1 - HOUSING COVER
BSD-3600508023.A35
3600508023
|
£13.41
|
£16.09
|
|
|
2 - COUNTERSUNK-HEAD SCREW DIN 63-AM3.5x8-5.8
BSD-2910501084.A26
2910501084
|
-
|
|
|
|
3 - GROMMET dia7 MM
BSD-2600703007.A46
2600703007
|
-
|
|
|
|
3 - GROMMET dia8.2 MM
BSD-2600703008.A113
2600703008
|
£1.75
|
£2.10
|
|
|
3 - GROMMET dia9.5 MM
BSD-2600703006.A251
2600703006
|
-
|
|
|
|
4 - HEX SCREW
BSD-2603527004.A35
2603527004
|
£1.75
|
£2.10
|
|
|
5 - FASTENING CLAMP
BSD-2601301002.A6
2601301002
|
£2.16
|
£2.59
|
|
|
6 - SUPPRESSION FILTER
BSD-2607329048.A4
2607329048
|
-
|
|
|
|
7 - CARBON-BRUSH SET
BSD-2604320905.A48
2604320905
|
-
|
|
|
|
8 - SPIRAL SPRING
BSD-2604652000.A4
2604652000
|
-
|
|
|
|
9 - CLAMPING SADDLE
BSD-2601321005.A8
2601321005
|
-
|
|
|
|
10 - SOCKET HEAD CAP SCREW
BSD-2603410010.A2
2603410010
|
-
|
|
|
|
12 - SOCKET HEAD CAP SCREW M 2.6x5 DIN 84
BSD-2910011028.A1
2910011028
|
-
|
|
|
|
13 - CLAMPING PIECE
BSD-2602305034.A46
2602305034
|
-
|
|
|
|
14 - CONNECTING TERMINAL
BSD-2604490003.A102
2604490003
|
-
|
|
|
|
15 - HEX NUT M 2.6 DIN 934-M-6
BSD-2915011002.A73
2915011002
|
-
|
|
|
|
16 - MOTOR HOUSING
BSD-2605108032.A34
2605108032
|
-
|
|
|
|
17 - INSULATING PART
BSD-2601322002.A5
2601322002
|
£1.75
|
£2.10
|
|
|
18 - CABLE
BSD-2604411061.A72
2604411061
|
-
|
|
|
|
19 - SWITCH
BSD-2607200045.A72
2607200045
|
-
|
|
|
|
20 - COUNTERSUNK-HEAD SCREW M 3x6 DIN 63-5.8
BSD-2910501048.A52
2910501048
|
-
|
|
|
|
21 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A99
2601007003
|
-
|
|
|
|
22 - HEX NUT M 2.6 DIN 934-M-6
BSD-2915011002.A74
2915011002
|
-
|
|
|
|
23 - CABLE CLIP
BSD-2601035005.A93
2601035005
|
£1.75
|
£2.10
|
|
|
24 - SOCKET HEAD CAP SCREW DIN 84-AM2.6x15-5.8
BSD-2910011033.A48
2910011033
|
-
|
|
|
|
25 - HEX NUT DIN 439-BM 3
BSD-2915051103.A94
2915051103
|
£1.75
|
£2.10
|
|
|
26 - SPRING LOCK WASHER A3-FSt
BSD-2916690001.A71
2916690001
|
-
|
|
|
|
27 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A553
2916011005
|
£1.75
|
£2.10
|
|
|
28 - HEX NUT DIN 934-M 3-m-8
BSD-2915011003.A40
2915011003
|
£1.75
|
£2.10
|
|
|
29 - NAMEPLATE
BSD-2601100038.A29
2601100038
|
-
|
|
|
|
29 - NAMEPLATE
BSD-160111A3H3.A1122
160111A3H3
|
£2.61
|
£3.13
|
|
|
30 - ROUND-HEAD GROOVED PIN 2x3 DIN 1476 ST
BSD-2917724031.A75
2917724031
|
-
|
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-BM3x50-5.8
BSD-2910011074.A48
2910011074
|
£1.75
|
£2.10
|
|
|
32 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A554
2916011005
|
£1.75
|
£2.10
|
|
|
33 - CABLE CLIP
BSD-2601099015.A48
2601099015
|
£1.75
|
£2.10
|
|
|
34 - FIELD 220-230V
BSD-2604220269.A11
2604220269
|
-
|
|
|
|
34 - POLE SHOE 220V
BSD-2604220241.A10
2604220241
|
-
|
|
|
|
35 - SEAL RING
BSD-2600113019.A58
2600113019
|
£2.80
|
