Bosch GRL 300 HVG / 3601K61700 / EU Spare Parts

An exploded drawing and listing for the Bosch GRL 300 HVG / 3601K61700 / EU

	Ex VAT	Inc VAT
1/2 - LENS MOUNT BSD-2610A13995.A0 2610A13995	£59.53	£71.44
1/3 - ROTATION UNIT BSD-2610A14000.A0 2610A14000	-
1/4 - ASSEMBLY BSD-2610A12340.A1 2610A12340	£72.18	£86.62
1/5 - BALL SLEEVE BSD-2610A12224.A4 2610A12224	£1.32	£1.58
1/6 - HEX SOCKET HEAD CAP SCREW BSD-2610A12461.A1 2610A12461	£1.75	£2.10
1/7 - HEX SOCKET HEAD CAP SCREW BSD-2610A12284.A21 2610A12284	£1.75	£2.10
1/1/1 - MOTOR HOUSING BSD-2610A12237.A1 2610A12237	£263.33	£316.00
1/1/2 - LEVELING ELEMENT BSD-2610A15782.A0 2610A15782	£306.65	£367.98
1/1/3 - LIMIT SWITCH BSD-2610A13397.A5 2610A13397	£1.75	£2.10
1/1/4 - SPECIAL WASHER BSD-2610A12269.A6 2610A12269	£2.61	£3.13
1/1/5 - HEX SOCKET HEAD CAP SCREW BSD-2610A12272.A5 2610A12272	£1.75	£2.10
1/1/6 - HEX SOCKET HEAD CAP SCREW BSD-2610A12284.A20 2610A12284	£1.75	£2.10
1/1/7 - FLEXIBLE PCB BSD-2610A12359.A3 2610A12359	£3.34	£4.01
1/1/8 - TAPPING SCREW BSD-2610A12301.A14 2610A12301	£1.75	£2.10
1/1/10 - LIMIT SWITCH BSD-2610A13399.A10 2610A13399	£1.75	£2.10
2 - HOUSING BSD-2610A12342.A3 2610A12342	-
3 - HOUSING BSD-2610A12957.A5 2610A12957	£27.23	£32.68
4 - HANDLE BSD-2610A12464.A1 2610A12464	£21.68	£26.01
5 - HANDLE BSD-2610A12309.A2 2610A12309	£21.68	£26.01
6 - BATTERY BOX ASSEMBLY BSD-2610A12327.A4 2610A12327	£14.91	£17.89
7 - CAGE BSD-2610A12311.A2 2610A12311	£27.23	£32.68
8 - THREADED BOLT BSD-2610A12310.A4 2610A12310	£2.80	£3.36
9 - HEX SOCKET HEAD CAP SCREW BSD-2610A12348.A3 2610A12348	£2.16	£2.59
10 - HEX SOCKET HEAD CAP SCREW BSD-2610A12459.A2 2610A12459	£1.75	£2.10
11 - HEX SOCKET HEAD CAP SCREW BSD-2610A12460.A4 2610A12460	£1.75	£2.10
12 - NAMEPLATE BSD-2610A14017.A0 2610A14017	-
14 - KEYBOARD BSD-2610A13406.A1 2610A13406	£27.31	£32.77
15 - MOTOR PLATE BSD-2610A12302.A8 2610A12302	-
16 - TAPPING SCREW BSD-2610A12301.A13 2610A12301	£1.75	£2.10
17 - HEX SOCKET HEAD CAP SCREW BSD-2610A12275.A11 2610A12275	£1.75	£2.10
18 - EXTENSION SPRING BSD-2610A12283.A4 2610A12283	£1.75	£2.10
19 - EXTENSION SPRING BSD-2610A13065.A1 2610A13065	£1.75	£2.10
21 - MOTOR-GEARBOX ASSEMBLY BSD-2610A13249.A13 2610A13249	£33.74	£40.49
650 - BATTERY CHARGER BSD-2610A15290.A6 2610A15290	£23.86	£28.63
651 - BATTERY PACK BSD-2610A15308.A3 2610A15308	-

Attribute Name	Value
Brand	Bosch
