2 - GEAR HOUSING
BSD-2605808909.A3
2605808909
|
-
|
|
|
|
3 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A415
2603410049
|
£1.75
|
£2.10
|
|
|
3 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A429
2910021122
|
£2.16
|
£2.59
|
|
|
5 - HOUSING COVER
BSD-2605500017.A20
2605500017
|
-
|
|
|
|
6 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A18
2600905007
|
-
|
|
|
|
7 - CUPPED WASHER
BSD-2600500008.A123
2600500008
|
-
|
|
|
|
8 - FELT DISC
BSD-2600108020.A41
2600108020
|
-
|
|
|
|
9 - RECEPTACLE
BSD-2600400020.A8
2600400020
|
-
|
|
|
|
12 - SHIM 0.5 MM
BSD-2600101616.A98
2600101616
|
-
|
|
|
|
13 - NEEDLE-ROLLER CAGE
BSD-2600913036.A13
2600913036
|
£1.75
|
£2.10
|
|
|
14 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A94
2603201037
|
£2.61
|
£3.13
|
|
|
15 - TOOTHED GEAR Z=32
BSD-2606320016.A7
2606320016
|
-
|
|
|
|
16 - SHIM 1.0 MM
BSD-2600102653.A33
2600102653
|
£1.75
|
£2.10
|
|
|
17 - SHIM 0.5 MM
BSD-2600102652.A195
2600102652
|
£1.75
|
£2.10
|
|
|
18 - FORK LEVER
BSD-2601923000.A23
2601923000
|
-
|
|
|
|
20 - SHIM 0.3 MM
BSD-2600100515.A3
2600100515
|
£2.61
|
£3.13
|
|
|
20 - SHIM 0.5 MM
BSD-2600100516.A222
2600100516
|
£2.16
|
£2.59
|
|
|
23 - SHIM 0.1 MM
BSD-2600100625.A60
2600100625
|
-
|
|
|
|
23 - SHIM 0.2 MM
BSD-2600100626.A178
2600100626
|
-
|
|
|
|
23 - SHIM 0.5 MM
BSD-2600100628.A229
2600100628
|
£1.75
|
£2.10
|
|
|
24 - COUNTERWEIGHT
BSD-2601015030.A9
2601015030
|
-
|
|
|
|
25 - ECCENTRIC DISC
BSD-2601072901.A213
2601072901
|
£7.36
|
£8.83
|
|
|
27 - SHIM 0.2 MM
BSD-2600100575.A24
2600100575
|
£2.16
|
£2.59
|
|
|
27 - SHIM 0.3 MM
BSD-2600100576.A293
2600100576
|
-
|
|
|
|
27 - SHIM 0.5 MM
BSD-2600100577.A24
2600100577
|
£1.75
|
£2.10
|
|
|
28 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A184
2916080910
|
£2.16
|
£2.59
|
|
|
29 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A93
2916080008
|
-
|
|
|
|
30 - SEALING PLATE
BSD-2601015900.A35
2601015900
|
-
|
|
|
|
33 - NEEDLE-ROLLER CAGE
BSD-2600913010.A39
2600913010
|
-
|
|
|
|
34 - NEEDLE BEARING
BSD-2600917900.A193
2600917900
|
£8.67
|
£10.41
|
|
|
35 - SEALING PLATE
BSD-2601015039.A20
2601015039
|
-
|
|
|
|
36 - AIR ELIMINATOR
BSD-2602389001.A22
2602389001
|
-
|
|
|
|
37 - GEAR COVER
BSD-2605808902.A19
2605808902
|
-
|
|
|
|
37 - GEAR COVER
BSD-2605808901.A7
2605808901
|
-
|
|
|
|
38 - NEEDLE ROLLER A 3x15.8G2DIN5402
BSD-1903201044.A71
1903201044
|
£2.33
|
£2.80
|
|
|
39 - COMPRESSION SPRING
BSD-2604613000.A125
2604613000
|
£1.75
|
£2.10
|
|
|
40 - GUIDE
BSD-2601032014.A9
2601032014
|
-
|
|
|
|
42 - CLAMP SCREW
BSD-2603400000.A87
2603400000
|
£4.26
|
£5.11
|
|
|
43 - CLAMPING SADDLE
BSD-2602329011.A127
2602329011
