3 - LUBRICATING FELT
BSD-1603212000.A41
1603212000
|
-
|
|
|
|
4 - HANDLE
BSD-3605132046.A92
3605132046
|
-
|
|
|
|
5 - FELT WASHER
BSD-1600205026.A131
1600205026
|
£2.61
|
£3.13
|
|
|
6/1 - STATOR 72V/300HZ
BSD-1604229184.A0
1604229184
|
-
|
|
|
|
6/1 - STATOR 42V/200HZ
BSD-1604229186.A2
1604229186
|
-
|
|
|
|
7 - AIR-DEFLECTOR RING
BSD-1600117001.A35
1600117001
|
£2.16
|
£2.59
|
|
|
9 - GROMMET dia5.5-dia8.3x75 MM
BSD-1600703012.A69
1600703012
|
£2.52
|
£3.02
|
|
|
10 - ELEC. CABLE W/CONNECTION
BSD-3604462048.A38
3604462048
|
-
|
|
|
|
11 - FASTENING CLAMP
BSD-1601302001.A143
1601302001
|
£1.75
|
£2.10
|
|
|
13 - SWITCH
BSD-1607200067.A51
1607200067
|
-
|
|
|
|
14 - REVERSING SWITCH
BSD-1607200066.A45
1607200066
|
£63.50
|
£76.20
|
|
|
15 - HOUSING COVER
BSD-3605500067.A9
3605500067
|
-
|
|
|
|
16 - NAMEPLATE
BSD-3601106053.A945
3601106053
|
£5.30
|
£6.36
|
|
|
17 - SHIM 0.3 MM
BSD-1420100666.A6
1420100666
|
-
|
|
|
|
18 - SPINDLE WITH GEAR Z=10/25
BSD-1606328062.A1
1606328062
|
-
|
|
|
|
21 - COMPRESSION SPRING
BSD-1604626001.A16
1604626001
|
-
|
|
|
|
23 - COUPLING HALF
BSD-3606455006.A5
3606455006
|
-
|
|
|
|
25/1 - SPRING LOCK WASHER
BSD-1600224011.A41
1600224011
|
-
|
|
|
|
27 - DRIVE SHAFT
BSD-1603124059.A10
1603124059
|
-
|
|
|
|
28 - CONICAL SPRING WASHER
BSD-1600501030.A120
1600501030
|
-
|
|
|
|
29 - GROOVE BALL BEARING 6x19x6
BSD-1900900428.A72
1900900428
|
£16.74
|
£20.09
|
|
|
30 - BEARING FLANGE
BSD-3605820057.A11
3605820057
|
-
|
|
|
|
31 - FELT WASHER
BSD-1600205025.A41
1600205025
|
-
|
|
|
|
32 - CYLINDRICAL GEAR Z=24
BSD-1606300001.A4
1606300001
|
-
|
|
|
|
33 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-8.8
BSD-2910021052.A56
2910021052
|
-
|
|
|
|
34 - O-RING 35.0x1.5 MM
BSD-1600210010.A74
1600210010
|
£2.80
|
£3.36
|
|
|
36 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A169
2916010409
|
-
|
|
|
|
37 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A187
2916060003
|
£1.32
|
£1.58
|
|
|
38 - SPRING WASHER
BSD-3600150009.A11
3600150009
|
£2.80
|
£3.36
|
|
|
38 - SPRING WASHER DIN 137-A4
BSD-1600150006.A415
1600150006
|
-
|
|
|
|
40 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A130
1903230003
|
£2.61
|
£3.13
|
|
|
41 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A729
1903230007
|
£1.75
|
£2.10
|
|
|
42 - SINTERED-METAL BUSHING J4G7x8R6x6DIN1850
BSD-1900301003.A68
1900301003
|
-
|
|
|
|
43 - TAPPING SCREW DIN 7971-BZ4.2x13
BSD-2910211025.A113
2910211025
|
£1.75
|
£2.10
|
|
|
44 - PAN HEAD SCREW DIN 85-AM3.5x15-4.8
BSD-2910091046.A84
2910091046
|
£1.75
|
£2.10
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM3x6-5.8
BSD-2910011048.A109
2910011048
|
£1.75
|
£2.10
|
|
|
46 - TAPPING SCREW DIN 7971-BZ3.5x19
BSD-2910211013.A44
2910211013
|
-
|
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-BM3x55-8.8
BSD-2910021076.A17
2910021076
|
-
|
|
|
|
48 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A46
2910110118
|
£1.75
|
£2.10
|
|
|
49 - DRIVE SHAFT
BSD-1603123013.A33
1603123013
|
-
|
|
|
|
50 - COUPLING HALF
BSD-1608710002.A10
1608710002
|
-
|
|
|
|
51 - COMPRESSION SPRING
BSD-1604618001.A1
1604618001
|
-
|
|
|
|
52 - BACKUP RING
BSD-1600222008.A27
1600222008
|
-
|
|
|
|
53 - RETAINING SNAP RING
BSD-1600200011.A33
1600200011
|
-
|
|
|
|
54 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A361
1903230004
|
£2.16
|
£2.59
|
|
|
55 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A728
1903230007
|
£1.75
|
£2.10
|
|
|
56 - ROTOR WITHOUT WINDING
BSD-1604080053.A30
1604080053
|
£134.16
|
£160.99
|
|
|
57 - CONICAL SPRING WASHER
BSD-1600501030.A119
1600501030
|
-
|
|
|
|
58 - GROOVE BALL BEARING 6x19x6
BSD-1900900428.A73
1900900428
|
£16.74
|
£20.09
|
|
|
59 - FELT WASHER
BSD-1600205025.A42
1600205025
|
-
|
|
|
|
60 - GEAR HOUSING
BSD-3605806105.A11
3605806105
|
£103.14
|
£123.77
|
|
|
61 - SHIM 0.60 MM
BSD-3600101016.A68
3600101016
|
-
|
|
|
|
62 - INTERMEDIATE RING
BSD-1600300044.A87
1600300044
|
-
|
|
|
|
63 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-8.8
BSD-2910021052.A57
2910021052
|
-
|
|
|
|
75 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A409
2912081116
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A53
3601119236
|
£3.72
|
£4.47
|
|
|
703 - QUICK-CHANGE COLLET CHUCK 1/4
BSD-3608120002.A18
3608120002
|
-
|
|
|
|
710 - COUPLING HALF 3/8
BSD-3606455004.A39
3606455004
|
-
|
|
|
|
711 - SUSPENSION LOOP
BSD-3604682001.A45
3604682001
|
-
|
|
|
|
712 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A748
2910021118
|
£1.75
|
£2.10
|
|
|
800 - INTERMEDIATE BEARING
BSD-1605820126.A9
1605820126
|
-
|
|
|
|
802 - COUPLING HALF
BSD-3606455021.A28
3606455021
|
-
|
|
|
