1 - DAMPING RING
MET-344101760.A2
344101760
|
-
|
|
|
|
2 - BRUSH HOLDER MODULE
MET-343437770.A0
343437770
|
-
|
|
|
|
3 - CARBON BRUSH SET CUT-OFF
MET-316046900.A49
316046900
|
£15.41
|
£18.49
|
|
|
4 - WASHER
MET-141155950.A4
141155950
|
-
|
|
|
|
5 - SELF-TAPP. FILL. H. SCREW
MET-141119900.A77
141119900
|
£1.50
|
£1.80
|
|
|
6 - FIELD COIL W.FIELD COIL 230V
MET-311012320.A1
311012320
|
-
|
|
|
|
7 - FILLISTER HEAD SCREW
MET-141124100.A9
141124100
|
-
|
|
|
|
8 - MOTOR FLANGE
MET-343437780.A3
343437780
|
-
|
|
|
|
9 - SELF-TAP. FILL. H. SCREW
MET-141118260.A23
141118260
|
£1.50
|
£1.80
|
|
|
10 - RUBBER BUSHING
MET-344097870.A321
344097870
|
£1.50
|
£1.80
|
|
|
11 - BALL BEARING 6X 19X 6
MET-143114750.A6
143114750
|
£13.63
|
£16.36
|
|
|
12 - ARMATURE COMPL. 230V
MET-310011590.A3
310011590
|
-
|
|
|
|
13 - BALL BEARING 8X 22X 7
MET-143115890.A1
143115890
|
£6.38
|
£7.65
|
|
|
14 - FLANGE
MET-315202930.A2
315202930
|
-
|
|
|
|
15 - GEAR GASKET
MET-339012140.A3
339012140
|
-
|
|
|
|
16 - FILLISTER HEAD SCREW
MET-141110540.A1
141110540
|
£1.50
|
£1.80
|
|
|
17 - RUBBER PLUG
MET-344091420.A43
344091420
|
£1.50
|
£1.80
|
|
|
18 - GEAR-BOX COVER CPL.
MET-316063070.A0
316063070
|
-
|
|
|
|
19 - INTERMEDIATE SHAFT CPL.
MET-316063080.A3
316063080
|
-
|
|
|
|
20 - GEAR GASKET
MET-339012130.A0
339012130
|
-
|
|
|
|
21 - INTERMEDIATE FLANGE CPL.
MET-316063090.A0
316063090
|
-
|
|
|
|
22 - BUTTING WASHER
MET-339007890.A2
339007890
|
-
|
|
|
|
23 - INTERNAL GEAR
MET-340004370.A1
340004370
|
-
|
|
|
|
24 - PLANET CARRIER CPL.
MET-316063100.A3
316063100
|
-
|
|
|
|
25 - 3EEDLE ROLLER AND CAGE
MET-143115450.A22
143115450
|
£6.38
|
£7.65
|
|
|
26 - PLANET WHEEL
MET-340004380.A2
340004380
|
-
|
|
|
|
27 - BUTTING WASHER
MET-339007900.A1
339007900
|
-
|
|
|
|
28 - WAVE WASHER
MET-143115880.A2
143115880
|
-
|
|
|
|
29 - SHIM
MET-141156760.A2
141156760
|
-
|
|
|
|
30 - SELF-TAP FILL H SCREW
MET-141116020.A976
141116020
|
£3.20
|
£3.84
|
|
|
31 - RATING PLATE 00136000 LSV 5-225 COMF
MET-338065300.A1
338065300
|
-
|
|
|
|
32 - WARNING LABEL
MET-338127050.A1
338127050
|
-
|
|
|
|
33 - HOUSING W. COVER COMPL.
MET-343437640.A1
343437640
|
-
|
|
|
|
34 - SHAFT
MET-341604830.A1
341604830
|
-
|
|
|
|
35 - NEEDLE SLEEVE
MET-143111740.A5
143111740
|
-
|
|
|
|
36 - FELT SEAL
MET-344071030.A0
344071030
|
-
|
|
|
|
37 - WASHER
MET-339001110.A1
339001110
|
£1.50
|
£1.80
|
|
|
38 - COUPLING
MET-341071700.A1
341071700
|
-
|
|
|
|
39 - PRESSURE SPRING
MET-342004040.A1
342004040
|
-
|
|
|
|
40 - CLAW RING
MET-341071680.A1
341071680
|
-
|
|
|
|
41 - LED COMPL.