|
£4.75
|
£5.70
|
|
|
44 - SLIDING PIECE 31/35 MM
BSD-2601321022.A52
2601321022
|
-
|
|
|
|
45 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9
BSD-2603421040.A184
2603421040
|
£1.75
|
£2.10
|
|
|
46 - SHIM 0.5 MM
BSD-2600101612.A329
2600101612
|
£1.75
|
£2.10
|
|
|
47 - SEAL RING 0.5 MM
BSD-2600290017.A198
2600290017
|
£1.75
|
£2.10
|
|
|
48 - SUPPORTING DISC 0.5 MM
BSD-2600112031.A184
2600112031
|
£1.75
|
£2.10
|
|
|
50 - PIVOT PIN
BSD-2603105015.A22
2603105015
|
-
|
|
|
|
51 - GUIDE ROLLER
BSD-2607001018.A26
2607001018
|
-
|
|
|
|
52 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A415
2916080007
|
£2.61
|
£3.13
|
|
|
55 - AXLE
BSD-2600326900.A6
2600326900
|
-
|
|
|
|
57 - SHIM 0.5 MM
BSD-2600100510.A26
2600100510
|
£2.61
|
£3.13
|
|
|
58 - LOCKING WASHER DIN 6799-2.3
BSD-2916080005.A127
2916080005
|
-
|
|
|
|
59 - SWITCH HANDLE
BSD-2607200042.A6
2607200042
|
-
|
|
|
|
60 - COMPRESSION SPRING
BSD-2604611023.A23
2604611023
|
-
|
|
|
|
61 - RATCHET SLEEVE
BSD-2600506002.A20
2600506002
|
-
|
|
|
|
62 - SHIM 0.5 MM
BSD-2600100568.A23
2600100568
|
£1.75
|
£2.10
|
|
|
62 - SHIM 1.0 MM
BSD-2600100569.A310
2600100569
|
£1.75
|
£2.10
|
|
|
62 - SHIM 0.3 MM
BSD-2600100570.A4
2600100570
|
£1.75
|
£2.10
|
|
|
63 - BASE PLATE
BSD-2601016045.A2
2601016045
|
-
|
|
|
|
64 - COUNTERSUNK-HEAD SCREW M 5x10 DIN 963-5.8
BSD-2910771152.A25
2910771152
|
-
|
|
|
|
65 - FLANGED FITTING
BSD-2605702000.A6
2605702000
|
-
|
|
|
|
66 - HANDLE
BSD-2603231002.A22
2603231002
|
£14.91
|
£17.89
|
|
|
67 - RATCHET SLEEVE
BSD-2600421000.A49
2600421000
|
£7.36
|
£8.83
|
|
|
68 - COMPRESSION SPRING
BSD-2604616001.A22
2604616001
|
£1.75
|
£2.10
|
|
|
69 - SCREW AND WASHER ASSEMBLY
BSD-2914501015.A8
2914501015
|
-
|
|
|
|
69 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A209
2910021154
|
£1.75
|
£2.10
|
|
|
71 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A135
2916660010
|
£1.75
|
£2.10
|
|
|
72 - SPACER SLEEVE
BSD-2600309009.A165
2600309009
|
£1.75
|
£2.10
|
|
|
73 - HEX NUT DIN 439-BM 4-04
BSD-2915051104.A31
2915051104
|
-
|
|
|
|
80 - SINTERED-METAL BUSHING
BSD-2600301046.A129
2600301046
|
£3.72
|
£4.47
|
|
|
81 - BUSHING
BSD-2600301045.A98
2600301045
|
£2.80
|
£3.36
|
|
|
82 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A9
1903201042
|
£2.16
|
£2.59
|
|
|
101 - MOTOR HOUSING
BSD-2605108902.A9
2605108902
|
-
|
|
|
|
102 - COVER DISC
BSD-2600522009.A57
2600522009
|
-
|
|
|
|
103 - POLE SHOE 110V
BSD-2604220372.A0
2604220372
|
-
|
|
|
|
104 - COMPRESSION SPRING
BSD-2604611024.A4
2604611024
|
£2.16
|
£2.59
|
|
|
105 - COMMUTATOR END SHIELD
BSD-2605808910.A13
2605808910
|
-
|
|
|
|
106 - SQUARE NUT M4
BSD-2603320001.A208
