1 - MOTOR HOUSING
BSD-3605108177.A12
3605108177
|
£31.64
|
£37.97
|
|
|
2 - STATOR 180W
BSD-3604090050.A11
3604090050
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220080.A3
3604220080
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700107.A87
3605700107
|
£37.27
|
£44.72
|
|
|
6 - GROOVE BALL BEARING 7x19x6
BSD-1900905044.A95
1900905044
|
£7.36
|
£8.83
|
|
|
7 - BEARING FLANGE
BSD-3605700148.A10
3605700148
|
£59.53
|
£71.44
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A179
1900905028
|
£33.74
|
£40.49
|
|
|
9 - INSERT PIPE
BSD-3600700200.A2
3600700200
|
£93.88
|
£112.65
|
|
|
26 - PINION Z=15
BSD-3606300018.A18
3606300018
|
£27.31
|
£32.77
|
|
|
27 - STOP DISC
BSD-3600101047.A169
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR dia19.5 MM
BSD-3606334085.A50
3606334085
|
£8.67
|
£10.41
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337181.A5
3606337181
|
£48.38
|
£58.06
|
|
|
30 - SPACER RING
BSD-3600209013.A32
3600209013
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A5
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A211
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A421
3603201000
|
£1.75
|
£2.10
|
|
|
34 - INTERMEDIATE HOUSING
BSD-3600700050.A1
3600700050
|
£23.86
|
£28.63
|
|
|
35 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A290
1903201042
|
£2.16
|
£2.59
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337191.A13
3606337191
|
£63.50
|
£76.20
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A72
3606316114
|
£13.12
|
£15.75
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905023.A11
3600905023
|
£21.52
|
£25.83
|
|
|
43 - SUPPORTING DISC
BSD-3600100084.A10
3600100084
|
£3.72
|
£4.47
|
|
|
56 - FITTING
BSD-3603462007.A33
3603462007
|
£7.36
|
£8.83
|
|
|
57 - SEALING DISK
BSD-3600206005.A30
3600206005
|
£5.30
|
£6.36
|
|
|
58 - SHIM WASHER
BSD-3600105001.A10
3600105001
|
£1.75
|
£2.10
|
|
|
60 - STRAINER
BSD-3600002006.A85
3600002006
|
£3.72
|
£4.47
|
|
|
61 - SILENCER
BSD-3603462000.A161
3603462000
|
£16.41
|
£19.69
|
|
|
62 - SCREENING RING
BSD-3600521002.A29
3600521002
|
£2.80
|
£3.36
|
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A104
1900210112
|
£2.61
|
£3.13
|
|
|
66 - STRAIGHT PIN
BSD-3603201009.A35
3603201009
|
£5.58
|
£6.70
|
|
|
67 - HALF-LENGTH GROOVED PIN ISO 8741-2x10-ST
BSD-2917690036.A9
2917690036
|
£1.75
|
£2.10
|
|
|
68 - VALVE CONE
BSD-3608750021.A7
3608750021
|
£4.26
|
£5.11
|
|
|
69 - STRAIGHT PIN DIN 6325-3M6x32
BSD-2917550088.A18
2917550088
|
£1.75
|
£2.10
|
|
|
73 - O-RING 25.0x2.0 MM
BSD-3600210122.A5
3600210122
|
£4.26
|
£5.11
|
|
|
74 - O-RING 1.8x1.2 MM
BSD-3600210105.A12
3600210105
|
£2.61
|
£3.13
|
|
|
75 - STRAIGHT PIN
BSD-3603100029.A7
3603100029
|
£18.96
|
£22.75
|
|
|
76 - PUSH-BUTTON
BSD-3602033005.A11
3602033005
|
£3.72
|
£4.47
|
|
|
77 - COMPRESSION SPRING
BSD-3604610016.A10
3604610016
|
£10.10
|
£12.12
|
|
|
78 - O-RING 16.0x1.0 MM
BSD-3600210104.A15
3600210104
|
£1.75
|
£2.10
|
|
|
79 - SCREW PLUG
BSD-3600313011.A13
3600313011
|
£3.72
|
£4.47
|
|
|
80 - TAPPING SCREW DIN 7982-ST2.9x16-F-Z
BSD-2912411407.A9
2912411407
|
£1.75
|
£2.10
|
|
|
81 - HOUSING
BSD-3608750045.A5
3608750045
|
£8.67
|
£10.41
|
|
|
82 - CHANGEOVER LEVER
BSD-3602000002.A2