MET-343085180.A1
343085180
|
-
|
|
|
|
42 - BRUSH HOLDER COMPL. CUT OUT 230V
MET-316046890.A23
316046890
|
£15.42
|
£18.51
|
|
|
43 - EXTRACTION CHANNEL
MET-343437680.A2
343437680
|
-
|
|
|
|
44 - CABLE CLIP
MET-343362490.A428
343362490
|
£3.20
|
£3.84
|
|
|
45 - SELF-TAP. FILL. H. SCREW
MET-141117060.A468
141117060
|
£3.20
|
£3.84
|
|
|
46 - CABLE SLEEVE
MET-344101140.A27
344101140
|
£3.82
|
£4.59
|
|
|
47 - SWITCH
MET-343410840.A1
343410840
|
-
|
|
|
|
48 - ON-OFF SWITCH
MET-343411540.A0
343411540
|
-
|
|
|
|
49 - END PIECE
MET-341162190.A1
341162190
|
£2.94
|
£3.53
|
|
|
50 - TERMINAL RAIL
MET-343050140.A0
343050140
|
£3.20
|
£3.84
|
|
|
51 - STRAND COMPL.
MET-344530490.A0
344530490
|
-
|
|
|
|
52 - STRAND COMPL.
MET-344530480.A1
344530480
|
-
|
|
|
|
53 - ELECTRONIC UNIT 230V 5060HZ
MET-343085690.A1
343085690
|
-
|
|
|
|
54 - TRANSFORMER COMPL.
MET-316097070.A0
316097070
|
-
|
|
|
|
55 - CABLE WITH PLUG
MET-344493180.A96
344493180
|
£26.35
|
£31.62
|
|
|
56 - ADJUSTING SLEEVE
MET-341071740.A0
341071740
|
-
|
|
|
|
57 - COUNTERSUNK SCREW
MET-141122860.A27
141122860
|
£1.50
|
£1.80
|
|
|
58 - SELF-TAP. FILL. H. SCREW
MET-141113180.A161
141113180
|
£1.50
|
£1.80
|
|
|
59 - CLAMPING ECCENTRIC
MET-341211180.A1
341211180
|
-
|
|
|
|
61 - CLAW RING
MET-341071690.A0
341071690
|
-
|
|
|
|
62 - CLAMPING LEVER
MET-343437700.A0
343437700
|
-
|
|
|
|
65 - FILLISTER HEAD SCREW
MET-141119850.A177
141119850
|
£1.50
|
£1.80
|
|
|
66 - HOUSING 2 PART
MET-343437810.A0
343437810
|
-
|
|
|
|
67 - TENTERHOOK
MET-315419120.A1
315419120
|
-
|
|
|
|
68 - WASHER
MET-141150110.A25
141150110
|
£1.50
|
£1.80
|
|
|
69 - RETAINING TUBE
MET-341112880.A0
341112880
|
-
|
|
|
|
71 - CONNECTING PIECE
MET-343438050.A1
343438050
|
-
|
|
|
|
72 - HOLLOW SHAFT COMPL.
MET-316061990.A0
316061990
|
-
|
|
|
|
73 - ADAPTER FLANGE COMPL.
MET-343437800.A1
343437800
|
-
|
|
|
|
74 - HOLLOW SHAFT COMPL.
MET-316061980.A1
316061980
|
-
|
|
|
|
76 - RETAINING TUBE
MET-341112870.A1
341112870
|
-
|
|
|
|
77 - RETAINING RING
MET-141180040.A8
141180040
|
£1.50
|
£1.80
|
|
|
78 - BALL BEARING 10X26X8
MET-143111120.A9
143111120
|
£22.61
|
£27.13
|
|
|
79 - INTERMEDIATE SHAFT
MET-341604820.A0
341604820
|
-
|
|
|
|
80 - RETAINER BUSHING
MET-341071770.A1
341071770
|
-
|
|
|
|
81 - CIRCLIP
MET-141156360.A45
141156360
|
£1.50
|
£1.80
|
|
|
82 - EXTRACTION HOSE COMPL.
MET-316062030.A1
316062030
|
-
|
|
|
|
83 - HOLDER COMPL.
MET-343437790.A0
343437790
|
-
|
|
|
|
84 - CAP SCREW
MET-141111050.A2
141111050
|
£1.50
|
£1.80
|
|
|
85 - COVER
MET-343438600.A2
343438600
|
-
|
|
|
|
86 - COVER
MET-343438610.A1
343438610
|
-
|
|
|
|
87 - FORK COMPL.