2603320001
|
£1.75
|
£2.10
|
|
|
108 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A547
2910021125
|
£1.75
|
£2.10
|
|
|
113 - SPIRAL SPRING
BSD-2604652000.A198
2604652000
|
-
|
|
|
|
115 - SOCKET HEAD CAP SCREW
BSD-2603410010.A409
2603410010
|
-
|
|
|
|
116 - NAMEPLATE
BSD-2601100038.A72
2601100038
|
-
|
|
|
|
117 - ARMATURE WITH FAN 110V
BSD-2604010502.A0
2604010502
|
-
|
|
|
|
118 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A255
1900905019
|
£14.91
|
£17.89
|
|
|
120 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A145
2910211004
|
-
|
|
|
|
122 - FAN
BSD-2606610016.A14
2606610016
|
-
|
|
|
|
123 - SUPPRESSION CAPACITOR
BSD-2607329076.A5
2607329076
|
-
|
|
|
|
124 - ON-OFF SWITCH
BSD-2607200076.A10
2607200076
|
-
|
|
|
|
125 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1835
2603410001
|
£1.75
|
£2.10
|
|
|
126 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A180
2604460053
|
-
|
|
|
|
127 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A138
2600703012
|
£2.80
|
£3.36
|
|
|
127 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A877
2600703013
|
£2.61
|
£3.13
|
|
|
127 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A902
2600703011
|
£2.80
|
£3.36
|
|
|
128 - CABLE CLIP
BSD-2601035001.A1792
2601035001
|
£1.75
|
£2.10
|
|
|
129 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1011
2910211019
|
£1.75
|
£2.10
|
|
|
130 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A209
1601110013
|
-
|
|
|
|
131 - HOUSING COVER
BSD-2600508001.A7
2600508001
|
-
|
|
|
|
132 - REC CT-SUNK TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601020.A16
2910601020
|
-
|
|
|
|
132 - TAPPING SCREW DIN 7971-3.9x38
BSD-2910215093.A27
2910215093
|
-
|
|
|
|
135 - SWITCH HANDLE
BSD-2602026015.A53
2602026015
|
£1.75
|
£2.10
|
|
|
136 - ADJUSTING SLIDE
BSD-2602319004.A8
2602319004
|
-
|
|
|
|
138 - INTERMEDIATE PIECE
BSD-1600026000.A28
1600026000
|
£1.75
|
£2.10
|
|
|
139 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A260
2910211005
|
£1.75
|
£2.10
|
|
|
144 - STICKER
BSD-2601110055.A24
2601110055
|
£4.26
|
£5.11
|
|
|
147 - CONNECTING CABLE L=80 MM
BSD-1614448014.A80
1614448014
|
£2.61
|
£3.13
|
|
|
148 - CABLE
BSD-2604448013.A5
2604448013
|
-
|
|
|
|
160 - STICKER
BSD-2601110041.A78
2601110041
|
-
|
|
|
|
664 - COOLANT TANK
BSD-2605405005.A17
2605405005
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604320902.A154
2604320902
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A706
1607000227
|
£23.86
|
£28.63
|
|
|
835/020 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A283
1900452012
|
£1.75
|
£2.10
|
|
|
841 - LIFTING ROD
BSD-2600780913.A44
2600780913
|
-
|
|
|
