1 - WASHER
MET-141150050.A8
141150050
|
£1.50
|
£1.80
|
|
|
2 - HEXAGON HEAD SCREW M 10X20 VERZ.
MET-6103005270.A8
6103005270
|
-
|
|
|
|
3 - REDUCER NIPPL 1X1/2 NR.241 / VERZ.
MET-7871026968.A18
7871026968
|
-
|
|
|
|
4 - HEX NUT
MET-141132030.A69
141132030
|
£2.94
|
£3.53
|
|
|
5 - THREADED PLUG 1 NR.596 / VERZ.
MET-7871675990.A17
7871675990
|
-
|
|
|
|
6 - DRAIN VALVE R 1/2
MET-7830029286.A10
7830029286
|
£28.45
|
£34.14
|
|
|
7 - SWIVEL PLATE CASTER RD 75X25 M.FESTSTELL
MET-7271663832.A13
7271663832
|
£20.12
|
£24.14
|
|
|
8 - HEXAGON SOCKET HEAD CAP SCREW M 10X25 VE
MET-6127609460.A0
6127609460
|
£1.50
|
£1.80
|
|
|
9 - HEXAGON NUT PREV. TORQUE TYPE
MET-6202024139.A22
6202024139
|
£1.50
|
£1.80
|
|
|
10 - WASHER B 13 VERZ.
MET-6305002508.A26
6305002508
|
£1.50
|
£1.80
|
|
|
11 - WHEEL PNEUMATIC TYRE RD 300/100
MET-7270663812.A7
7270663812
|
-
|
|
|
|
12 - WASHER
MET-6300016705.A51
6300016705
|
£1.50
|
£1.80
|
|
|
13 - HEXAGON HEAD SCRE M 12X100 VERZ.
MET-6103001275.A10
6103001275
|
-
|
|
|
|
14 - CABLE RUBBER JACKET
MET-8402415682.A12
8402415682
|
-
|
|
|
|
15 - HANDLE
MET-1341630874.A3
1341630874
|
-
|
|
|
|
16 - CROSS RECD PAN HEAD TAP.SCREW ST 3 5X19
MET-6172039616.A10
6172039616
|
£1.50
|
£1.80
|
|
|
17 - HANDLE TUBE RDA 20X1 5X1231 GEBOGEN
MET-1317677835.A10
1317677835
|
-
|
|
|
|
18 - HOSE COIL ASSEMBLY ET
MET-1001678430.A10
1001678430
|
-
|
|
|
|
19 - QUICK CONNECTION COUPLING EURO 1/2 AG
MET-7802009105.A1
7802009105
|
-
|
|
|
|
20 - REDUCER NIPPL 1X1/2 NR.241 / VERZ.
MET-7871026968.A17
7871026968
|
-
|
|
|
|
21 - HEXAGON HEAD SCREW M 10X40 VERZ.
MET-141124500.A25
141124500
|
-
|
|
|
|
22 - STEEL MESH HOSE NW13X500/16BAR M26X1
MET-7853663993.A3
7853663993
|
-
|
|
|
|
23 - CHECK VALVE ELBOW TYPE R 1/2X RD 18 M.
MET-1001676705.A10
1001676705
|
£35.57
|
£42.68
|
|
|
24 - HOSE CLAMP
MET-1341645472.A17
1341645472
|
-
|
|
|
|
30 - FILLISTER HEAD SCREW
MET-6172001830.A49
6172001830
|
£1.50
|
£1.80
|
|
|
31 - TIN NUT
MET-6265167657.A15
6265167657
|
£2.60
|
£3.12
|
|
|
32 - BEARING BLOCK
MET-1341634594.A17
1341634594
|
£3.11
|
£3.73
|
|
|
33 - ELBOW TAP CONNECTOR R 1/4A X 10MM M.O-R
MET-7872675854.A0
7872675854
|
-
|
|
|
|
34 - CRANK
MET-1341634608.A3
1341634608
|
£3.11
|
£3.73
|
|
|
40 - ELBOW TAP CONNECTOR R 1/4A X 10MM M.O-R
MET-7872675854.A1
7872675854
|
-
|
|
|
|
41 - AUTOM.PRESS.CONTR.SWITCH ASSY MDR 3/11
MET-8101190820.A8
8101190820
|
£111.88
|
£134.26
|
|
|
42 - CABLE RUBBER JACKET
MET-8401664077.A9
8401664077
|
-
|
|
|
|
43 - RELIEF VALVE EV3 S
MET-7834664121.A16
7834664121
|
-
|
|
|
|
44 - PLASTIC HOSE COMPL.
