1 - CLAMSHELL SET
BDE-NA065755.A2
NA065755
|
£34.00
|
£40.80
|
|
|
1 - CLAMSHELL SET
BDE-NA065755.A3
NA065755
|
£34.00
|
£40.80
|
|
|
2 - MOTOR COVER
BDE-N054423.A5
N054423
|
£10.85
|
£13.02
|
|
|
2 - MOTOR COVER
BDE-N054423.A6
N054423
|
£10.85
|
£13.02
|
|
|
3 - END CAP
BDE-N173219.A0
N173219
|
£7.18
|
£8.62
|
|
|
3 - END CAP
BDE-629547-00.A4
629547-00
|
-
|
|
|
|
4 - SCREW
BDE-90611830.A176
90611830
|
£1.50
|
£1.80
|
|
|
4 - SCREW
BDE-90611830.A186
90611830
|
£1.50
|
£1.80
|
|
|
5 - SCREW
BDE-398987-00.A15
398987-00
|
£1.50
|
£1.80
|
|
|
5 - SCREW
BDE-398987-00.A16
398987-00
|
£1.50
|
£1.80
|
|
|
6 - BRAND LABEL
BDE-N094673.A8
N094673
|
£1.50
|
£1.80
|
|
|
6 - BRAND LABEL
BDE-N094673.A9
N094673
|
£1.50
|
£1.80
|
|
|
7 - HEX KEY 5 MM
BDE-098000-11.A23
098000-11
|
£1.50
|
£1.80
|
|
|
7 - HEX KEY 5 MM
BDE-098000-11.A24
098000-11
|
£1.50
|
£1.80
|
|
|
8 - SWITCH SA GB
BDE-N189271.A0
N189271
|
£71.44
|
£85.73
|
|
|
8 - NO LONGER AVAILABLE PRE EMI
BDE-000000-00.A129434
000000-00
|
-
|
|
|
|
8 - SWITCH SA PRE EMI GB
BDE-N189271.A1
N189271
|
£71.44
|
£85.73
|
|
|
9 - BUTTON LOCK-OFF
BDE-605107-00.A2
605107-00
|
£3.80
|
£4.56
|
|
|
9 - BUTTON LOCK-OFF
BDE-605107-00.A3
605107-00
|
£3.80
|
£4.56
|
|
|
10 - SCREW
BDE-330019-40.A16
330019-40
|
£1.50
|
£1.80
|
|
|
10 - SCREW
BDE-330019-40.A17
330019-40
|
£1.50
|
£1.80
|
|
|
11 - SPRING
BDE-389120-00.A9
389120-00
|
£2.26
|
£2.71
|
|
|
11 - SPRING
BDE-389120-00.A10
389120-00
|
£2.26
|
£2.71
|
|
|
12 - PIN
BDE-388531-00.A9
388531-00
|
£1.50
|
£1.80
|
|
|
12 - PIN
BDE-388531-00.A10
388531-00
|
£1.50
|
£1.80
|
|
|
14 - SPINDLE SA
BDE-659417-00SV.A102
659417-00SV
|
£24.39
|
£29.27
|
|
|
14 - SPINDLE SA
BDE-659417-00SV.A105
659417-00SV
|
£24.39
|
£29.27
|
|
|
15 - GASKET
BDE-605081-01.A2
605081-01
|
£1.50
|
£1.80
|
|
|
15 - GASKET
BDE-605081-01.A3
605081-01
|
£1.50
|
£1.80
|
|
|
16 - SCREW
BDE-613783-00.A12
613783-00
|
£1.50
|
£1.80
|
|
|
16 - SCREW
BDE-613783-00.A13
613783-00
|
£1.50
|
£1.80
|
|
|
17 - WIPER
BDE-605094-00.A2
605094-00
|
£1.50
|
£1.80
|
|
|
17 - WIPER
BDE-605094-00.A3
605094-00
|
£1.50
|
£1.80
|
|
|
18 - SPINDLE LOCK
BDE-629444-00.A2
629444-00
|
£1.50
|
£1.80
|
|
|
18 - SPINDLE LOCK
BDE-629444-00.A3
629444-00
|
£1.50
|
£1.80
|
|
|
19 - SPRING
BDE-58698-00.A37
58698-00
|
£1.50
|
£1.80
|
|
|
19 - SPRING
BDE-58698-00.A38
58698-00
|
£1.50
|
£1.80
|
|
|
20 - GUARD UPPER
BDE-NA006178.A0
NA006178
|
£30.08
|
£36.10
|
|
|
20 - GUARD UPPER
BDE-NA006178.A1
NA006178
|
£30.08
|
£36.10
|
|
|
