1 - MOTOR HOUSING
BSD-1605108145.A29
1605108145
|
£23.86
|
£28.63
|
|
|
2 - FIELD 230-240V
BSD-1604220388.A7
1604220388
|
£54.42
|
£65.30
|
|
|
3/50 - FAN
BSD-1606610127.A194
1606610127
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-3607200064.A7
3607200064
|
£37.27
|
£44.72
|
|
|
6 - GROMMET dia 10.5-dia11.0x100 MM
BSD-1600703023.A32
1600703023
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A821
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE GNF 65A
BSD-3601119292.A2
3601119292
|
£5.58
|
£6.70
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328035.A129
1607328035
|
£4.26
|
£5.11
|
|
|
13 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A576
1600905011
|
£5.58
|
£6.70
|
|
|
14 - GROOVE BALL BEARING 10x35x11
BSD-1600905023.A157
1600905023
|
£12.04
|
£14.45
|
|
|
16 - BRUSH HOLDER
BSD-1604336021.A97
1604336021
|
£2.80
|
£3.36
|
|
|
23 - SEALING CAP
BSD-1605500150.A90
1605500150
|
£3.72
|
£4.47
|
|
|
24 - HANDLE
BSD-1605132122.A1
1605132122
|
£14.91
|
£17.89
|
|
|
25 - GRINDING SPINDLE M14. SW17
BSD-1603523100.A104
1603523100
|
£14.91
|
£17.89
|
|
|
28 - O-RING 79.0x1.78 MM
BSD-1600210033.A659
1600210033
|
£1.75
|
£2.10
|
|
|
29 - O-RING 4.0x1.0 MM
BSD-1600210034.A81
1600210034
|
£1.75
|
£2.10
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591010.A105
1600591010
|
£2.16
|
£2.59
|
|
|
31 - AIR-DEFLECTOR RING
BSD-1600591011.A73
1600591011
|
£1.75
|
£2.10
|
|
|
32 - RETAINING SNAP RING
BSD-1600290019.A632
1600290019
|
£1.75
|
£2.10
|
|
|
33 - ROTARY SHAFT LIP SEAL 16 MM
BSD-1600290064.A368
1600290064
|
£2.16
|
£2.59
|
|
|
34 - SHIM 0.15 MM
BSD-1600190020.A28
1600190020
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.3 MM
BSD-1600190021.A799
1600190021
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190022.A28
1600190022
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.2 MM
BSD-1600190037.A395
1600190037
|
£1.75
|
£2.10
|
|
|
35 - FELT WASHER
BSD-1600205034.A45
1600205034
|
£1.75
|
£2.10
|
|
|
36 - SPIRAL SPRING
BSD-1604652015.A341
1604652015
|
£2.80
|
£3.36
|
|
|
37 - SEAL RING
BSD-1600290020.A48
1600290020
|
£1.75
|
£2.10
|
|
|
38 - RUBBER RING 7 MM
BSD-1600206020.A671
1600206020
|
£1.75
|
£2.10
|
|
|
39 - RUBBER RING
BSD-1600206030.A24
1600206030
|
£1.75
|
£2.10
|
|
|
44 - HOLDING BRACKET
BSD-1601334008.A44
1601334008
|
£2.61
|
£3.13
|
|
|
45 - HEX NUT M10. SW14
BSD-1603300019.A131
1603300019
|
£1.75
|
£2.10
|
|
|
48 - RETAINING CLIP
BSD-1600119010.A643
1600119010
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING
BSD-3600905134.A116
3600905134
|
£11.30
|
£13.56
|
|
|
51 - PLAIN BEARING dia14 MM
BSD-1600200031.A496
1600200031
|
£2.80
|
£3.36
|
|
|
52 - CABLE ROUTING
BSD-1602388027.A333
1602388027
|
£2.61
|
£3.13
|
|
|
53 - SOCKET HOUSING
BSD-1605190038.A38
1605190038
|
£1.75
|
£2.10
|
|
|
55 - STORAGE LEDGE
BSD-1602388029.A265
1602388029
|
£1.75
|
£2.10
|
|
|
60 - THREAD-FORMING TAP. SCREW
BSD-1603435076.A150
1603435076
|
£2.61
|
£3.13
|
|
|
61 - TAPPING SCREW DIN 7981-4.8x38-C-Z-ST
BSD-2912401038.A11
2912401038
|
£1.75
|
£2.10
|
|
|
62 - TAPPING SCREW C4.8x63 MM
BSD-1603435024.A242
1603435024
|
£1.75
|
£2.10
|
|
|
63 - PAN HEAD SCREW M 3.5x10 MM
BSD-3603410009.A5
3603410009
|
£1.32
|
£1.58
|
|
|
64 - PLASTIC-CUTTING SCREW St3.9x12
BSD-1603435042.A607
1603435042
|
£1.75
|
£2.10
|
|
|
65 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A87
2912401020
|
£2.16
|
£2.59
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A192
2910211019
|
£1.75
|
£2.10
|
|
|
67 - LENS HEAD SCREW
BSD-3603435040.A23
3603435040
|
£1.75
|
£2.10
|
|
|
100 - SPEED GOVERNOR 220-240V
BSD-1607233040.A7
1607233040
