1 - GEAR HOUSING
BSD-2605806280.A5
2605806280
|
-
|
|
|
2 - INTERMEDIATE FLANGE
BSD-2605700168.A3
2605700168
|
-
|
|
|
7 - SHIM 0.50 MM
BSD-2600100613.A164
2600100613
|
£1.75
|
£2.10
|
|
8 - DRIVE SHAFT
BSD-2603124066.A26
2603124066
|
-
|
|
|
9 - SHIM 0.5 MM
BSD-2600100505.A61
2600100505
|
£1.32
|
£1.58
|
|
10 - CYLINDRICAL GEAR Z=41
BSD-2606325004.A5
2606325004
|
-
|
|
|
11 - SPACER BUSHING
BSD-2600400023.A1
2600400023
|
-
|
|
|
12 - CYLINDRICAL GEAR Z=42
BSD-2606325003.A13
2606325003
|
-
|
|
|
13 - BUSHING
BSD-2600322043.A6
2600322043
|
-
|
|
|
14 - RETAINING RING
BSD-1600224025.A63
1600224025
|
£2.61
|
£3.13
|
|
15 - COMPRESSION SPRING
BSD-2604630000.A6
2604630000
|
-
|
|
|
16 - PLAIN WASHER
BSD-2600101513.A62
2600101513
|
£1.75
|
£2.10
|
|
17 - O-RING 12x2 MM
BSD-1900210009.A11
1900210009
|
-
|
|
|
18 - FELT DISC
BSD-2600108020.A195
2600108020
|
-
|
|
|
19 - CUPPED WASHER
BSD-2600500008.A191
2600500008
|
-
|
|
|
20 - RECEPTACLE
BSD-2600400020.A127
2600400020
|
-
|
|
|
21 - ARMATURE PLATE
BSD-2600121002.A36
2600121002
|
-
|
|
|
22 - FAN
BSD-2606610040.A7
2606610040
|
-
|
|
|
23 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A204
2600905007
|
-
|
|
|
24 - ARMATURE 110-115V
BSD-2604010393.A1
2604010393
|
-
|
|
|
25 - BALL BEARING 7x22x7
BSD-1900905018.A824
1900905018
|
£18.96
|
£22.75
|
|
26 - SHIM
BSD-2600150004.A88
2600150004
|
£2.16
|
£2.59
|
|
28 - SHIM 0.5 MM
BSD-2600101020.A117
2600101020
|
£1.75
|
£2.10
|
|
28 - SHIM 0.2 MM
BSD-2600101022.A533
2600101022
|
£1.75
|
£2.10
|
|
28 - SHIM 0.3 MM
BSD-2600101023.A117
2600101023
|
£1.75
|
£2.10
|
|
29 - MOTOR HOUSING
BSD-2605104903.A80
2605104903
|
-
|
|
|
30 - POLE SHOE 110-115V
BSD-2604222239.A1
2604222239
|
-
|
|
|
33 - COVER DISC
BSD-2601328021.A35
2601328021
|
-
|
|
|
34 - COMPRESSION SPRING
BSD-2604611026.A255
2604611026
|
-
|
|
|
37 - CARBON-BRUSH SET
BSD-2604320906.A81
2604320906
|
-
|
|
|
38 - SPIRAL SPRING
BSD-2604652002.A172
2604652002
|
-
|
|
|
39 - SOCKET HEAD CAP SCREW
BSD-2603410010.A7
2603410010
|
-
|
|
|
41 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A377
2910211004
|
-
|
|
|
45 - PAN HEAD SCREW
BSD-2603410025.A34
2603410025
|
-
|
|
|
46 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A15
2916690003
|
£1.75
|
£2.10
|
|
47 - ON-OFF SWITCH
BSD-2607200043.A174
2607200043
|
-
|
|
|
48 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A452
2603410023
|
-
|
|
|
49 - SUPPRESSION FILTER
BSD-2607329051.A264
2607329051
|
-
|
|
|
53 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A187
2600703011
|
£2.80
|
£3.36
|
|
53 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1324
2600703012
|
£2.80
|
£3.36
|
|
53 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A144
2600703013
|
£2.61
|
£3.13
|
|
54 - CABLE CLIP
BSD-2601035001.A309
2601035001
|
£1.75
|
£2.10
|
|
55 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A671
2910211021
|
£1.75
|
£2.10
|
|
56 - HOUSING COVER
BSD-2605132007.A46
2605132007
|
-
|
|
|
57 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1647
2910211019
|
£1.75
|
£2.10
|
|
58 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A102
2601007003
|
-
|
|
|
58 - NAMEPLATE
BSD-160111A3H3.A1104
160111A3H3
|
£2.61
|
£3.13
|
|
60 - ROUND-HEAD GROOVED PIN 2x3 DIN 1476 ST
BSD-2917724031.A80
2917724031
|
-
|
|
|
61 - SUSPENSION LOOP
BSD-2604682007.A1
2604682007
|
-
|
|
|
65 - BUSHING
BSD-2600300058.A73
2600300058
|
-
|
|
|
66 - BUSHING
BSD-3600328036.A15
3600328036
|
-
|
|
|
67 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A297
1903201042
|
£2.16
|
£2.59
|
|
800 - SPINDLE WITH GEAR Z=13/35
BSD-2606328900.A14
2606328900
|
-
|
|
|
801 - SPINDLE WITH GEAR Z=9/11
BSD-2606328901.A6
2606328901
|
-
|
|
|
802 - TWO-JAW DRILL JUCK M4-M12
BSD-1608573002.A1
1608573002
|
-
|
|
|
803 - GRIPPING WEDGE dia 5x18 MM/3.6 MM
BSD-1603110000.A23
1603110000
|
-
|
|
|
804 - HEXAGON SOCKET WRENCH
BSD-1607950002.A14
1607950002
|
-
|
|
|
805 - STUD BOLT
BSD-1603502000.A8
1603502000
|
£21.52
|
£25.83
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390002.A15
1600390002
|
-
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390003.A18
1600390003
|
-
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390004.A3
1600390004
|
-
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390005.A18
1600390005
|
-
|
|
|