MET-316061030.A59
316061030
|
£26.35
|
£31.62
|
|
|
45 - V-BELT SPA 1432
MET-7230663925.A3
7230663925
|
-
|
|
|
|
46 - HEXAGON SOCKET HEAD CAP SCREW M 10X35 VE
MET-6127056666.A3
6127056666
|
-
|
|
|
|
47 - ELECTRIC MOTOR 3 00 DN 400/3/50 B3 /M.K
MET-8013663891.A0
8013663891
|
-
|
|
|
|
48 - FLANGE NUT M 10
MET-6209675984.A0
6209675984
|
£1.50
|
£1.80
|
|
|
49 - HEXAGONAL LOCK NUT
MET-141130930.A10
141130930
|
£1.50
|
£1.80
|
|
|
50 - WASHER
MET-141150020.A87
141150020
|
£1.50
|
£1.80
|
|
|
51 - TUBE FITTING 1/8X RD 6 GERADE-STECKBAR
MET-7872722836.A15
7872722836
|
£7.04
|
£8.45
|
|
|
52 - FLANGE NUT
MET-6209110995.A31
6209110995
|
£1.50
|
£1.80
|
|
|
53 - PLASTIC HOSE RD 6X2X100000 DRUCK./HITZEB
MET-7851675935.A18
7851675935
|
-
|
|
|
|
54 - CAGE NUT M 5
MET-1010739906.A4
1010739906
|
-
|
|
|
|
55 - PROTECTIVE GRATING FRONT
MET-1312739840.A0
1312739840
|
-
|
|
|
|
56 - PROTECTIVE GRATING REAR BL 1
MET-1312722379.A2
1312722379
|
-
|
|
|
|
57 - HEXAGON SOCKET HEAD CAP SCREW
MET-6121121296.A12
6121121296
|
£1.50
|
£1.80
|
|
|
58 - FILTER PRESSURE REGULATOR ASS` FR 1/4/0
MET-7820724784.A1
7820724784
|
£64.79
|
£77.75
|
|
|
59 - SAFETY VALVE R 1/4 11 BAR
MET-7833009618.A16
7833009618
|
£54.94
|
£65.93
|
|
|
60 - ELBOW TAP CONNECTOR 1/4A X 6MM M.O-RING
MET-7872663090.A3
7872663090
|
-
|
|
|
|
61 - TUBE FITTING 1/2I X 1/2A LÖSBAR
MET-7871664190.A3
7871664190
|
-
|
|
|
|
62 - PIPE NIPPL 1/2X150 VERZINKT
MET-7812052440.A11
7812052440
|
-
|
|
|
|
63 - CONNECTING PLATE BL 1 50X25
MET-1312739891.A4
1312739891
|
-
|
|
|
|
64 - LOCKING BUSH 1610-28 / NUT 8 MM TAPER
MET-7243676678.A3
7243676678
|
-
|
|
|
|
65 - V-BELT PULLEY TBA 150-1-1610
MET-7240663982.A0
7240663982
|
-
|
|
|
|
66 - FEATHER KEY A 8X7X35 ET
MET-6721608849.A9
6721608849
|
-
|
|
|
|
67 - HEXAGON HEAD SCREW
MET-141114860.A97
141114860
|
£3.20
|
£3.84
|
|
|
68 - WASHER
MET-141151340.A72
141151340
|
£1.50
|
£1.80
|
|
|
69 - INTEGRATED PRESSURE GAUGE RD 40 R1/8I 0
MET-1001697303.A11
1001697303
|
-
|
|
|
|
70 - RETENTION PLATE BL 2 00X262X276
MET-1312722506.A1
1312722506
|
-
|
|
|
|
73 - FAN COVER BAUGRÖßE 100/ET MEGA 600/700/7
MET-1312713981.A7
1312713981
|
-
|
|
|
|
74 - FAN WING BAUGRÖßE 100/ET MEGA 600/700/71
MET-1312713973.A5
1312713973
|
-
|
|
|
|
100 - COMPRESSOR PUMP B 4900/A M.LÜFTERRAD RD
MET-1313663856.A1
1313663856
