1 - MOTOR HOUSING
BSD-3605108094.A21
3605108094
|
-
|
|
|
|
2 - BRUSH HOLDER
BSD-1604336005.A82
1604336005
|
-
|
|
|
|
3 - SPIRAL SPRING
BSD-1604652001.A96
1604652001
|
-
|
|
|
|
4 - POLE SHOE 100-120V
BSD-1604220206.A1
1604220206
|
-
|
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209002.A365
1600209002
|
£5.30
|
£6.36
|
|
|
7 - ARMATURE WITH FAN 110-115V
BSD-1604010026.A0
1604010026
|
-
|
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A2210
2600905032
|
£5.30
|
£6.36
|
|
|
8 - INTERMEDIATE RING
BSD-1600502011.A310
1600502011
|
£2.61
|
£3.13
|
|
|
12 - SEALING CAP
BSD-3605500057.A3
3605500057
|
-
|
|
|
|
15 - SWITCH
BSD-1607200078.A110
1607200078
|
£40.80
|
£48.96
|
|
|
15 - SWITCH
BSD-1607200037.A176
1607200037
|
£45.67
|
£54.80
|
|
|
16 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A784
1607000227
|
£23.86
|
£28.63
|
|
|
17 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A161
3600703011
|
£2.80
|
£3.36
|
|
|
19 - SUPPRESSION CAPACITOR
BSD-1607328012.A111
1607328012
|
-
|
|
|
|
20 - REFERENCE PLATE
BSD-1601110058.A4
1601110058
|
£1.75
|
£2.10
|
|
|
21 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A96
1602381001
|
-
|
|
|
|
24 - NAMEPLATE
BSD-160111A3H3.A4804
160111A3H3
|
£2.61
|
£3.13
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110004.A17
1601110004
|
-
|
|
|
|
27 - O-RING 74.0x3.0 MM
BSD-1600210006.A196
1600210006
|
£1.75
|
£2.10
|
|
|
28 - FASTENING CLAMP
BSD-1601302014.A557
1601302014
|
£2.61
|
£3.13
|
|
|
30 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A877
2910211019
|
£1.75
|
£2.10
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A239
2910021154
|
£1.75
|
£2.10
|
|
|
33 - SOCKET HEAD CAP SCREW M5x35 DIN 84-5.8
BSD-2910011168.A23
2910011168
|
-
|
|
|
|
33 - SCREW B 4.8x45 MM
BSD-3603415560.A223
3603415560
|
£1.75
|
£2.10
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-BM5x55-8.8
BSD-2910021176.A30
2910021176
|
-
|
|
|
|
34 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A95
1613412001
|
£1.75
|
£2.10
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM5x22-8.8
BSD-2910021163.A74
2910021163
|
-
|
|
|
|
36 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A558
2910021125
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A804
2910021118
|
£1.75
|
£2.10
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A518
2910021116
|
£2.16
|
£2.59
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-8.8
BSD-2910021128.A140
2910021128
|
-
|
|
|
|
39 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A252
2910211220
|
-
|
|
|
|
41 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A136
2916680006
|
-
|
|
|
|
42 - SPRING WASHER DIN 137-A4
BSD-1600150006.A594
1600150006
|
-
|
|
|
|
44 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A384
2910110116
|
£1.75
|
£2.10
|
|
|
45 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A992
2916690003
|
£1.75
|
£2.10
|
|
|
46 - PLAIN WASHER A 4.3 DIN 125-ST
BSD-2916010410.A267
2916010410
|
-
|
|
|
|
60 - SPINDLE BEARING
BSD-1605806222.A0
1605806222
|
-
|
|
|
|
61 - DRILLING SPINDLE
BSD-1603124039.A92
1603124039
|
-
|
|
|
|
62 - GROOVE BALL BEARING 15x32x8
BSD-1900900201.A3
1900900201
|
-
|
|
|
|
63 - RETAINING SNAP RING
BSD-3607030355.A1
3607030355
|
£18.96
|
£22.75
|
|
|
64 - SEALING DISK
BSD-1600108000.A104
1600108000
|
-
|
|
|
|
65 - SPACER BUSHING
BSD-1600300026.A105
1600300026
|
-
|
|
|
|
66 - GROOVE BALL BEARING 15x35x11
BSD-1900900303.A121
1900900303
|
-
|
|
|
|
67 - SHIM 0.5 MM
BSD-1600102003.A3
1600102003
|
£1.75
|
£2.10
|
|
|
68 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A165
2916660014
|
£1.75
|
£2.10
|
|
|
69 - SPACER BUSHING
BSD-1600300027.A2
1600300027
|
-
|
|
|
|
70 - CYLINDRICAL GEAR Z=50
BSD-1606317045.A120
1606317045
|
-
|
|
|
|
71 - SPINDLE WITH GEAR Z=9/33
BSD-1606328044.A24
1606328044
|
-
|
|
|
|
72 - SHIM 0.5 MM
BSD-1600100631.A76
1600100631
|
£1.75
|
£2.10
|
|
|
96 - FELT DISC
BSD-1600108003.A226
1600108003
|
£1.32
|
£1.58
|
|
|
97 - BEARING COVER
BSD-1600501019.A120
1600501019
|
£23.86
|
£28.63
|
|
|
98 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A73
1600900001
|
-
|
|
|
|
99 - BEARING FLANGE
BSD-1605820096.A3
1605820096
|
-
|
|
|
|
100 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A559
2910021125
|
£1.75
|
£2.10
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1284
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1038
1602025030
|
£18.96
|
£22.75
|
|
|
651 - KEY CHUCK dia1.5-13 MM. B16
BSD-1608571027.A1
1608571027
|
-
|
|
|
|
800 - HANDLE
BSD-3605133012.A42
3605133012
|
-
|
|
|
|
802 - CARBON-BRUSH SET
BSD-1607014101.A27
1607014101
|
£11.30
|
£13.56
|
|
