1 - MOTOR HOUSING
BSD-3605108109.A2
3605108109
|
£54.42
|
£65.30
|
|
|
2 - FIELD 220-230V
BSD-2604220429.A133
2604220429
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 220-230V
BSD-2604010629.A3
2604010629
|
£59.53
|
£71.44
|
|
|
3/10 - FAN
BSD-2606610049.A477
2606610049
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-2607200248.A7
2607200248
|
£68.42
|
£82.10
|
|
|
5 - ELEC. CABLE W/CONNECTION BR 2.65m 2 x 1.0mm H07RN-F
BSD-1604460282.A0
1604460282
|
£13.12
|
£15.75
|
|
|
6 - GROMMET dia7.3-dia8.6x67 MM
BSD-1600703031.A39
1600703031
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A324
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-3601110365.A2
3601110365
|
£2.33
|
£2.80
|
|
|
11 - O-RING 22.0x2.2 MM
BSD-3600210134.A3
3600210134
|
£2.16
|
£2.59
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329096.A21
2607329096
|
£7.36
|
£8.83
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A809
1900905018
|
£18.96
|
£22.75
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A470
2600905021
|
£8.67
|
£10.41
|
|
|
15 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A14
2603435015
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A215
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1532
2603490022
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-3601110367.A2
3601110367
|
£3.34
|
£4.01
|
|
|
21 - STRAIGHT PIN 4 H 8x12 DIN 7
BSD-2917500095.A80
2917500095
|
£1.75
|
£2.10
|
|
|
22 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A731
2600914010
|
£2.80
|
£3.36
|
|
|
23 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A732
2600914010
|
£2.80
|
£3.36
|
|
|
25 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A328
1613435034
|
£1.75
|
£2.10
|
|
|
26 - HOUSING COVER
BSD-3605500018.A3
3605500018
|
£7.36
|
£8.83
|
|
|
27 - BRUSH HOLDER
BSD-2604337003.A303
2604337003
|
£2.16
|
£2.59
|
|
|
28 - AIR-DEFLECTOR RING
BSD-3605500017.A8
3605500017
|
£6.61
|
£7.93
|
|
|
29 - COMPRESSION SPRING
BSD-2604611024.A145
2604611024
|
£2.16
|
£2.59
|
|
|
31 - SUPPORTING DISC
BSD-3600190003.A9
3600190003
|
£4.26
|
£5.11
|
|
|
32 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A547
2916660008
|
£2.16
|
£2.59
|
|
|
33 - SUSPENSION LOOP
BSD-2604682001.A16
2604682001
|
£6.61
|
£7.93
|
|
|
34 - RECEPTACLE
BSD-2600400008.A65
2600400008
|
£1.75
|
£2.10
|
|
|
35 - CYLINDRICAL GEAR Z=31
BSD-2606317001.A16
2606317001
|
£31.64
|
£37.97
|
|
|
39 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A114
1900900287
|
£21.68
|
£26.01
|
|
|
40 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A274
1903230007
|
£1.75
|
£2.10
|
|
|
41 - BUSHING
BSD-1605801018.A1
1605801018
|
£45.67
|
£54.80
|
|
|
43 - COMPRESSION SPRING
BSD-1604619010.A1
1604619010
|
£6.52
|
£7.83
|
|
|
44 - STRIKER
BSD-2608710001.A8
2608710001
|
£195.26
|
£234.31
|
|
|
45 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A144
1903230013
|
£2.16
|
£2.59
|
|
|
46 - DRIVE SHAFT
BSD-2603124002.A8
2603124002
|
£72.18
|
£86.62
|
|
|
49 - IMPACT MECHANISM HOUSING
BSD-3605190188.A1
3605190188
|
£93.88
|
£112.65
|
|
|
50 - PROTECTIVE RING
BSD-2600250005.A17
2600250005
|
£4.26
|
£5.11
|
|
|
51 - SPACER RING
BSD-3600113007.A1
3600113007
|
£2.16
|
£2.59
|
|
|
52 - CUPPED WASHER
BSD-2600500002.A288
2600500002
|
£1.75
|
£2.10
|
|
|
56 - SHIM 1.0 MM
BSD-2600100569.A63
2600100569
|
£1.75
|
£2.10
|
|
|
57 - FELT WASHER
BSD-2600108077.A221
2600108077
|
£1.75
|
£2.10
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A259
2910211020
|
£2.16
|
£2.59
|
|
|
61 - CABLE
BSD-3604431001.A2
3604431001
|
£2.61
|
£3.13
|
|
|
63 - SHIM
BSD-2600150004.A73
2600150004
|
£2.16
|
£2.59
|
|
|
64 - SHIM 0.3 MM
BSD-2600101023.A120
2600101023
|
£1.75
|
£2.10
|
|
|
64 - SHIM 0.2 MM
BSD-2600101022.A530
2600101022
|
£1.75
|
£2.10
|
|
|
64 - SHIM 0.5 MM
BSD-2600101020.A120
2600101020
|
£1.75
|
£2.10
|
|
|
65 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A222
2910141166
|
£1.75
|
£2.10
|
|
|
66 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A227
2916690004
|
£1.75
|
£2.10
|
|
|
67 - RETAINING RING
BSD-3600224063.A8
3600224063
|
£2.80
|
£3.36
|
|
|
71 - SUPPRESSION FILTER
BSD-3604503005.A5
3604503005
|
£10.10
|
£12.12
|
|
|
72 - SUPPRESSION FILTER
BSD-3604503006.A0
3604503006
|
£10.10
|
£12.12
|
|
|
73 - CABLE
BSD-3604431000.A8
3604431000
|
£5.58
|
£6.70
|
|
|
74 - CABLE
BSD-3604431019.A5
3604431019
|
£5.30
|
£6.36
|
|
|
75 - CABLE
BSD-3604431008.A9
3604431008
|
£5.58
|
£6.70
|
|
|
76 - CABLE
BSD-3604431020.A0
3604431020
|
£5.58
|
£6.70
|
|
|
78 - STRAIGHT PIN 4 H 8x24 DIN 7
BSD-2917500101.A23
2917500101
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-160111A3H6.A39
160111A3H6
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A550
2604321905
|
£11.30
|
£13.56
|
|
|
810 - CARBON-BRUSH SET 10 x 2 604 321 905
BSD-1607000484.A23
1607000484
|
£72.18
|
£86.62
|
|
|
837 - INTERMEDIATE BEARING
BSD-3605500187.A8
3605500187
|
£93.88
|
£112.65
|
|
|
838 - INTERMEDIATE FLANGE
BSD-3605700120.A16
3605700120
|
£37.27
|
£44.72
|
|
|
848 - TOOL HOLDING FIXTURE
BSD-3607030424.A1
3607030424
|
£135.25
|
£162.30
|
|
|
849 - IMPACT MECHANISM HOUSING
BSD-3605190188.A0
3605190188
|
£93.88
|
£112.65
|
|
|
853 - TOOTHED SHAFT
BSD-3606309058.A9
3606309058
|
£63.50
|
£76.20
|
|
|
859 - SWITCH
BSD-1617200042.A81
1617200042
|
£16.41
|
£19.69
|
|
|
859/10 - O-RING 33.0x2.0 MM
BSD-2600210019.A17
2600210019
|
£1.75
|
£2.10
|
|
|
868 - RETAINING RING
BSD-2600224007.A26
2600224007
|
£6.52
|
£7.83
|
|
|
869 - O-RING 7.65x1.78 MM
BSD-2600210001.A29
2600210001
|
£2.16
|
£2.59
|
|
