2 - FIELD 220-240V
BSD-1604220283.A25
1604220283
|
£27.31
|
£32.77
|
|
|
4 - SWITCH
BSD-1607200199.A19
1607200199
|
£16.41
|
£19.69
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460401.A64
1604460401
|
£19.45
|
£23.34
|
|
|
6 - GROMMET
BSD-1600703039.A23
1600703039
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A658
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C2TV.A1
160111C2TV
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-2600905072.A1
2600905072
|
-
|
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A367
1600905032
|
£5.58
|
£6.70
|
|
|
24 - COVER
BSD-1605500228.A41
1605500228
|
£2.80
|
£3.36
|
|
|
25 - HOUSING COVER
BSD-1605500251.A49
1605500251
|
£7.36
|
£8.83
|
|
|
26 - RUBBER RING
BSD-1600206036.A52
1600206036
|
£1.75
|
£2.10
|
|
|
27 - RUBBER RING
BSD-1600206025.A529
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A91
1600591025
|
£2.61
|
£3.13
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591014.A380
1600591014
|
£2.61
|
£3.13
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A74
1600210035
|
£1.75
|
£2.10
|
|
|
34 - BRAKING ELEMENT
BSD-1600A012X9.A7
1600A012X9
|
-
|
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A436
1600136013
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A84
1600136014
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A436
1600136015
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A82
1600136020
|
£3.72
|
£4.47
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A313
1600290016
|
£2.61
|
£3.13
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A279
1600119011
|
£2.16
|
£2.59
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A81
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A632
2603490021
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW M4x16-St w/ Precote 85-3
BSD-160343508X.A24
160343508X
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1237
2603490023
|
£1.75
|
£2.10
|
|
|
52 - CONNECTING CABLE L=90 MM
BSD-1604448013.A12
1604448013
|
£2.16
|
£2.59
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A36
1603435078
|
£1.75
|
£2.10
|
|
|
54 - TORX OVAL-HEAD SCREW 4x30
BSD-1603414026.A169
1603414026
|
£1.75
|
£2.10
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A63
1601008005
|
£4.26
|
£5.11
|
|
|
301/1 - MOTOR HOUSING
BSD-1605108249.A33
1605108249
|
£11.30
|
£13.56
|
|
|
301/16 - BRUSH HOLDER
BSD-1601323023.A31
1601323023
|
£3.72
|
£4.47
|
|
|
301/17 - SPIRAL SPRING
BSD-1604652013.A717
1604652013
|
£1.75
|
£2.10
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026088.A82
1602026088
|
£1.75
|
£2.10
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611026.A383
1604611026
|
£1.75
|
£2.10
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319011.A80
1602319011
|
£1.75
|
£2.10
|
|
|
301/48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A53
1613435034
|
£1.75
|
£2.10
|
|
|
343 - CATCH LEVER
BSD-1607000742.A173
1607000742
|
£7.36
|
£8.83
|
|
|
343/44 - COMPRESSION SPRING
BSD-1604611042.A25
1604611042
|
£1.75
|
£2.10
|
|
|
651 - PROTECTIVE COVER
BSD-1600A00XK9.A94
1600A00XK9
|
£14.72
|
£17.67
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1604010A20.A11
1604010A20
|
£57.02
|
£68.42
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A225
1607000386
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A6J4.A0
160111A6J4
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A188
1607014176
|
£13.12
|
£15.75
|
|
|
810 - CARBON-BRUSH SET 10 x 1 607 014 176
BSD-1607000482.A81
1607000482
|
£93.88
|
£112.65
|
|
|
818 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A346
2910110048
|
£1.75
|
£2.10
|
|
|
821 - GEAR HOUSING
BSD-1607000D5B.A1
1607000D5B
|
-
|
|
|
|
828 - PARTS SET
BSD-1607000D5G.A3
1607000D5G
|
-
|
|
|
|
828/04 - O-RING 47.0x1.5 MM
BSD-3600210109.A67
3600210109
|
£2.16
|
£2.59
|
|
|
835 - FAN
BSD-1606610132.A133
1606610132
|
£2.16
|
£2.59
|
|
|
840 - PARTS SET
BSD-1607000D5X.A6
1607000D5X
|
-
|
|
|
|
841 - PARTS SET
BSD-1607000D5Z.A11
1607000D5Z
|
-
|
|
|
|
851 - SPEED GOVERNOR
BSD-16072335CG.A8
16072335CG
|
£54.42
|
£65.30
|
|
|
891 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A870
160202509T
|
£3.72
|
£4.47
|
|
|
891 - AUXILIARY HANDLE M10 ANTI-VIBRATION
BSD-16020250A0.A92
16020250A0
|
£21.42
|
£25.71
|
|