|
-
|
|
|
|
101 - AIR FILTER ET
MET-7825156180.A1
7825156180
|
£26.85
|
£32.22
|
|
|
102 - PISTON RING RD 50X2
MET-1319164193.A3
1319164193
|
-
|
|
|
|
103 - PISTON RING RD 50X2
MET-1319164207.A1
1319164207
|
-
|
|
|
|
104 - OIL WIPING RING RD 50X4
MET-1319164215.A3
1319164215
|
-
|
|
|
|
105 - PISTON HP RD 50 ET
MET-1319163790.A2
1319163790
|
-
|
|
|
|
106 - GUDGEON PIN RD 18X42 ET
MET-1315163915.A0
1315163915
|
-
|
|
|
|
107 - CIRCLIP FOR BORES 18X1 ET
MET-6401627209.A10
6401627209
|
-
|
|
|
|
108 - PISTON-CONNECTING ROD SET
MET-341211040.A3
341211040
|
-
|
|
|
|
109 - CONROD BEARING SHELL ET
MET-1319157057.A0
1319157057
|
-
|
|
|
|
110 - PACKING INTERMEDIATE COOLER ET
MET-1319157138.A4
1319157138
|
£9.82
|
£11.79
|
|
|
111 - SAFETY VALVE R 1/4 4
MET-7833626781.A10
7833626781
|
-
|
|
|
|
113 - ROTARY SHAFT SEAL ET
MET-7635157067.A9
7635157067
|
£11.20
|
£13.44
|
|
|
114 - FLYWHEEL RD 350 ET
MET-1319678391.A2
1319678391
|
-
|
|
|
|
115 - WASHER 8 5X30X5 ET
MET-1315166400.A0
1315166400
|
-
|
|
|
|
116 - CAP SCREW
MET-6121000839.A19
6121000839
|
£1.50
|
£1.80
|
|
|
117 - CRANKSHAFT ET
MET-1315164709.A4
1315164709
|
-
|
|
|
|
119 - DEEP GROOVE BALL BEARING 25X52X15 6205
MET-7100157076.A8
7100157076
|
-
|
|
|
|
121 - CYLINDER HEAD GASKET ET
MET-1319156174.A3
1319156174
|
-
|
|
|
|
122 - PACKING VALVE PLATE ET
MET-1319156140.A2
1319156140
|
-
|
|
|
|
123 - CYLINDER GASKET ET
MET-1319156166.A1
1319156166
|
-
|
|
|
|
126 - OIL WIPING RIN RD 95X5
MET-1319164240.A1
1319164240
|
-
|
|
|
|
127 - PISTON RIN RD 95X2
MET-1319164231.A3
1319164231
|
-
|
|
|
|
128 - PISTON RIN RD 95X2
MET-1319164223.A1
1319164223
|
-
|
|
|
|
129 - HEXAGON NUT PREV. TORQUE TYPE
MET-6202002305.A138
6202002305
|
£1.50
|
£1.80
|
|
|
130 - CYLINDER HEAD ET
MET-1319156123.A1
1319156123
|
-
|
|
|
|
131 - VALVE PLATE SET
MET-341165090.A1
341165090
|
-
|
|
|
|
133 - CYLINDER FOOT GASKET ET
MET-1319161992.A1
1319161992
|
-
|
|
|
|
134 - CRANKCASE BREATHER 3/8 ET
MET-1319155895.A0
1319155895
|
-
|
|
|
|
135 - BEARING CAP PINION END ET
MET-1319157049.A12
1319157049
|
-
|
|
|
|
136 - OIL SIGHT GLASS 1/2 ET
MET-1319155860.A9
1319155860
|
£9.82
|
£11.79
|
|
|
138 - CRANKCASE PACKING ET
MET-1319164444.A1
1319164444
|
£26.85
|
£32.22
|
|
|
140 - PACKING PRESSURE LINE ET
MET-1319161763.A0
1319161763
|
£11.20
|
£13.44
|
|
