1 - MOTOR HOUSING
BSD-1605108152.A13
1605108152
|
-
|
|
|
|
1/2 - MOTOR HOUSING
BSD-1605108134.A0
1605108134
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-1604220354.A46
1604220354
|
£33.74
|
£40.49
|
|
|
3/50 - FAN
BSD-1606610122.A11
1606610122
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-2607200169.A10
2607200169
|
-
|
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A164
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A348
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A73
1601110483
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A588
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A364
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-1610905009.A77
1610905009
|
£14.72
|
£17.67
|
|
|
16 - BRUSH HOLDER
BSD-3604336001.A6
3604336001
|
-
|
|
|
|
21 - MANUFACTURER'S NAMEPLATE
BSD-1601110636.A6
1601110636
|
£2.61
|
£3.13
|
|
|
22 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A86
2912401019
|
£1.75
|
£2.10
|
|
|
24 - PROTECTIVE COVER
BSD-1605510157.A18
1605510157
|
£14.72
|
£17.67
|
|
|
26 - BEARING COVER
BSD-1605808062.A9
1605808062
|
-
|
|
|
|
27 - INTERMEDIATE RING
BSD-1600221003.A38
1600221003
|
£2.61
|
£3.13
|
|
|
28 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A226
2603410001
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591007.A29
1600591007
|
£2.61
|
£3.13
|
|
|
31 - SEALING CAP
BSD-1605500158.A4
1605500158
|
-
|
|
|
|
32 - INTERMEDIATE RING
BSD-1600502011.A74
1600502011
|
£2.61
|
£3.13
|
|
|
33 - SLOTTED SPRING PIN 6x22 DIN7346
BSD-2917780150.A33
2917780150
|
£1.75
|
£2.10
|
|
|
34 - COVER STRIP
BSD-1601099021.A1
1601099021
|
-
|
|
|
|
34 - COVER STRIP
BSD-1601099014.A4
1601099014
|
-
|
|
|
|
35 - HANDLE COVER
BSD-1605500159.A22
1605500159
|
-
|
|
|
|
35 - HANDLE COVER
BSD-1605500155.A1
1605500155
|
-
|
|
|
|
35/2 - HANDLE COVER
BSD-1605500134.A4
1605500134
|
-
|
|
|
|
36 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A152
2603435042
|
£1.75
|
£2.10
|
|
|
38 - MOUNTING PLATE
BSD-1600134005.A12
1600134005
|
-
|
|
|
|
39 - CONICAL SPRING WASHER SW 36
BSD-1605703079.A15
1605703079
|
-
|
|
|
|
40 - CONICAL SPRING WASHER dia 30 MM
BSD-1605703080.A1
1605703080
|
-
|
|
|
|
41 - THREAD-FORMING TAP. SCREW DIN 7500-M 4x12
BSD-2914491409.A88
2914491409
|
£1.66
|
£1.99
|
|
|
42 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A598
1900905163
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A301
2916660014
|
£1.75
|
£2.10
|
|
|
44 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A316
1603414007
|
£2.29
|
£2.75
|
|
|
45 - CYLINDRICAL GEAR Z=41
BSD-1606320076.A5
1606320076
|
-
|
|
|
|
46 - DRIVE SHAFT M6. dia16 MM
BSD-1603124112.A2
1603124112
|
-
|
|
|
|
47 - EXTENSION SPRING
BSD-1604649001.A33
1604649001
|
-
|
|
|
|
48 - NOZZLE SOCKET
BSD-1600910019.A20
1600910019
|
£3.34
|
£4.01
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM4x5-5.8
BSD-2910011115.A1
