1 - WASHER
MET-141150050.A101
141150050
|
£1.50
|
£1.80
|
|
|
2 - HEXAGON HEAD SCREW M 10X20 VERZ.
MET-6103005270.A66
6103005270
|
-
|
|
|
|
3 - REDUCER NIPPL 3/4X1/2 NR. 241 / VERZ.
MET-7871032658.A1
7871032658
|
-
|
|
|
|
4 - UNION R 1/2AG X RD 15 GERADE
MET-7872027356.A6
7872027356
|
£9.82
|
£11.79
|
|
|
5 - HEX NUT
MET-141132030.A147
141132030
|
£2.94
|
£3.53
|
|
|
6 - THREADED PLUG 1 NR.596 / VERZ.
MET-7871675990.A4
7871675990
|
-
|
|
|
|
7 - DRAIN VALVE R 1/2
MET-7830029286.A8
7830029286
|
£28.45
|
£34.14
|
|
|
8 - SWIVEL PLATE CASTER RD 75X25 M.FESTSTELL
MET-7271663832.A6
7271663832
|
£20.12
|
£24.14
|
|
|
9 - HEXAGON SOCKET HEAD CAP SCREW M 10X25 VE
MET-6127609460.A13
6127609460
|
£1.50
|
£1.80
|
|
|
10 - HEXAGON NUT PREV. TORQUE TYPE
MET-6202024139.A14
6202024139
|
£1.50
|
£1.80
|
|
|
11 - WASHER B 13 VERZ.
MET-6305002508.A63
6305002508
|
£1.50
|
£1.80
|
|
|
12 - WHEEL PNEUMATIC TYRE RD 260/85 M.STAHLF
MET-7270663825.A4
7270663825
|
£35.57
|
£42.68
|
|
|
13 - WASHER
MET-6300016705.A5
6300016705
|
£1.50
|
£1.80
|
|
|
14 - HEXAGON HEAD SCRE M 12X80 VERZ.
MET-6102024123.A0
6102024123
|
£1.50
|
£1.80
|
|
|
15 - CABLE RUBBER JACKET
MET-8402415682.A13
8402415682
|
-
|
|
|
|
16 - HANDLE
MET-1341630874.A18
1341630874
|
-
|
|
|
|
17 - CROSS RECD PAN HEAD TAP.SCREW ST 3 5X19
MET-6172039616.A2
6172039616
|
£1.50
|
£1.80
|
|
|
18 - HANDLE TUBE RDA 20X1 5X1231 GEBOGEN
MET-1317677835.A19
1317677835
|
-
|
|
|
|
19 - HOSE COIL ASSEMBLY ET
MET-1001678430.A12
1001678430
|
-
|
|
|
|
20 - QUICK CONNECTION COUPLING EURO 1/2 AG
MET-7802009105.A22
7802009105
|
-
|
|
|
|
21 - REDUCER NIPPL 1X1/2 NR.241 / VERZ.
MET-7871026968.A9
7871026968
|
-
|
|
|
|
22 - HEXAGON HEAD SCREW M 10X40 VERZ.
MET-141124500.A6
141124500
|
-
|
|
|
|
23 - COPPER PIPE RD 15X1X1250 GEBOGEN
MET-1317678300.A1
1317678300
|
£49.88
|
£59.86
|
|
|
24 - CHECK VALVE ELBOW TYP R 1/2X RD 15 M.G
MET-1001193151.A2
1001193151
|
£41.44
|
£49.73
|
|
|
25 - HOSE CLAMP
MET-1341645472.A2
1341645472
|
-
|
|
|
|
30 - FILLISTER HEAD SCREW
MET-6172001830.A29
6172001830
|
£1.50
|
£1.80
|
|
|
31 - TIN NUT
MET-6265167657.A10
6265167657
|
£2.60
|
£3.12
|
|
|
32 - BEARING BLOCK
MET-1341634594.A2
1341634594
|
£3.11
|
£3.73
|
|
|
33 - ELBOW TAP CONNECTOR R 1/4A X 10MM M.O-R
MET-7872675854.A34
7872675854
|
-
|
|
|
|
34 - CRANK
MET-1341634608.A18
1341634608
|
£3.11
|
£3.73
|
|
|
40 - ELBOW TAP CONNECTOR R 1/4A X 10MM M.O-R
MET-7872675854.A33
7872675854
|
-
|
|
|
|
41 - AUTOM. PRESSURE CONTROL SWITCH MDR 3/11-
MET-8101182747.A2
8101182747
|
£105.54
|
£126.65
|
|
|
42 - CABLE RUBBER JACKET
MET-8401664077.A16
8401664077
|
-
|
|
|
|
43 - RELIEF VALVE EV3 S
MET-7834664121.A2
7834664121
|
-
|
|
|
|
44 - PLASTIC HOSE COMPL.
