1 - MOTOR HOUSING
BSD-1619P09772.A3
1619P09772
|
£13.12
|
£15.75
|
|
|
2 - FIELD 220-240V
BSD-1604220328.A14
1604220328
|
£21.52
|
£25.83
|
|
|
3 - ARMATURE 220-240V
BSD-1604010626.A44
1604010626
|
£31.64
|
£37.97
|
|
|
3/50 - FAN
BSD-1606610141.A96
1606610141
|
£4.26
|
£5.11
|
|
|
4 - ON-OFF SWITCH
BSD-1607200179.A75
1607200179
|
£10.59
|
£12.71
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 0.75mm H05 VV-F
BSD-1604460260.A1
1604460260
|
£11.30
|
£13.56
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A695
2600703012
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A164
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE GWS 6-100
BSD-2609130611.A1
2609130611
|
£3.72
|
£4.47
|
|
|
12 - SUPPRESSION FILTER
BSD-1619P07647.A39
1619P07647
|
£6.52
|
£7.83
|
|
|
13 - BALL BEARING 7x19x6 MM
BSD-1619P00456.A34
1619P00456
|
£2.80
|
£3.36
|
|
|
14 - BALL BEARING
BSD-1619P00455.A40
1619P00455
|
£3.72
|
£4.47
|
|
|
16 - BRUSH HOLDER
BSD-1619P01811.A168
1619P01811
|
£2.80
|
£3.36
|
|
|
17 - SPIRAL SPRING
BSD-1604652013.A224
1604652013
|
£1.75
|
£2.10
|
|
|
18 - COMPRESSION SPRING
BSD-1604611031.A172
1604611031
|
£2.80
|
£3.36
|
|
|
22 - ADJUSTING SLIDE
BSD-1602319009.A99
1602319009
|
£2.80
|
£3.36
|
|
|
23 - SWITCH HANDLE
BSD-1602026068.A1
1602026068
|
£2.61
|
£3.13
|
|
|
25 - HOUSING COVER
BSD-1605500194.A66
1605500194
|
£5.30
|
£6.36
|
|
|
26 - INTERMEDIATE RING
BSD-1600502023.A47
1600502023
|
£2.16
|
£2.59
|
|
|
27 - RUBBER RING
BSD-1600206025.A232
1600206025
|
£2.16
|
£2.59
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591024.A10
1600591024
|
£3.72
|
£4.47
|
|
|
32 - GRINDING SPINDLE M10. SW12
BSD-1603523111.A1
1603523111
|
£6.52
|
£7.83
|
|
|
33 - O-RING 42.0x1.1 MM
BSD-1600210041.A4
1600210041
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.1 MM
BSD-1600136016.A94
1600136016
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.2 MM
BSD-1600136017.A18
1600136017
|
£2.61
|
£3.13
|
|
|
37 - COVER DISC
BSD-1600100033.A142
1600100033
|
£2.61
|
£3.13
|
|
|
38 - CONVERSION GEAR
BSD-2609110150.A87
2609110150
|
£6.52
|
£7.83
|
|
|
39 - PINION
BSD-2609110149.A25
2609110149
|
£4.26
|
£5.11
|
|
|
45 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A120
2915011007
|
-
|
|
|
|
47 - SPECIAL SCREW
BSD-2609110052.A3
2609110052
|
£1.75
|
£2.10
|
|
|
48 - TORX OVAL-HEAD SCREW 3x10
BSD-1619P00220.A6
1619P00220
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW DIN 7500. M4x10. SR10.2
BSD-1603435068.A160
1603435068
|
£1.75
|
£2.10
|
|
|
50 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A47
2910611020
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7981-ST3.9x25-C-H
BSD-2910611022.A6
2910611022
|
-
|
|
|
|
80 - SEALING DISK
BSD-3600150021.A533
3600150021
|
£3.80
|
£4.56
|
|
|
650/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A10
160202509T
|
£3.72
|
£4.47
|
|
|
650/20 - ROUND NUT WITH 2 HOLES
BSD-1619P09976.A14
1619P09976
|
£2.16
|
£2.59
|
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-2609110015.A10
2609110015
|
£2.61
|
£3.13
|
|
|
650/50 - CLAMPING-FLANGE M10. 16-20 MM
BSD-1605703113.A6
1605703113
|
£1.75
|
£2.10
|
|
|
651 - PROTECTIVE GUARD dia 115 MM
BSD-2609110050.A1
2609110050
|
£11.30
|
£13.56
|
|
|
808 - NAMEPLATE
BSD-1619P00631.A0
1619P00631
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014145.A18
1607014145
|
£10.10
|
£12.12
|
|
|
821 - GEAR HOUSING
BSD-1605806466.A7
1605806466
|
£16.41
|
£19.69
|
|
|
828 - BEARING FLANGE
BSD-1605805090.A3
1605805090
|
£16.41
|
£19.69
|
|
|
840 - PUSH-BUTTON
BSD-1607000298.A91
1607000298
|
£4.26
|
£5.11
|
|
|
841 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A32
1600910018
|
£5.30
|
£6.36
|
|
|
857 - OVAL-HEAD SCREW DIN7985-M3.5x5-4.8-H
BSD-2910641081.A107
2910641081
|
-
|
|
|
