76.20
|
|
|
37 - INTERMEDIATE RING
BSD-1600300090.A66
1600300090
|
£3.72
|
£4.47
|
|
|
38 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A74
3600905131
|
£11.30
|
£13.56
|
|
|
40 - WOODRUFF KEY DIN 6888-4x5-ST60-2
BSD-1900023006.A39
1900023006
|
£2.61
|
£3.13
|
|
|
41 - TORX OVAL-HEAD SCREW
BSD-3603435057.A12
3603435057
|
£1.75
|
£2.10
|
|
|
43 - COMPRESSION SPRING
BSD-1604613006.A46
1604613006
|
£1.75
|
£2.10
|
|
|
44 - GROOVE BALL BEARING
BSD-1600905017.A3
1600905017
|
£5.01
|
£6.01
|
|
|
46 - SCREW 4x16
BSD-2603490022.A3131
2603490022
|
£1.75
|
£2.10
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A518
2910021118
|
£1.75
|
£2.10
|
|
|
48 - SPIRAL SPRING
BSD-1604652006.A304
1604652006
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW
BSD-2914201529.A52
2914201529
|
£1.75
|
£2.10
|
|
|
51 - ELECTRONICS MODULE
BSD-1607233319.A77
1607233319
|
£40.80
|
£48.96
|
|
|
52 - OVAL-HEAD SCREW 4x18 MM.TORX T20
BSD-2914201506.A85
2914201506
|
£1.75
|
£2.10
|
|
|
53 - INTERMEDIATE BEARING
BSD-3605820045.A1
3605820045
|
£81.81
|
£98.17
|
|
|
54 - WIRE GUIDE
BSD-3601025003.A74
3601025003
|
£1.75
|
£2.10
|
|
|
55 - AIR-DEFLECTOR RING
BSD-1600502019.A25
1600502019
|
£3.72
|
£4.47
|
|
|
63 - PAN HEAD SCREW M4x10 MM
BSD-1603410014.A173
1603410014
|
£1.75
|
£2.10
|
|
|
68 - SEALING PLATE
BSD-1601006011.A481
1601006011
|
£2.61
|
£3.13
|
|
|
90 - TAB WASHER
BSD-1601030022.A502
1601030022
|
£1.75
|
£2.10
|
|
|
150 - SHRINKABLE TUBE
BSD-3600707022.A116
3600707022
|
£3.72
|
£4.47
|
|
|
152 - BLADE TERMINAL
BSD-1604477001.A91
1604477001
|
£1.75
|
£2.10
|
|
|
153 - CONNECTING CABLE
BSD-3604438034.A1
3604438034
|
£7.36
|
£8.83
|
|
|
650/1 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A565
1607950061
|
£5.42
|
£6.50
|
|
|
650/2 - HOLDING PIN
BSD-3603101005.A1
3603101005
|
£5.30
|
£6.36
|
|
|
650/3 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A192
1907950007
|
£5.30
|
£6.36
|
|
|
650/4 - ROUND NUT
BSD-3603345014.A1
3603345014
|
£54.42
|
£65.30
|
|
|
653 - PROTECTIVE COVER dia 125 MM
BSD-3605510030.A32
3605510030
|
£27.23
|
£32.68
|
|
|
653/5 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A138
2910141244
|
£1.75
|
£2.10
|
|
|
802 - FIELD
BSD-3607031864.A0
3607031864
|
£93.88
|
£112.65
|
|
|
804 - ON-OFF SWITCH
BSD-1607000C14.A64
1607000C14
|
£30.28
|
£36.33
|
|
|
805 - POWER SUPPLY CORD
BSD-1607000391.A108
1607000391
|
£18.96
|
£22.75
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2891
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014012.A93
3607014012
|
£23.86
|
£28.63
|
|
|
820 - CARTRIDGE BEARING
BSD-3604441011.A1
3604441011
|
£31.64
|
£37.97
|
|
|
826 - SEALING CAP
BSD-3605500063.A182
3605500063
|
£4.26
|
£5.11
|
|
|
839 - BRUSH HOLDER
BSD-3604336012.A136
3604336012
|
£5.58
|
£6.70
|
|
