2 - NO LONGER AVAILABLE IT 48 VOLT
BDE-000000-00.A39813
000000-00
|
-
|
|
|
|
3 - NO LONGER AVAILABLE IT 48 VOLT
BDE-000000-00.A39814
000000-00
|
-
|
|
|
|
6 - NO LONGER AVAILABLE
BDE-000000-00.A39815
000000-00
|
-
|
|
|
|
7 - NO LONGER AVAILABLE
BDE-000000-00.A39816
000000-00
|
-
|
|
|
|
8 - NO LONGER AVAILABLE
BDE-000000-00.A39817
000000-00
|
-
|
|
|
|
9 - SCREW
BDE-860084-09.A24
860084-09
|
£1.50
|
£1.80
|
|
|
10 - NO LONGER AVAILABLE
BDE-000000-00.A39818
000000-00
|
-
|
|
|
|
11 - LEVER
BDE-932315-00.A3
932315-00
|
£3.22
|
£3.86
|
|
|
12 - SPRING
BDE-932313-00.A3
932313-00
|
£5.72
|
£6.87
|
|
|
13 - COVER
BDE-932317-00.A5
932317-00
|
£3.70
|
£4.44
|
|
|
14 - PIN
BDE-932314-00.A5
932314-00
|
£1.42
|
£1.70
|
|
|
15 - SPRING
BDE-931013-00.A9
931013-00
|
£1.42
|
£1.70
|
|
|
16 - SCREW
BDE-860093-11.A4
860093-11
|
£1.50
|
£1.80
|
|
|
18 - WASHER
BDE-932293-00.A4
932293-00
|
£1.50
|
£1.80
|
|
|
19 - NO LONGER AVAILABLE
BDE-000000-00.A39819
000000-00
|
-
|
|
|
|
20 - NO LONGER AVAILABLE
BDE-000000-00.A39820
000000-00
|
-
|
|
|
|
21 - NO LONGER AVAILABLE
BDE-000000-00.A39821
000000-00
|
-
|
|
|
|
22 - NO LONGER AVAILABLE
BDE-000000-00.A39822
000000-00
|
-
|
|
|
|
23 - WASHER
BDE-932287-00.A2
932287-00
|
£1.42
|
£1.70
|
|
|
24 - SPINDLE & GEAR SA
BDE-869219-00.A2
869219-00
|
£135.36
|
£162.43
|
|
|
25 - WASHER
BDE-932286-00.A7
932286-00
|
£2.71
|
£3.25
|
|
|
26 - SPINDLE & GEAR SA
BDE-869219-02.A7
869219-02
|
£101.69
|
£122.03
|
|
|
27 - WASHER
BDE-932285-00.A2
932285-00
|
£3.30
|
£3.96
|
|
|
28 - PLATE
BDE-932288-00.A7
932288-00
|
£1.50
|
£1.80
|
|
|
29 - SEAL
BDE-930039.A22
930039
|
£1.42
|
£1.70
|
|
|
30 - WASHER
BDE-932289-00.A2
932289-00
|
£1.42
|
£1.70
|
|
|
31 - LEVER SA
BDE-932265-00.A7
932265-00
|
£29.32
|
£35.18
|
|
|
32 - SPRING
BDE-932290-00.A9
932290-00
|
£1.78
|
£2.13
|
|
|
33 - SPRING
BDE-932291-00.A2
932291-00
|
£4.58
|
£5.49
|
|
|
34 - SCREW
BDE-932408-00.A0
932408-00
|
£1.42
|
£1.70
|
|
|
35 - WASHER
BDE-931429-00.A7
931429-00
|
£3.30
|
£3.96
|
|
|
36 - EJECTOR
BDE-932304-00.A3
932304-00
|
-
|
|
|
|
37 - NO LONGER AVAILABLE
BDE-000000-00.A39823
000000-00
|
-
|
|
|
|
38 - CAP
BDE-932308-01.A2
932308-01
|
-
|
|
|
|
39 - GASKET
