1 - ARMATURE COMPL. 120V
MET-310012240.A0
310012240
|
£79.43
|
£95.32
|
|
|
2 - FIELD COIL W.FIELD COIL 120 V
MET-311012010.A12
311012010
|
£61.08
|
£73.30
|
|
|
3 - SWITCH 2-POLE X2
MET-343410270.A35
343410270
|
£13.63
|
£16.36
|
|
|
4 - CABLE SLEEVE
MET-344101220.A78
344101220
|
£3.20
|
£3.84
|
|
|
5 - CABLE W.UL/CSA-PLUG 110V
MET-344499590.A5
344499590
|
-
|
|
|
|
6 - CABLE CLIP
MET-343362490.A766
343362490
|
£3.20
|
£3.84
|
|
|
7 - MOTOR HOUSING
MET-315013790.A21
315013790
|
£13.63
|
£16.36
|
|
|
8 - BAFFLE
MET-339151180.A101
339151180
|
£2.94
|
£3.53
|
|
|
9 - BAFFLE
MET-339151200.A277
339151200
|
£2.94
|
£3.53
|
|
|
10 - ELECTRONIC UNIT W.SWITCH
MET-316066540.A0
316066540
|
-
|
|
|
|
11 - BALL BEARING 6X19X6
MET-143115690.A228
143115690
|
£3.82
|
£4.59
|
|
|
12 - RUBBER BUSHING
MET-344097870.A129
344097870
|
£1.50
|
£1.80
|
|
|
13 - WASHER
MET-339133060.A98
339133060
|
£1.50
|
£1.80
|
|
|
14 - BALL BEARING 8X22X7
MET-143115700.A471
143115700
|
£4.76
|
£5.71
|
|
|
15 - WASHER
MET-339006390.A96
339006390
|
£1.50
|
£1.80
|
|
|
16 - HEXAGON NUT W.RECESS
MET-341102260.A56
341102260
|
-
|
|
|
|
18 - HANDLE 2 PART
MET-343439030.A13
343439030
|
£13.63
|
£16.36
|
|
|
20 - SWITCH TRIGGER COMPL.
MET-316065300.A11
316065300
|
-
|
|
|
|
21 - CLAMPING FLANGE
MET-341031290.A129
341031290
|
£9.62
|
£11.54
|
|
|
25 - WARNING LABEL 52X22
MET-338122090.A191
338122090
|
-
|
|
|
|
31 - GASKET
MET-339012200.A2
339012200
|
-
|
|
|
|
32 - FILL. HEAD SCREW(DIN 7985)
MET-141121640.A552
141121640
|
£1.50
|
£1.80
|
|
|
33 - SELF-TAP. FILL. H. SCREW
MET-141116980.A89
141116980
|
£1.50
|
£1.80
|
|
|
35 - SELF-TAP. FILL. H. SCREW
MET-141117060.A255
141117060
|
£3.20
|
£3.84
|
|
|
40 - SPINDLE 5/8
MET-341605300.A0
341605300
|
-
|
|
|
|
41 - FLANGE NUT
MET-341101480.A27
341101480
|
£11.78
|
£14.13
|
|
|
45 - SLOTTED DISC
MET-341070990.A12
341070990
|
£2.94
|
£3.53
|
|
|
46 - THUMBSCREW COMPL.
MET-341112690.A8
341112690
|
£2.94
|
£3.53
|
|
|
50 - BEARING FLANGE PRE-ASSEMBLED
MET-316063410.A2
316063410
|
-
|
|
|
|
51 - NUT
MET-341102460.A59
341102460
|
£3.82
|
£4.59
|
|
|
61 - RETAINING RING
MET-141156650.A209
141156650
|
£1.50
|
£1.80
|
|
|
62 - O-RING
MET-143196000.A0
143196000
|
-
|
|
|
|
63 - PRESSURE SPRING
MET-342003390.A41
342003390
|
£1.50
|
£1.80
|
|
|
64 - PUSH BUTTON
MET-343433640.A58
343433640
|
£1.50
|
£1.80
|
|
|
65 - BOLT
MET-341515640.A103
341515640
|
£2.94
|
£3.53
|
|
|
70 - TACHO DISC
MET-343433060.A68
343433060
|
£3.82
|
£4.59
|
|
|
73 - PRESSURE SPRING
MET-342004190.A11
342004190
|
-
|
|
|
|
80 - SCHUTZHAUBE VOLLST
MET-316051710.A0
316051710
|
£60.03
|
£72.04
|
|
|
81 - LOOP HANDLE COMPL.
MET-343399690.A36
343399690
|
£19.18
|
£23.02
|
|
|
82 - PIN SPANNER OFFSET
MET-344160700.A9
344160700
|
-
|
|
|
|
83 - RATING PLATE
MET-338067680.A0
338067680
|
-
|
|
|
|
84 - BEVEL GEAR W.PINION
MET-316054990.A9
316054990
|
£32.88
|
£39.45
|
|
|
85 - GEAR HOUSING COMPL.
MET-316066890.A0
316066890
|
-
|
|
|
|
86 - SAFETY CLUTCH
MET-316065010.A0
316065010
|
-
|
|
|
|
87 - BRUSH HOLDER SET
MET-316065420.A3
316065420
|
£17.55
|
£21.06
|
|
|
88 - FAN W. DUST GUARD
MET-316054850.A18
316054850
|
£5.62
|
£6.75
|
|
|
89 - CARBON BRUSH SET CUT-OFF
MET-316065460.A22
316065460
|
£15.41
|
£18.49
|
|
|
91 - COVER COMPL.
MET-316052780.A0
316052780
|
£22.96
|
£27.55
|
|
|
92 - WIRE STRAP
MET-342200680.A0
342200680
|
-
|
|
|
|
93 - PROTECTION PLATE
MET-339135870.A0
339135870
|
-
|
|
|
|
94 - PRESSURE SPRING
MET-342003810.A6
342003810
|
-
|
|
|
|
95 - TIGHTENING PIN
MET-141160850.A0
141160850
|
£1.50
|
£1.80
|
|
|
96 - WHEEL GUARD
MET-315418180.A1
315418180
|
-
|
|
|
|
97 - FILLISTER HEAD SCREW
MET-141123980.A10
141123980
|
-
|
|
|
|
98 - WASHER
MET-141150110.A79
141150110
|
£1.50
|
£1.80
|
|
|
99 - BRUSH COMPL. D 125
MET-344080650.A1
344080650
|
£22.61
|
£27.13
|
|
|
105 - V-RING VA 22 V6B01
MET-143195980.A2
143195980
|
£7.36
|
£8.83
|
|
|
124 - CARBONBRUSH WITH BRUSHOLDER SET 110V
MET-316066670.A44
316066670
|
£17.55
|
£21.06
|
|
|
880 - GREASE 100G
MET-344130920.A417
344130920
|
£19.18
|
£23.02
|
|
|
885 - GREASE SF 011 50GR 1.8oz
MET-344130560.A189
344130560
|
£19.18
|
£23.02
|
|
|
1001 - DIAGRAM
MET-338506170.A1
338506170
|
-
|
|
|
|
1005 - PART NOT NEEDED
MET-399999990.A1491
399999990
|
-
|
|
|
