1 - MOTOR HOUSING
BSD-1605108119.A5
1605108119
|
-
|
|
|
|
2 - BRUSH HOLDER
BSD-1604336008.A70
1604336008
|
£21.52
|
£25.83
|
|
|
3 - POLE SHOE 240V
BSD-1604220111.A2
1604220111
|
-
|
|
|
|
3/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A175
1901350003
|
£1.75
|
£2.10
|
|
|
4 - ARMATURE 240V
BSD-1604011136.A0
1604011136
|
-
|
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A289
1604652015
|
£2.80
|
£3.36
|
|
|
8 - SEALING CAP
BSD-1605500089.A252
1605500089
|
-
|
|
|
|
9 - HANDLE
BSD-1605132093.A3
1605132093
|
-
|
|
|
|
10/10 - SEALING WASHER DIN 85-AM 4x8-4.8
BSD-2916091118.A4
2916091118
|
-
|
|
|
|
11 - SEAL
BSD-1600113002.A292
1600113002
|
£1.75
|
£2.10
|
|
|
12 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A963
3600703011
|
£2.80
|
£3.36
|
|
|
13 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07RN-F
BSD-1604460203.A4
1604460203
|
£33.74
|
£40.49
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A419
1607328034
|
£4.26
|
£5.11
|
|
|
15 - FASTENING CLAMP
BSD-1601302013.A148
1601302013
|
£1.75
|
£2.10
|
|
|
17 - COVER PLATE
BSD-1601037009.A11
1601037009
|
-
|
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A143
1601014005
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026058.A28
1602026058
|
-
|
|
|
|
19/00/08 - FELT WASHER
BSD-1600205019.A216
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A124
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A66
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A63
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A192
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A376
1600306001
|
£2.61
|
£3.13
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A881
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A19
1600206020
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502017.A50
1600502017
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A145
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A145
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A232
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A51
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A216
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A21
1600206015
|
£2.16
|
£2.59
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A6
1601110003
|
-
|
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A166
1900905227
|
-
|
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A67
1900905234
|
£31.64
|
£37.97
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A172
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1086
2910021118
|
£1.75
|
£2.10
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A243
2910021050
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A694
2910211006
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A499
2916011005
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A51
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A77
2910211220
|
-
|
|
|
|
59 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A334
1613435009
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A164
2910211036
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A188
2910011162
|
£1.75
|
£2.10
|
|
|
62 - HEX NUT
BSD-1603300018.A7
1603300018
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A86
1603435006
|
-
|
|
|
|
65 - SPRING WASHER DIN 137-A4
BSD-1600150006.A322
1600150006
|
-
|
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A260
2910211018
|
£1.75
|
£2.10
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A622
2910021122
|
£2.16
|
£2.59
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A210
2910211011
|
£1.75
|
£2.10
|
|
|
91 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A26
2916060006
|
£1.32
|
£1.58
|
|
|
100 - GROOVED RING
BSD-1600390011.A71
1600390011
|
-
|
|
|
|
105 - STICKER
BSD-1601110240.A65
1601110240
|
-
|
|
|
|
150 - END SPLICE
BSD-3604477009.A279
3604477009
|
£2.61
|
£3.13
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A133
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A562
1602025030
|
£18.96
|
£22.75
|
|
|
703 - PARTS SET
BSD-1607000140.A35
1607000140
|
-
|
|
|
|
703/11 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A219
2603450007
|
£5.58
|
£6.70
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A155
1607014103
|
£14.91
|
£17.89
|
|
|
803 - CONNECTING CABLE
BSD-1604440004.A186
1604440004
|
-
|
|
|
|
804 - CROWN GEAR Z=51
BSD-1606333223.A3
1606333223
|
-
|
|
|
|
805 - BEVEL GEAR Z=10
BSD-1606333224.A6
1606333224
|
-
|
|
|
|
813 - PARTS SET
BSD-1607000161.A16
1607000161
|
-
|
|
|
|
816 - PARTS SET
BSD-1607000905.A23
1607000905
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A20
1607000229
|
-
|
|
|
|
831 - ON-OFF SWITCH
BSD-1607200097.A31
1607200097
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A921
160111A3H3
|
£2.61
|
£3.13
|
|