MET-316061030.A8
316061030
|
£26.35
|
£31.62
|
|
|
45 - V-BELT SPA 1400
MET-7230663917.A5
7230663917
|
-
|
|
|
|
46 - HEXAGON SOCKET HEAD CAP SCREW M 10X35 VE
MET-6127056666.A10
6127056666
|
-
|
|
|
|
47 - ELECTRIC MOTOR 400/3/50 2800UPM B3 /M.KL
MET-8013677990.A3
8013677990
|
-
|
|
|
|
48 - FLANGE NUT M 10
MET-6209675984.A20
6209675984
|
£1.50
|
£1.80
|
|
|
49 - HEXAGONAL LOCK NUT
MET-141130930.A33
141130930
|
£1.50
|
£1.80
|
|
|
50 - WASHER
MET-141150020.A23
141150020
|
£1.50
|
£1.80
|
|
|
51 - TUBE FITTING 1/8X RD 6 GERADE-STECKBAR
MET-7872722836.A6
7872722836
|
£7.04
|
£8.45
|
|
|
52 - FLANGE NUT
MET-6209110995.A110
6209110995
|
£1.50
|
£1.80
|
|
|
53 - PLASTIC HOSE RD 6X2X100000 DRUCK./HITZEB
MET-7851675935.A0
7851675935
|
-
|
|
|
|
54 - CAGE NUT M 5
MET-1010739906.A1
1010739906
|
-
|
|
|
|
55 - PROTECTIVE GRATING FRONT
MET-1312739832.A0
1312739832
|
-
|
|
|
|
56 - PROTECTIVE GRATING REAR BL 1
MET-1312722360.A3
1312722360
|
-
|
|
|
|
57 - HEXAGON SOCKET HEAD CAP SCREW
MET-6121121296.A21
6121121296
|
£1.50
|
£1.80
|
|
|
58 - FILTER PRESSURE REGULATOR ASS` FR 1/4/0
MET-7820724784.A5
7820724784
|
£64.79
|
£77.75
|
|
|
59 - SAFETY VALVE R 1/4 11 BAR
MET-7833009618.A2
7833009618
|
£54.94
|
£65.93
|
|
|
60 - ELBOW TAP CONNECTOR 1/4A X 6MM M.O-RING
MET-7872663090.A19
7872663090
|
-
|
|
|
|
61 - TUBE FITTING 1/2I X 1/2A LÖSBAR
MET-7871664190.A17
7871664190
|
-
|
|
|
|
62 - PIPE NIPPL 1/2X150 VERZINKT
MET-7812052440.A7
7812052440
|
-
|
|
|
|
63 - CONNECTING PLATE BL 1 50X25
MET-1312739891.A2
1312739891
|
-
|
|
|
|
64 - LOCKING BUSH 1610-24 / NUT 8 MM TAPER
MET-7243676007.A5
7243676007
|
-
|
|
|
|
65 - V-BELT PULLEY TBA 132-1-1610
MET-7240663966.A2
7240663966
|
-
|
|
|
|
66 - FEATHER KEY A 8X7X35 ET
MET-6721608849.A12
6721608849
|
-
|
|
|
|
67 - HEXAGON HEAD SCREW
MET-141114860.A33
141114860
|
£3.20
|
£3.84
|
|
|
68 - WASHER
MET-141151340.A165
141151340
|
£1.50
|
£1.80
|
|
|
69 - INTEGRATED PRESSURE GAUGE RD 40 R1/8I 0
MET-1001697303.A8
1001697303
|
-
|
|
|
|
70 - RETENTION PLATE BL 2 00X262X276
MET-1312722506.A11
1312722506
|
-
|
|
|
|
73 - FAN COVER T 90 L-2
MET-1312714732.A2
1312714732
|
-
|
|
|
|
74 - FAN WING T 90 L-2
MET-1312714724.A1
1312714724
|
-
|
|
|
|
100 - COMPRESSOR PUMP B3800B M.LÜFTERRAD RD350
MET-1313663848.A0
1313663848
|
£293.94
|
£352.73
|
|
|
101 - AIR FILTER ET
MET-7825156113.A10
7825156113
|
-
|
|
|
|
102 - PISTON RING RD 60X2 ET
MET-1319164100.A9
1319164100
|
£36.59
|
£43.91
|
|
|
103 - PISTON RING RD 60X2 ET
MET-1319164118.A5
1319164118
|
£42.65
|
£51.18
|
|
|
104 - OIL WIPING RING RD 60X3 ET
MET-1319164126.A9
1319164126
|
£48.88
|
£58.66
|
|
|
106 - GUDGEON PIN RD 15X50 ET
MET-1315163885.A7
1315163885
|
-
|
|
|
|
108 - CONNECTING ROD ET
MET-1319657378.A6
1319657378
|
£54.44
|
£65.33
|
|
|
109 - ROTARY SHAFT SEAL ET
MET-7635157067.A2
7635157067
|
£11.20
|
£13.44
|
|
|
110 - HOUSING LID
MET-1319720150.A2
1319720150
|
-
|
|
|
|
111 - FLYWHEEL RD 350 ET
MET-1319678391.A7
1319678391
|
-
|
|
|
|
112 - WASHER 8 5X30X5 ET
MET-1315166400.A18
1315166400
|
-
|
|
|
|
113 - CAP SCREW
MET-6121000839.A48
6121000839
|
£1.50
|
£1.80
|
|
|
115 - DEEP GROOVE BALL BEARING 25X52X15 6205
MET-7100157076.A2
7100157076
|
-
|
|
|
|
118 - PACKING AFTERCOOLER ET
MET-1319151431.A6
1319151431
|
-
|
|
|
|
119 - AFTERCOOLER 11 LAMELLEN B3800B /ET
MET-1319707448.A6
1319707448
|
£54.94
|
£65.93
|
|
|
124 - BEARING CAP PINION END ET
MET-1319157049.A2
1319157049
|
-
|
|
|
|
125 - OIL SIGHT GLASS 1/2 ET
MET-1319155860.A1
1319155860
|
£9.82
|
£11.79
|
|
|
126 - PACKING HOUSING LID ET
MET-1319657386.A1
1319657386
|
£26.85
|
£32.22
|
|
|
129 - OIL WIPING SCREW 3/8 ET
MET-1319655111.A8
1319655111
|
£17.95
|
£21.54
|
|