MET-343437760.A2
343437760
|
-
|
|
|
|
88 - SWIVEL FLANGE COMPL.
MET-343437820.A1
343437820
|
-
|
|
|
|
89 - SLIDING BUSHING
MET-341006290.A1
341006290
|
-
|
|
|
|
90 - SELF-TAP. FILL. H. SCREW
MET-141116130.A30
141116130
|
£1.50
|
£1.80
|
|
|
91 - LOCKING DISC
MET-339007990.A1
339007990
|
-
|
|
|
|
92 - CONNECTOR BOLT
MET-341515860.A1
341515860
|
-
|
|
|
|
93 - FELT RING
MET-339012230.A1
339012230
|
-
|
|
|
|
94 - INSERT SET
MET-316064360.A1
316064360
|
-
|
|
|
|
95 - INTERMEDIATE FLANGE COMPL.
MET-316065150.A1
316065150
|
-
|
|
|
|
96 - WASHER
MET-339009440.A1
339009440
|
-
|
|
|
|
98 - BEARING CLAMP
MET-343437710.A1
343437710
|
-
|
|
|
|
99 - SLIDING BUSHING
MET-341006280.A2
341006280
|
-
|
|
|
|
100 - WHEEL GUARD
MET-343437830.A2
343437830
|
-
|
|
|
|
101 - SLIDING BUSHING
MET-341006270.A1
341006270
|
-
|
|
|
|
102 - COVERING HOOD
MET-343437720.A2
343437720
|
-
|
|
|
|
103 - ANGLE BRACKET
MET-343437730.A1
343437730
|
-
|
|
|
|
104 - ADJUSTING RING CPL.
MET-316063120.A3
316063120
|
-
|
|
|
|
105 - EDGE PROTECTION
MET-343437690.A2
343437690
|
-
|
|
|
|
107 - PRESSURE SPRING
MET-342004050.A1
342004050
|
-
|
|
|
|
108 - BRUSH HOLDER
MET-343438280.A1
343438280
|
-
|
|
|
|
109 - REPLACEMENT BRUSH RIM 225 MM
MET-626663000.A2
626663000
|
-
|
|
|
|
110 - ROUND COMPL.
MET-316062010.A1
316062010
|
-
|
|
|
|
111 - WASHER
MET-141151940.A260
141151940
|
£1.50
|
£1.80
|
|
|
112 - CAP SCREW
MET-141113840.A78
141113840
|
£3.20
|
£3.84
|
|
|
113 - INSERT SET
MET-316063130.A0
316063130
|
-
|
|
|
|
114 - FLEXIBLE SHAFT
MET-345000170.A1
345000170
|
£79.43
|
£95.32
|
|
|
115 - GEAR COVER
MET-316063110.A1
316063110
|
-
|
|
|
|
116 - SELF-TAPP. COUNTERS. SCREW
MET-141119430.A1
141119430
|
£1.50
|
£1.80
|
|
|
117 - CONNECTING SLEEVE
MET-316062390.A0
316062390
|
-
|
|
|
|
120 - TOROIDAL FERRITE
MET-143160180.A3
143160180
|
-
|
|
|
|
121 - BEARING FLANGE
MET-315202920.A1
315202920
|
-
|
|
|
|
122 - RETAINING RING
MET-141180060.A121
141180060
|
£1.50
|
£1.80
|
|
|
123 - BALL BEARING 12X28X8
MET-143111440.A40
143111440
|
£26.35
|
£31.62
|
|
|
124 - SHAFT SEALING RING
MET-143194880.A9
143194880
|
-
|
|
|
|
125 - INTERMEDIATE PIECE
MET-341013440.A0
341013440
|
-
|
|
|
|
126 - RETAINING RING
MET-141180360.A17
141180360
|
£3.20
|
£3.84
|
|
|
127 - DRIVE SHAFT
MET-341211150.A0
341211150
|
-
|
|
|
|
199 - FLEXIBLE SHAFT CORE PACKED
MET-316064470.A1
316064470
|
£36.59
|
£43.91
|
|
|
880 - GREASE 50GR 1.8oz
MET-344130930.A114
344130930
|
£36.59
|
£43.91
|
|
|
1001 - WIRING DIAGRAM 230V
MET-338506390.A0
338506390
|
-
|
|
|