BDE-932312-00.A6
932312-00
|
£1.42
|
£1.70
|
|
|
40 - PIN
BDE-932301-00.A5
932301-00
|
-
|
|
|
|
41 - GEARCASE COVER SA
BDE-943963-00.A2
943963-00
|
£59.41
|
£71.29
|
|
|
42 - SEAL
BDE-932311-00.A3
932311-00
|
£2.21
|
£2.65
|
|
|
43 - RING
BDE-931052-00.A13
931052-00
|
£1.42
|
£1.70
|
|
|
44 - RING
BDE-930940-00.A5
930940-00
|
£3.22
|
£3.86
|
|
|
45 - BEARING
BDE-330003-11.A17
330003-11
|
£10.85
|
£13.02
|
|
|
46 - CIRCLIP
BDE-949729-02.A4
949729-02
|
£1.50
|
£1.80
|
|
|
47 - WASHER
BDE-932309-00.A11
932309-00
|
£1.50
|
£1.80
|
|
|
48 - SPACER
BDE-930073-00.A5
930073-00
|
£1.42
|
£1.70
|
|
|
49 - BEARING
BDE-577745-00.A131
577745-00
|
£7.85
|
£9.42
|
|
|
50 - SLEEVE
BDE-934409-00.A5
934409-00
|
-
|
|
|
|
51 - BAFFLE
BDE-930072-00.A10
930072-00
|
£2.21
|
£2.65
|
|
|
52 - SCREW
BDE-930246-00.A2
930246-00
|
£1.42
|
£1.70
|
|
|
53 - WASHER
BDE-761035-00.A25
761035-00
|
£1.42
|
£1.70
|
|
|
54 - WASHER
BDE-949876-08.A10
949876-08
|
£1.50
|
£1.80
|
|
|
55 - FIELDCASE
BDE-932261-01.A3
932261-01
|
-
|
|
|
|
57 - SCREW
BDE-930251-00.A7
930251-00
|
£1.42
|
£1.70
|
|
|
58 - NO LONGER AVAILABLE
BDE-000000-00.A39824
000000-00
|
-
|
|
|
|
59 - SCREW
BDE-930242-00.A2
930242-00
|
£1.42
|
£1.70
|
|
|
60 - BASEPLATE SA
BDE-930269-00.A2
930269-00
|
£3.22
|
£3.86
|
|
|
61 - SPRING
BDE-930099-00.A14
930099-00
|
-
|
|
|
|
62 - BLOCK
BDE-932307-00.A12
932307-00
|
£1.42
|
£1.70
|
|
|
63 - PLATE
BDE-932320-00.A7
932320-00
|
£7.64
|
£9.17
|
|
|
64 - SCREW
BDE-932319-00.A1
932319-00
|
£1.42
|
£1.70
|
|
|
65 - NO LONGER AVAILABLE IT 48 VOLT
BDE-000000-00.A39825
000000-00
|
-
|
|
|
|
66 - PIN
BDE-932406-00.A7
932406-00
|
£1.42
|
£1.70
|
|
|
67 - RING
BDE-932268-00.A3
932268-00
|
£3.22
|
£3.86
|
|
|
68 - ROLLER
BDE-932405-00.A1
932405-00
|
£1.42
|
£1.70
|
|
|
69 - SCREW
BDE-930079-01.A119
930079-01
|
£1.42
|
£1.70
|
|
|
70 - SWITCH REVERSE
BDE-932403-00.A8
932403-00
|
£23.75
|
£28.50
|
|
|
71 - NO LONGER AVAILABLE
BDE-000000-00.A39826
000000-00
|
-
|
|
|
|
72 - NO LONGER AVAILABLE
BDE-000000-00.A39827
000000-00
|
-
|
|
|
|
79 - CORD CLAMP IT 48 VOLT
BDE-930103-00.A146
930103-00
|
£1.50
|
£1.80
|
|
|
80 - CORD PROTECTOR IT 48 VOLT
BDE-930981-00.A24
930981-00
|
£1.42
|
£1.70
|
|
