2 - POLE SHOE 220V
BSD-F000600224.A0
F000600224
|
-
|
|
|
|
3 - ARMATURE 230V
BSD-1604011268.A0
1604011268
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-9618086632.A2
9618086632
|
-
|
|
|
|
5 - POWER SUPPLY CORD
BSD-9618089007.A1
9618089007
|
-
|
|
|
|
6 - GROMMET dia 10.5-dia11.0x100 MM
BSD-1600703023.A319
1600703023
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A213
1601302013
|
£1.75
|
£2.10
|
|
|
13 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A44
1600905011
|
£5.58
|
£6.70
|
|
|
14 - GROOVE BALL BEARING 10x35x11
BSD-1600900027.A0
1600900027
|
-
|
|
|
|
15 - BEARING FLANGE
BSD-9618086677.A2
9618086677
|
£10.10
|
£12.12
|
|
|
21 - GEAR HOUSING
BSD-F000600532.A1
F000600532
|
-
|
|
|
|
22 - BEARING FLANGE dia 180 MM
BSD-1605805063.A8
1605805063
|
£14.91
|
£17.89
|
|
|
23 - SEALING CAP
BSD-1605500150.A70
1605500150
|
£3.72
|
£4.47
|
|
|
24 - HANDLE
BSD-1605132119.A3
1605132119
|
£11.30
|
£13.56
|
|
|
25 - GRINDING SPINDLE
BSD-F000600150.A0
F000600150
|
£13.12
|
£15.75
|
|
|
26 - CROWN GEAR Z=53
BSD-1606333618.A40
1606333618
|
-
|
|
|
|
27 - BEVEL GEAR Z=17
BSD-1606333237.A13
1606333237
|
-
|
|
|
|
28 - O-RING 79.0x1.78 MM
BSD-1600210033.A45
1600210033
|
£1.75
|
£2.10
|
|
|
29 - O-RING 4.0x1.0 MM
BSD-1600210034.A186
1600210034
|
£1.75
|
£2.10
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591010.A49
1600591010
|
£2.16
|
£2.59
|
|
|
31 - AIR-DEFLECTOR RING
BSD-1600591011.A129
1600591011
|
£1.75
|
£2.10
|
|
|
32 - RETAINING SNAP RING
BSD-1600290019.A64
1600290019
|
£1.75
|
£2.10
|
|
|
33 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A469
1600290013
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.15 MM
BSD-1600190020.A826
1600190020
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.3 MM
BSD-1600190021.A1
1600190021
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190022.A826
1600190022
|
£1.75
|
£2.10
|
|
|
35 - FELT WASHER
BSD-1600205034.A676
1600205034
|
£1.75
|
£2.10
|
|
|
37 - SEAL RING
BSD-1600290036.A17
1600290036
|
£2.16
|
£2.59
|
|
|
38 - RUBBER RING 7 MM
BSD-1600206020.A439
1600206020
|
£1.75
|
£2.10
|
|
|
39 - RUBBER RING
BSD-1600206030.A222
1600206030
|
£1.75
|
£2.10
|
|
|
40 - PUSH-BUTTON
BSD-1603231012.A0
1603231012
|
£2.16
|
£2.59
|
|
|
41 - COMPRESSION SPRING
BSD-1604611024.A79
1604611024
|
£1.75
|
£2.10
|
|
|
42 - DETENT PIN
BSD-1603123032.A3
1603123032
|
£3.34
|
£4.01
|
|
|
44 - HOLDING BRACKET
BSD-1601334008.A153
1601334008
|
£2.61
|
£3.13
|
|
|
45 - HEX NUT M10. SW14
BSD-1603300019.A620
1603300019
|
£1.75
|
£2.10
|
|
|
46 - RETAINING WASHER 1.8 MM
BSD-1600102018.A4
1600102018
|
£1.75
|
£2.10
|
|
|
47 - RETAINING CLIP
BSD-1600119008.A4
1600119008
|
£1.75
|
£2.10
|
|
|
48 - RETAINING CLIP
BSD-1600119010.A62
1600119010
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING
BSD-1600900032.A0
1600900032
|
-
|
|
|
|
51 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A608
2600910001
|
£4.26
|
£5.11
|
|
|
52 - CABLE ROUTING
BSD-1602388027.A177
1602388027
|
£2.61
|
£3.13
|
|
|
55 - STORAGE LEDGE
BSD-1602388029.A76
1602388029
|
£1.75
|
£2.10
|
|
|
60 - SCREW
BSD-9618086638.A0
9618086638
|
£1.75
|
£2.10
|
|
|
61 - TAPPING SCREW
BSD-F000600216.A3
F000600216
|
£1.75
|
£2.10
|
|
|
62 - TAPPING SCREW
BSD-F000600218.A3
F000600218
|
£1.75
|
£2.10
|
|
|
63 - PAN HEAD SCREW M4x10 MM
BSD-1603410014.A575
1603410014
|
£1.75
|
£2.10
|
|
|
64 - TAPPING SCREW 4x16 MM
BSD-9618087099.A15
9618087099
|
£1.75
|
£2.10
|
|
|
65 - TAPPING SCREW 4x16 MM
BSD-9618087099.A16
9618087099
|
£1.75
|
£2.10
|
|
|
66 - SOCKET HEAD CAP SCREW
BSD-2910022116.A0
2910022116
|
-
|
|
|
|
71 - THREAD-FORMING TAP. SCREW
BSD-9618089885.A4
9618089885
|
£1.75
|
£2.10
|
|
|
661 - AUXILIARY HANDLE M14
BSD-1602025022.A980
1602025022
|
£13.41
|
£16.09
|
|
|
662 - PIN-TYPE FACE-WRENCH 35x6
BSD-1607950056.A0
1607950056
|
-
|
|
|
|
663 - PROTECTIVE COVER dia180 MM
BSD-1605510176.A48
1605510176
|
-
|
|
|
|
664 - ROUND NUT M14
BSD-1603345043.A1087
1603345043
|
£8.67
|
£10.41
|
|
|
665 - CLAMPING-FLANGE
BSD-1605703028.A0
1605703028
|
£19.24
|
£23.09
|
|
|
666 - CONICAL SPRING WASHER
BSD-1600114021.A2
1600114021
|
-
|
|
|
|
667 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A327
2605703014
|
£7.36
|
£8.83
|
|
|
668 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A987
1603340027
|
£46.82
|
£56.18
|
|
|
670 - SPARE PART
BSD-9618086834.A2
9618086834
|
£2.80
|
£3.36
|
|
|
671 - PARTS SET dia180 MM
BSD-1607000250.A21
1607000250
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-9618086832.A0
9618086832
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014171.A18
1607014171
|
£14.91
|
£17.89
|
|
|
811 - BRUSH HOLDER
BSD-1604336021.A66
1604336021
|
£2.80
|
£3.36
|
|