£3.36
|
|
|
36 - SHIM
BSD-2600100699.A36
2600100699
|
£1.75
|
£2.10
|
|
|
37 - SHIM
BSD-2600150002.A28
2600150002
|
-
|
|
|
|
38 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A204
1900905015
|
£30.42
|
£36.51
|
|
|
39 - SHIM 0.3 MM
BSD-2600100612.A15
2600100612
|
£2.61
|
£3.13
|
|
|
40 - ARMATURE WITH FAN 220V
BSD-2604010333.A8
2604010333
|
-
|
|
|
|
41 - FAN
BSD-2606610037.A14
2606610037
|
-
|
|
|
|
42 - GROOVE BALL BEARING 609-ZY DIN 625
BSD-1900905007.A48
1900905007
|
-
|
|
|
|
43 - BEARING SLEEVE
BSD-2600300044.A2
2600300044
|
-
|
|
|
|
44 - INTERMEDIATE FLANGE
BSD-2605820017.A5
2605820017
|
-
|
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A300
2910021125
|
£1.75
|
£2.10
|
|
|
46 - SUSPENSION LOOP
BSD-1604682003.A29
1604682003
|
-
|
|
|
|
54 - BUSHING
BSD-3600328036.A12
3600328036
|
-
|
|
|
|
55 - SHIM 0.5 MM
BSD-2600100505.A48
2600100505
|
£1.32
|
£1.58
|
|
|
56 - CYLINDRICAL GEAR Z=41
BSD-2606325004.A13
2606325004
|
-
|
|
|
|
57 - BUSHING
BSD-2600300058.A76
2600300058
|
-
|
|
|
|
58 - SHIM 0.50 MM
BSD-2600100613.A175
2600100613
|
£1.75
|
£2.10
|
|
|
59 - SPINDLE WITH GEAR Z=13/35
BSD-2606328900.A4
2606328900
|
-
|
|
|
|
60 - SPINDLE WITH GEAR Z=9/11
BSD-2606328901.A16
2606328901
|
-
|
|
|
|
61 - SPACER BUSHING
BSD-2600400023.A15
2600400023
|
-
|
|
|
|
62 - DRIVE SHAFT
BSD-2603124066.A17
2603124066
|
-
|
|
|
|
63 - CYLINDRICAL GEAR Z=42
BSD-2606325003.A6
2606325003
|
-
|
|
|
|
64 - RETAINING RING
BSD-1600224025.A51
1600224025
|
£2.61
|
£3.13
|
|
|
65 - PLAIN WASHER
BSD-2600101513.A51
2600101513
|
£1.75
|
£2.10
|
|
|
66 - COMPRESSION SPRING
BSD-2604630000.A15
2604630000
|
-
|
|
|
|
67 - O-RING 12x2 MM
BSD-1900210009.A2
1900210009
|
-
|
|
|
|
68 - GEAR HOUSING
BSD-2605806097.A4
2605806097
|
-
|
|
|
|
68/1 - BUSHING
BSD-2600322043.A2
2600322043
|
-
|
|
|
|
69 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A19
2916690003
|
£1.75
|
£2.10
|
|
|
70 - SOCKET HEAD CAP SCREW DIN 84-BM4x45-5.8
BSD-2910011140.A20
2910011140
|
-
|
|
|
|
71 - SOCKET HEAD CAP SCREW DIN 84-BM4x45-8.8
BSD-2910021142.A20
2910021142
|
-
|
|
|
|
72 - GRIPPING WEDGE dia 5x18 MM/3.6 MM
BSD-1603110000.A11
1603110000
|
-
|
|
|
|
73 - TWO-JAW DRILL JUCK M4-M12
BSD-1608573002.A13
1608573002
|
-
|
|
|
|
73 - HEXAGON SOCKET WRENCH
BSD-1607950002.A2
1607950002
|
-
|
|
|
|
74 - STUD BOLT
BSD-1603502000.A20
1603502000
|
£21.52
|
£25.83
|
|
|
75 - CLAMPING JAWS M 12x1.5
BSD-1600390002.A30
1600390002
|
-
|
|
|
|
75 - CLAMPING JAWS M 12x1.5
BSD-1600390003.A3
1600390003
|
-
|
|
|
|
75 - CLAMPING JAWS M 12x1.5
BSD-1600390004.A18
1600390004
|
-
|
|
|
|
75 - CLAMPING JAWS M 12x1.5
BSD-1600390005.A3
1600390005
|
-
|
|
|
|
100 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A22
1607000227
|
£23.86
|
£28.63
|
|