|
£68.42
|
£82.10
|
|
|
118 - CLAMPING-FLANGE dia 42 MM. SW17
BSD-3609202039.A0
3609202039
|
£21.68
|
£26.01
|
|
|
119 - ROUND NUT dia 45 MM. M14
BSD-3609202040.A7
3609202040
|
£40.80
|
£48.96
|
|
|
120 - PLAIN WASHER dia 42X22.2X4 MM
BSD-3609202041.A0
3609202041
|
£5.58
|
£6.70
|
|
|
121 - PLAIN WASHER dia 42X22.2X6 MM
BSD-3609202042.A13
3609202042
|
£3.80
|
£4.56
|
|
|
200 - PROTECTIVE COVER
BSD-3605500127.A2
3605500127
|
£410.78
|
£492.94
|
|
|
201 - PROTECTIVE COVER
BSD-3605500128.A1
3605500128
|
-
|
|
|
|
202 - LATERAL GUARD
BSD-3605500129.A2
3605500129
|
-
|
|
|
|
203 - SWIVEL ARM
BSD-3609202033.A0
3609202033
|
£37.27
|
£44.72
|
|
|
204 - COMPRESSION SPRING
BSD-3609202034.A3
3609202034
|
£2.61
|
£3.13
|
|
|
205 - PLAIN WASHER 8.4 DIN 433-ST
BSD-2916011015.A33
2916011015
|
£1.75
|
£2.10
|
|
|
207 - CLAMPING LEVER
BSD-1907904721.A2
1907904721
|
£14.91
|
£17.89
|
|
|
208 - STAR KNOB DIN 6336-K40-M8
BSD-1905621105.A1
1905621105
|
£16.41
|
£19.69
|
|
|
210 - MOUNTING RAIL
BSD-3609202035.A0
3609202035
|
£48.38
|
£58.06
|
|
|
211 - AXLE
BSD-3609202036.A3
3609202036
|
£27.23
|
£32.68
|
|
|
212 - ROLLER dia 36X50 MM
BSD-3609202037.A0
3609202037
|
£23.86
|
£28.63
|
|
|
213 - ROLLER dia 36X28 MM
BSD-3609202038.A3
3609202038
|
£21.52
|
£25.83
|
|
|
214 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A60
2916650003
|
£1.75
|
£2.10
|
|
|
215 - SHIM RING
BSD-3603435021.A1
3603435021
|
£2.61
|
£3.13
|
|
|
216 - SHIM RING
BSD-3603435022.A2
3603435022
|
£2.80
|
£3.36
|
|
|
217 - SEAL
BSD-3601010045.A1
3601010045
|
£5.30
|
£6.36
|
|
|
218 - MANUFACTURER'S NAMEPLATE
BSD-3601119110.A2
3601119110
|
-
|
|
|
|
667 - SPLITTING TOOL
BSD-3607959005.A19
3607959005
|
£21.68
|
£26.01
|
|
|
722 - AUXILIARY HANDLE M14x1.5 MM
BSD-2602025075.A153
2602025075
|
£10.30
|
£12.36
|
|
|
753 - CARRYING CASE
BSD-2605438348.A2
2605438348
|
-
|
|
|
|
755 - DIAMOND CUTTING BLADE dia 230x22.2x2.8 MM
BSD-2608600037.A1
2608600037
|
-
|
|
|
|
755 - DIAMOND CUTTING BLADE dia 230X22.2X2.8 MM
BSD-2608600141.A2
2608600141
|
-
|
|
|
|
756 - DIAMOND CUTTING BLADE dia 230x22.2x2.8 MM
BSD-2608600035.A2
2608600035
|
-
|
|
|
|
756 - DIAMOND CUTTING BLADE dia 230X22.2X2.8 MM
BSD-2608600142.A1
2608600142
|
-
|
|
|
|
757 - DIAMOND CUTTING BLADE dia 230X22.2X2.8 MM
BSD-2608600126.A2
2608600126
|
-
|
|
|
|
758 - DIAMOND CUTTING BLADE dia 230x22.2x2.8 MM
BSD-2608600039.A2
2608600039
|
-
|
|
|
|
763 - SUCTION BEND dia 35 MM
BSD-1600793007.A21
1600793007
|
£19.24
|
£23.09
|
|
|
764 - PIN-TYPE FACE-WRENCH
BSD-1607950004.A192
1607950004
|
£8.33
|
£10.00
|
|
|
770 - AIR HOSE dia 35 MM. L=5 M
BSD-1609202230.A145
1609202230
|
£85.74
|
£102.89
|
|
|
803 - ARMATURE 230-240V
BSD-1604011156.A15
1604011156
|
£135.25
|
£162.30
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A276
1607000228
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3670
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014171.A484
1607014171
|
£14.91
|
£17.89
|
|
|
818 - TENSIONER PARTS SET
BSD-3609202043.A0
3609202043
|
£63.50
|
£76.20
|
|
|
821 - GEAR HOUSING
BSD-1605805592.A57
1605805592
|
£72.18
|
£86.62
|
|
|
822 - BEARING FLANGE dia 230 MM
BSD-1607000922.A67
1607000922
|
£45.67
|
£54.80
|
|
|
826 - ASSEMBLY OF SERVICE PARTS
BSD-1600A005BH.A91
1600A005BH
|
£45.67
|
£54.80
|
|
|
833 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A188
1600290013
|
£2.61
|
£3.13
|
|
|
840 - PUSH-BUTTON
BSD-1607000206.A188
1607000206
|
£11.30
|
£13.56
|
|
|
846 - RETAINING WASHER
BSD-1607000C3E.A259
1607000C3E
|
£12.04
|
£14.45
|
|
|
851 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A163
2600910001
|
£4.26
|
£5.11
|
|
