2 - FIELD 220-240V
BSD-1604220283.A26
1604220283
|
£27.31
|
£32.77
|
|
|
4 - SWITCH
BSD-1607200199.A20
1607200199
|
£16.41
|
£19.69
|
|
|
6 - GROMMET
BSD-1600703039.A22
1600703039
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A659
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C2TV.A0
160111C2TV
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-2600905072.A2
2600905072
|
-
|
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A368
1600905032
|
£5.58
|
£6.70
|
|
|
24 - COVER
BSD-1605500228.A42
1605500228
|
£2.80
|
£3.36
|
|
|
25 - HOUSING COVER
BSD-1605500251.A48
1605500251
|
£7.36
|
£8.83
|
|
|
26 - RUBBER RING
BSD-1600206036.A51
1600206036
|
£1.75
|
£2.10
|
|
|
27 - RUBBER RING
BSD-1600206025.A530
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A90
1600591025
|
£2.61
|
£3.13
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591014.A381
1600591014
|
£2.61
|
£3.13
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A75
1600210035
|
£1.75
|
£2.10
|
|
|
34 - BRAKING ELEMENT
BSD-1600A012X9.A9
1600A012X9
|
-
|
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A437
1600136013
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A83
1600136014
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A437
1600136015
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A81
1600136020
|
£3.72
|
£4.47
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A312
1600290016
|
£2.61
|
£3.13
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A278
1600119011
|
£2.16
|
£2.59
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A82
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A633
2603490021
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW M4x16-St w/ Precote 85-3
BSD-160343508X.A25
160343508X
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1236
2603490023
|
£1.75
|
£2.10
|
|
|
52 - CONNECTING CABLE L=90 MM
BSD-1604448013.A11
1604448013
|
£2.16
|
£2.59
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A35
1603435078
|
£1.75
|
£2.10
|
|
|
54 - TORX OVAL-HEAD SCREW 4x30
BSD-1603414026.A168
1603414026
|
£1.75
|
£2.10
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A64
1601008005
|
£4.26
|
£5.11
|
|
|
301/1 - MOTOR HOUSING
BSD-1605108249.A34
1605108249
|
£11.30
|
£13.56
|
|
|
301/16 - BRUSH HOLDER
BSD-1601323023.A30
1601323023
|
£3.72
|
£4.47
|
|
|
301/17 - SPIRAL SPRING
BSD-1604652013.A716
1604652013
|
£1.75
|
£2.10
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026088.A81
1602026088
|
£1.75
|
£2.10
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611026.A382
1604611026
|
£1.75
|
£2.10
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319011.A81
1602319011
|
£1.75
|
£2.10
|
|
|
301/48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A52
1613435034
|
£1.75
|
£2.10
|
|
|
343 - CATCH LEVER
BSD-1607000742.A172
1607000742
|
£7.36
|
£8.83
|
|
|
343/44 - COMPRESSION SPRING
BSD-1604611042.A26
1604611042
|
£1.75
|
£2.10
|
|
|
651 - PROTECTIVE COVER
BSD-1600A00XK9.A93
1600A00XK9
|
£14.72
|
£17.67
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1604010A20.A12
1604010A20
|
£57.02
|
£68.42
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A224
1607000386
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A6J3.A0
160111A6J3
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A187
1607014176
|
£13.12
|
£15.75
|
|
|
810 - CARBON-BRUSH SET 10 x 1 607 014 176
BSD-1607000482.A82
1607000482
|
£93.88
|
£112.65
|
|
|
818 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A347
2910110048
|
£1.75
|
£2.10
|
|
|
821 - GEAR HOUSING
BSD-1607000D5B.A0
1607000D5B
|
-
|
|
|
|
828 - PARTS SET
BSD-1607000D5G.A0
1607000D5G
|
-
|
|
|
|
828/04 - O-RING 47.0x1.5 MM
BSD-3600210109.A64
3600210109
|
£2.16
|
£2.59
|
|
|
835 - FAN
BSD-1606610132.A131
1606610132
|
£2.16
|
£2.59
|
|
|
840 - PARTS SET
BSD-1607000D5X.A5
1607000D5X
|
-
|
|
|
|
841 - PARTS SET
BSD-1607000D5Z.A12
1607000D5Z
|
-
|
|
|
|
851 - SPEED GOVERNOR
BSD-16072335CG.A9
16072335CG
|
£54.42
|
£65.30
|
|
|
891 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A869
160202509T
|
£3.72
|
£4.47
|
|
|
891 - AUXILIARY HANDLE M10 ANTI-VIBRATION
BSD-16020250A0.A94
16020250A0
|
£21.42
|
£25.71
|
|