2910011115
|
£1.75
|
£2.10
|
|
|
50 - GUIDE BUSHING
BSD-1600309011.A26
1600309011
|
-
|
|
|
|
51 - BASE PLATE 358x151 MM
BSD-1608000107.A22
1608000107
|
-
|
|
|
|
52 - RUBBER BUFFER
BSD-1600305001.A60
1600305001
|
£1.75
|
£2.10
|
|
|
53 - SPACER BUSHING
BSD-1600309012.A4
1600309012
|
£1.75
|
£2.10
|
|
|
54 - RIVING KNIFE
BSD-1600025016.A4
1600025016
|
£4.75
|
£5.70
|
|
|
55 - WING NUT M6
BSD-1603339006.A145
1603339006
|
£2.52
|
£3.02
|
|
|
57 - PAN HEAD SCREW M6x170 MM
BSD-1603434005.A37
1603434005
|
-
|
|
|
|
58 - ADJUSTING PLATE
BSD-1601329017.A3
1601329017
|
-
|
|
|
|
61 - SPACER RING
BSD-1600201014.A6
1600201014
|
-
|
|
|
|
62 - PARTS SET
BSD-1607000197.A32
1607000197
|
-
|
|
|
|
63 - WING SCREW
BSD-1603480022.A31
1603480022
|
-
|
|
|
|
64 - ROUND-HEAD BOLT M6x35 MM
BSD-1603434006.A3
1603434006
|
-
|
|
|
|
65 - AUXILIARY HANDLE
BSD-1605133039.A1
1605133039
|
£8.49
|
£10.19
|
|
|
66 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A375
1907950006
|
£4.26
|
£5.11
|
|
|
67 - SUPPRESSOR BOX
BSD-1604503014.A27
1604503014
|
-
|
|
|
|
68 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A405
1600290016
|
£2.61
|
£3.13
|
|
|
69 - LOCKING RING
BSD-1600390013.A38
1600390013
|
£5.01
|
£6.01
|
|
|
70 - BLADE TERMINAL
BSD-1604477005.A53
1604477005
|
£2.61
|
£3.13
|
|
|
72 - PARTS SET
BSD-1607000223.A12
1607000223
|
-
|
|
|
|
73 - COMPRESSION SPRING
BSD-1604611029.A33
1604611029
|
£1.32
|
£1.58
|
|
|
74 - THREAD-FORMING TAP. SCREW TT M5x30 MM
BSD-1603435022.A20
1603435022
|
£1.75
|
£2.10
|
|
|
77 - PAN HEAD SCREW DIN 923-M4x10-5.8
BSD-2910271120.A18
2910271120
|
£1.32
|
£1.58
|
|
|
80 - OVAL-HEAD SCREW DIN 7985-M6x16-4.8
BSD-2910641197.A22
2910641197
|
-
|
|
|
|
81 - STOPPING DEVICE
BSD-1603231011.A32
1603231011
|
-
|
|
|
|
82 - O-RING 46.0x1.1 MM
BSD-3600210124.A266
3600210124
|
£2.80
|
£3.36
|
|
|
83 - REFERENCE PLATE
BSD-1601110470.A11
1601110470
|
£1.75
|
£2.10
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A58
1607014129
|
£16.41
|
£19.69
|
|
|
801 - SPIRAL SPRING
BSD-2604652008.A1
2604652008
|
-
|
|
|
|
804 - ON-OFF SWITCH
BSD-1607200088.A2
1607200088
|
-
|
|
|
|
805 - POWER SUPPLY CORD
BSD-1607000389.A24
1607000389
|
-
|
|
|
|
823 - COILED SPRING
BSD-1604651008.A17
1604651008
|
-
|
|
|
|
830 - ARMATURE WITH FAN 220-230V
BSD-1604010328.A2
1604010328
|
-
|
|
|
|
835 - HANDLE COVER
BSD-1607000925.A16
1607000925
|
-
|
|
|
|
836 - LOCKING LEVER
BSD-1602099003.A14
1602099003
|
-
|
|
|
|
837 - PIVOTING BLADE GUARD
BSD-1605510172.A36
1605510172
|
-
|
|
|
|
859 - PARTS SET
BSD-1607000197.A31
1607000197
|
-
|
|
|
|
872 - PARTS SET
BSD-1607000223.A13
1607000223
|
-
|
|
|
|
878 - PARTS SET
BSD-1607000192.A5
1607000192
|
-
|
|
|
|
878 - PARTS SET
BSD-1607000205.A74
1607000205
|
-
|
|
|
|
882 - SEALING DISK
BSD-1600135002.A4
1600135002
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1031
160111A3H3
|
£2.61
|
£3.13
|
|