3602000002
|
£3.72
|
£4.47
|
|
|
83 - COMPRESSION SPRING
BSD-3604619017.A8
3604619017
|
£1.75
|
£2.10
|
|
|
84 - HOUSING COVER
BSD-3605500147.A10
3605500147
|
£6.52
|
£7.83
|
|
|
87 - SILENCER
BSD-3601010010.A6
3601010010
|
£2.16
|
£2.59
|
|
|
91 - SUPPORTING DISC
BSD-2600100648.A5
2600100648
|
£3.72
|
£4.47
|
|
|
92 - REFERENCE PLATE
BSD-3601110574.A5
3601110574
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A399
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119136.A16
3601119136
|
£4.26
|
£5.11
|
|
|
99 - STICKER
BSD-3601110572.A9
3601110572
|
-
|
|
|
|
100 - HOUSING
BSD-3605125054.A30
3605125054
|
£45.67
|
£54.80
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445043.A156
3606445043
|
£102.57
|
£123.08
|
|
|
102 - OUTPUT SHAFT
BSD-3603124023.A74
3603124023
|
£68.42
|
£82.10
|
|
|
106 - COMPRESSION SPRING
BSD-3604610011.A10
3604610011
|
£2.80
|
£3.36
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A121
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3600224053.A29
3600224053
|
£1.75
|
£2.10
|
|
|
113 - CLAMP BUSHING
BSD-3600499023.A75
3600499023
|
£18.96
|
£22.75
|
|
|
114 - PLAIN BEARING
BSD-3600921001.A115
3600921001
|
£10.10
|
£12.12
|
|
|
115 - SEALING PLATE
BSD-3601023011.A124
3601023011
|
£2.61
|
£3.13
|
|
|
116 - SETTING RING
BSD-3600134014.A81
3600134014
|
£31.64
|
£37.97
|
|
|
119 - SUPPORT DISC
BSD-3600190038.A47
3600190038
|
£18.96
|
£22.75
|
|
|
120 - CATCH DISK
BSD-3603344047.A41
3603344047
|
£23.86
|
£28.63
|
|
|
121 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A227
1903230003
|
£2.61
|
£3.13
|
|
|
125 - BACKUP RING
BSD-3600202020.A21
3600202020
|
£8.67
|
£10.41
|
|
|
126 - RETAINING RING
BSD-3600224006.A183
3600224006
|
£2.80
|
£3.36
|
|
|
127 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A176
1903230006
|
£2.16
|
£2.59
|
|
|
128 - BALL 4.5 MM III DIN 5401-ST
BSD-1903230008.A61
1903230008
|
£1.75
|
£2.10
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A228
1903230003
|
£2.61
|
£3.13
|
|
|
133 - WASHER
BSD-3600190024.A11
3600190024
|
£2.16
|
£2.59
|
|
|
140 - LOCKING WASHER DIN 6799-9-FSt
BSD-2916080012.A93
2916080012
|
£1.75
|
£2.10
|
|
|
141 - PROTECTION SLEEVE
BSD-3600400022.A34
3600400022
|
£18.96
|
£22.75
|
|
|
143 - O-RING 9.0x1.2 MM
BSD-3600210038.A128
3600210038
|
£2.61
|
£3.13
|
|
|
145 - O-RING
BSD-3600210116.A22
3600210116
|
£2.80
|
£3.36
|
|
|
146 - STRAIGHT PIN
BSD-3604710069.A3
3604710069
|
£4.26
|
£5.11
|
|
|
652 - HOSE FITTING
BSD-3603386066.A82
3603386066
|
£14.91
|
£17.89
|
|
|
654 - SUSPENSION LOOP
BSD-3601923019.A13
3601923019
|
£13.12
|
£15.75
|
|
|
657 - SCREWDRIVER
BSD-3607950027.A117
3607950027
|
£14.91
|
£17.89
|
|
|
706 - COMPRESSION SPRING
BSD-3604618003.A80
3604618003
|
£7.36
|
£8.83
|
|
|
753 - SILENCER
BSD-3607000074.A100
3607000074
|
£23.86
|
£28.63
|
|
|
801 - OVERRIDING CLUTCH
BSD-3607031501.A6
3607031501
|
£357.27
|
£428.72
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031505.A0
3607031505
|
£357.27
|
£428.72
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031304.A67
3607031304
|
£27.23
|
£32.68
|
|
|
868 - VALVE CONE
BSD-3608750042.A29
3608750042
|
£6.52
|
£7.83
|
|
|
876 - ASSEMBLY OF SERVICE PARTS
BSD-3607030332.A24
3607030332
|
£33.74
|
£40.49
|
|
