2 - FIELD 230V
BSD-1604220470.A2
1604220470
|
£27.23
|
£32.68
|
|
|
3/13 - BALL BEARING 7x19x6
BSD-2600905032.A537
2600905032
|
£5.30
|
£6.36
|
|
|
4 - SWITCH
BSD-1607200199.A25
1607200199
|
£16.41
|
£19.69
|
|
|
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460244.A25
2604460244
|
£27.23
|
£32.68
|
|
|
6 - GROMMET
BSD-1600703042.A12
1600703042
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A695
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE GWS 9-115
BSD-1601118L02.A2
1601118L02
|
£2.61
|
£3.13
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A355
1600905032
|
£5.58
|
£6.70
|
|
|
24 - COVER
BSD-1605500279.A13
1605500279
|
£2.80
|
£3.36
|
|
|
25 - HOUSING COVER
BSD-1605500278.A4
1605500278
|
£8.67
|
£10.41
|
|
|
26 - INTERMEDIATE RING
BSD-1600502023.A194
1600502023
|
£2.16
|
£2.59
|
|
|
27 - RUBBER RING
BSD-1600206025.A582
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A98
1600591025
|
£2.61
|
£3.13
|
|
|
30 - AIR DISTRIBUTOR
BSD-1600591050.A14
1600591050
|
£2.61
|
£3.13
|
|
|
32 - GRINDING SPINDLE
BSD-1607000D6A.A8
1607000D6A
|
£7.36
|
£8.83
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A126
1600210035
|
£1.75
|
£2.10
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A382
1600136013
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A138
1600136014
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A382
1600136015
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A136
1600136020
|
£3.72
|
£4.47
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A333
1600119011
|
£2.16
|
£2.59
|
|
|
41 - PLAIN BEARING
BSD-1600200029.A288
1600200029
|
£4.26
|
£5.11
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A126
1603300016
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW M4x16
BSD-2914491410.A145
2914491410
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1278
2603490023
|
£1.75
|
£2.10
|
|
|
52 - CONNECTING CABLE L=90 MM
BSD-1604448013.A21
1604448013
|
£2.16
|
£2.59
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A78
1603435078
|
£1.75
|
£2.10
|
|
|
54 - TORX OVAL-HEAD SCREW 4x30
BSD-1603414026.A205
1603414026
|
£1.75
|
£2.10
|
|
|
55 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A619
2603490021
|
£1.75
|
£2.10
|
|
|
80 - SEALING DISK
BSD-3600150021.A188
3600150021
|
£3.80
|
£4.56
|
|
|
104 - O-RING 4.5x1.0 MM
BSD-1600210044.A103
1600210044
|
£1.75
|
£2.10
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A72
1601008005
|
£4.26
|
£5.11
|
|
|
301/1 - MOTOR HOUSING
BSD-1605108287.A0
1605108287
|
£10.10
|
£12.12
|
|
|
301/17 - SPIRAL SPRING
BSD-1604652021.A37
1604652021
|
£1.75
|
£2.10
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026088.A79
1602026088
|
£1.75
|
£2.10
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611026.A380
1604611026
|
£1.75
|
£2.10
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319010.A75
1602319010
|
£1.75
|
£2.10
|
|
|
301/48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A109
1613435034
|
£1.75
|
£2.10
|
|
|
343 - CATCH LEVER
BSD-1607000742.A147
1607000742
|
£7.36
|
£8.83
|
|
|
343/44 - COMPRESSION SPRING
BSD-1604611042.A86
1604611042
|
£1.75
|
£2.10
|
|
|
650/1 - AUXILIARY HANDLE M10 ANTI-VIBRATION
BSD-16020250A0.A143
16020250A0
|
£21.42
|
£25.71
|
|
|
650/2 - ROUND NUT M14
BSD-1603345043.A855
1603345043
|
£8.67
|
£10.41
|
|
|
650/3 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A91
1607950052
|
£3.72
|
£4.47
|
|
|
650/5 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A933
2605703014
|
£7.36
|
£8.83
|
|
|
650/5/2 - O-RING 20.35x1.78 MM
BSD-1600210039.A137
1600210039
|
£2.16
|
£2.59
|
|
|
651 - PROTECTIVE COVER
BSD-1600A00XK8.A13
1600A00XK8
|
£14.91
|
£17.89
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1607000V49.A3
1607000V49
|
£45.67
|
£54.80
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A50
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607000V53.A6
1607000V53
|
£13.12
|
£15.75
|
|
|
816 - BRUSH HOLDER
BSD-1607000V54.A14
1607000V54
|
£2.80
|
£3.36
|
|
|
818 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A353
2910110048
|
£1.75
|
£2.10
|
|
|
821 - GEAR HOUSING
BSD-1607000V55.A3
1607000V55
|
£31.64
|
£37.97
|
|
|
828 - BEARING FLANGE
BSD-1607000D6C.A108
1607000D6C
|
£12.04
|
£14.45
|
|
|
828/04 - O-RING 47.0x1.5 MM
BSD-3600210109.A109
3600210109
|
£2.16
|
£2.59
|
|
|
835 - FAN
BSD-1606610132.A78
1606610132
|
£2.16
|
£2.59
|
|
|
838 - SET OF GEARWHEELS
BSD-1607000D4Y.A250
1607000D4Y
|
£21.42
|
£25.71
|
|
|
840 - PUSH-BUTTON
BSD-1607000V41.A21
1607000V41
|
£4.26
|
£5.11
|
|
|
851 - SPEED GOVERNOR
BSD-16072335CG.A1
16072335CG
|
£54.42
|
£65.30
|
|
|
891 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A883
160202509T
|
£3.72
|
£4.47
|
|
|
896 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A772
1603340027
|
£46.82
|
£56.18
|
|
