1 - MOTOR HOUSING
BSD-3600760010.A1
3600760010
|
£63.50
|
£76.20
|
|
2 - STATOR 120W
BSD-3604090017.A21
3604090017
|
£81.81
|
£98.17
|
|
3 - ROTOR
BSD-3604220013.A4
3604220013
|
£102.57
|
£123.08
|
|
5 - BEARING FLANGE
BSD-3605700023.A5
3605700023
|
£23.86
|
£28.63
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A1274
2600905032
|
£5.30
|
£6.36
|
|
7 - BEARING FLANGE
BSD-3605700022.A14
3605700022
|
£72.18
|
£86.62
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A26
1900905030
|
£33.74
|
£40.49
|
|
11 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A226
2916011011
|
£1.75
|
£2.10
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A210
2911061150
|
£2.61
|
£3.13
|
|
26 - PINION
BSD-3606300011.A1
3606300011
|
£33.74
|
£40.49
|
|
27 - STOP DISC
BSD-3600101008.A77
3600101008
|
£1.75
|
£2.10
|
|
28 - RING GEAR
BSD-3606334007.A3
3606334007
|
£63.50
|
£76.20
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A434
3600913000
|
£4.26
|
£5.11
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A30
3603201000
|
£1.75
|
£2.10
|
|
34 - STOP DISC
BSD-3600103003.A13
3600103003
|
£2.80
|
£3.36
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A128
3600905002
|
£16.41
|
£19.69
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337028.A3
3606337028
|
£102.57
|
£123.08
|
|
39 - CYLINDRICAL GEAR
BSD-3606316112.A54
3606316112
|
£21.68
|
£26.01
|
|
41 - GROOVE BALL BEARING 10x22x6
BSD-3600905003.A2
3600905003
|
-
|
|
|
43 - SPRING RETAINING RING
BSD-3600119001.A12
3600119001
|
-
|
|
|
44 - THREADED BUSHING
BSD-3600390003.A79
3600390003
|
£12.04
|
£14.45
|
|
45 - RADIAL SEAL
BSD-3600283003.A2
3600283003
|
-
|
|
|
46 - THREADED RING
BSD-3603344005.A1
3603344005
|
£14.91
|
£17.89
|
|
56 - CONNECTION HOUSING
BSD-3605190040.A1
3605190040
|
-
|
|
|
57 - PROTECTIVE CAP
BSD-1820516004.A4
1820516004
|
-
|
|
|
66 - STRAIGHT PIN
BSD-3603201014.A2
3603201014
|
£11.30
|
£13.56
|
|
95 - NAMEPLATE
BSD-160111A3HF.A194
160111A3HF
|
£3.72
|
£4.47
|
|
97 - GROOVED NAIL
BSD-3603133000.A40
3603133000
|
£2.61
|
£3.13
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1815
3601119236
|
£3.72
|
£4.47
|
|
700 - HOSE FITTING
BSD-3603386002.A31
3603386002
|
£3.34
|
£4.01
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031059.A3
3607031059
|
£306.65
|
£367.98
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030259.A22
3607030259
|
£31.64
|
£37.97
|
|
