An exploded drawing and listing for the Bosch GSS 230 A / 0601292042 / GB 230 Volt
Ex VAT Inc VAT
1 - MOTOR HOUSING BSD-2605104538.A0 2605104538 £16.41 £19.69
2 - FIELD 230-240V BSD-2604220529.A58 2604220529 £23.86 £28.63
3 - ARMATURE 230-240V BSD-2604011110.A25 2604011110 £33.74 £40.49
3/13 - GROOVE BALL BEARING 7x19x6 BSD-1610905025.A454 1610905025 £6.52 £7.83
3/60 - FAN BSD-2606610076.A68 2606610076 £3.72 £4.47
4 - SWITCH BSD-2607200260.A131 2607200260 £11.30 £13.56
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H05 RN-F BSD-2604460222.A8 2604460222 £18.96 £22.75
6 - GROMMET dia6.4-dia7.2x76 MM BSD-2600703017.A822 2600703017 £2.61 £3.13
7 - CABLE CLIP BSD-2601035001.A1273 2601035001 £1.75 £2.10
9 - MANUFACTURER'S NAMEPLATE BSD-2601119322.A1 2601119322 -
12 - SUPPRESSION FILTER BSD-1617328026.A6 1617328026 £7.36 £8.83
14 - GROOVE BALL BEARING BSD-1619P00290.A62 1619P00290 £6.52 £7.83
16 - BRUSH HOLDER BSD-2604337016.A22 2604337016 £1.75 £2.10
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8 BSD-2603410001.A975 2603410001 £1.75 £2.10
19 - SCREW 4x16 BSD-2603490022.A259 2603490022 £1.75 £2.10
21 - TORX OVAL-HEAD SCREW 3x10 BSD-2603490017.A1647 2603490017 £2.16 £2.59
22 - INNER RING BSD-2600400035.A10 2600400035 £10.10 £12.12
25 - SPRING RETAINING RING DIN 471 9x1MM BSD-2916640006.A95 2916640006 £1.75 £2.10
26 - FAN BSD-2606610085.A19 2606610085 £8.67 £10.41
28 - ECCENTRIC BSD-2600499041.A3 2600499041 £21.52 £25.83
29 - THREAD-FORMING TAP. SCREW M4x8 BSD-2603410048.A392 2603410048 £1.75 £2.10
30 - NEEDLE BEARING BSD-2600910012.A23 2600910012 £5.30 £6.36
32 - CONTACT STRAP BSD-2601329053.A73 2601329053 £1.75 £2.10
34 - TENSIONING LEVER BSD-2608045022.A12 2608045022 £8.67 £10.41
35 - V-RING BSD-2600290030.A33 2600290030 £2.80 £3.36
36 - HOUSING COVER BSD-2605500125.A11 2605500125 £10.10 £12.12
37 - SQUARE NUT DIN 562-M6-04 BSD-2915121006.A121 2915121006 £2.61 £3.13
38 - SEALING COVER BSD-2600500019.A21 2600500019 £1.75 £2.10
39 - SANDER PLATE BSD-2608000165.A16 2608000165 £33.74 £40.49
40 - SHAFT SEAL BSD-2600290031.A10 2600290031 £2.80 £3.36
41 - SEALING DISK BSD-2600590013.A26 2600590013 £2.16 £2.59
43 - THREAD-FORMING TAP. SCREW BSD-2603435042.A88 2603435042 £1.75 £2.10
44 - SUCTION HOOD BSD-2600282017.A13 2600282017 £37.27 £44.72
45 - AIR GUIDE PLATE BSD-2601328055.A38 2601328055 £2.61 £3.13
46 - SUCTION SOCKET BSD-2601328053.A3 2601328053 £2.61 £3.13
47 - FELT STRIP BSD-2601005017.A28 2601005017 £1.75 £2.10
48 - AIR-DEFLECTOR RING BSD-2600034006.A5 2600034006 £8.67 £10.41
49 - PUSHER BSD-2601035002.A60 2601035002 £2.16 £2.59
50 - SWING-PLATE BSD-2608000166.A6 2608000166 £21.52 £25.83
51 - OFFSET SCREWDRIVER DIN 911-SW5 BSD-1907950006.A201 1907950006 £4.26 £5.11
52 - HEX NUT DIN 439-BM8-04 BSD-2915051107.A85 2915051107 £1.75 £2.10
53 - THREAD-FORMING TAP. SCREW M4x12 MM BSD-2603410049.A94 2603410049 £1.75 £2.10
55 - CONNECTING CABLE L=110 MM BSD-2604448146.A46 2604448146 £1.75 £2.10
57 - SUPPRESSION FILTER BSD-2604465090.A12 2604465090 £7.36 £8.83
754 - DUST BAG BSD-2605411112.A21 2605411112 £8.74 £10.49
754/1 - DUST BAG BSD-2605411113.A8 2605411113 £6.12 £7.34
754/2 - DUST BAG BSD-2605411114.A21 2605411114 £17.49 £20.99
755 - AUXILIARY HANDLE BSD-2602026069.A6 2602026069 £5.30 £6.36
768 - CARRYING CASE BSD-2605438368.A4 2605438368 £23.49 £28.19
808 - NAMEPLATE BSD-2601119352.A0 2601119352 -
811 - CARBON BRUSH BSD-1607014117.A33 1607014117 £10.10 £12.12
833 - SPRING BSD-2608005902.A27 2608005902 £16.41 £19.69