21 - BUMPER
BDE-N248899.A12
N248899
|
£1.51
|
£1.81
|
|
|
21 - BUMPER
BDE-N248899.A3
N248899
|
£1.51
|
£1.81
|
|
|
22 - SCREW
BDE-610134-00.A7
610134-00
|
£1.50
|
£1.80
|
|
|
22 - SCREW
BDE-610134-00.A8
610134-00
|
£1.50
|
£1.80
|
|
|
23 - SPIROL PIN
BDE-614048-00.A5
614048-00
|
£2.49
|
£2.99
|
|
|
23 - SPIROL PIN
BDE-614048-00.A6
614048-00
|
£2.49
|
£2.99
|
|
|
24 - GUARD LOWER
BDE-611925-00.A1
611925-00
|
£17.48
|
£20.97
|
|
|
24 - GUARD LOWER
BDE-611925-00.A2
611925-00
|
£17.48
|
£20.97
|
|
|
25 - SPRING
BDE-N035365.A6
N035365
|
£1.50
|
£1.80
|
|
|
25 - SPRING
BDE-N035365.A7
N035365
|
£1.50
|
£1.80
|
|
|
26 - RETAINER
BDE-150383-00.A17
150383-00
|
£1.50
|
£1.80
|
|
|
26 - RETAINER
BDE-150383-00.A18
150383-00
|
£1.50
|
£1.80
|
|
|
27 - SHOE SA
BDE-N491713.A2
N491713
|
£55.30
|
£66.36
|
|
|
27 - SHOE SA
BDE-N491713.A3
N491713
|
£55.30
|
£66.36
|
|
|
28 - LEVER
BDE-605105-00.A10
605105-00
|
£1.82
|
£2.19
|
|
|
28 - LEVER
BDE-605105-00.A11
605105-00
|
£1.82
|
£2.19
|
|
|
29 - SHAFT
BDE-618901-00.A1
618901-00
|
£5.88
|
£7.06
|
|
|
29 - SHAFT
BDE-618901-00.A2
618901-00
|
£5.88
|
£7.06
|
|
|
30 - SCREW
BDE-330045-14.A99
330045-14
|
£1.50
|
£1.80
|
|
|
30 - SCREW
BDE-330045-14.A100
330045-14
|
£1.50
|
£1.80
|
|
|
31 - WASHER
BDE-N112241.A2
N112241
|
£1.50
|
£1.80
|
|
|
31 - WASHER
BDE-N112241.A3
N112241
|
£1.50
|
£1.80
|
|
|
32 - CARRIAGE BOLT
BDE-098128-85.A7
098128-85
|
£1.50
|
£1.80
|
|
|
32 - CARRIAGE BOLT
BDE-098128-85.A8
098128-85
|
£1.50
|
£1.80
|
|
|
33 - KNOB
BDE-395889-00.A23
395889-00
|
£3.80
|
£4.56
|
|
|
33 - KNOB
BDE-395889-00.A24
395889-00
|
£3.80
|
£4.56
|
|
|
34 - CARRIAGE BOLT
BDE-N022876.A4
N022876
|
£1.50
|
£1.80
|
|
|
34 - CARRIAGE BOLT
BDE-N022876.A5
N022876
|
£1.50
|
£1.80
|
|
|
35 - SCREW
BDE-381069-00.A7
381069-00
|
£1.50
|
£1.80
|
|
|
35 - SCREW
BDE-381069-00.A8
381069-00
|
£1.50
|
£1.80
|
|
|
36 - SPRING
BDE-058287-00.A14
058287-00
|
£1.50
|
£1.80
|
|
|
36 - SPRING
BDE-058287-00.A27
058287-00
|
£1.50
|
£1.80
|
|
|
37 - KNOB
BDE-396992-02.A2
396992-02
|
£1.66
|
£1.99
|
|
|
37 - KNOB
BDE-396992-02.A3
396992-02
|
£1.66
|
£1.99
|
|
|
38 - WASHER INNER CLAMP GB
BDE-610046-00.A1
610046-00
|
£5.88
|
£7.06
|
|
|
38 - WASHER INNER CLAMP
BDE-650109-00.A2
650109-00
|
£1.50
|
£1.80
|
|
|
39 - WASHER OUTER CLAMP GB
BDE-N621119.A7
N621119
|
£3.30
|
£3.96
|
|
|
39 - WASHER OUTER CLAMP
BDE-N621119.A8
N621119
|
£3.30
|
£3.96
|
|
|
40 - BLADE BOLT
BDE-648697-00.A4
648697-00
|
£1.88
|
£2.25
|
|
|
40 - BLADE BOLT
BDE-648697-00.A5
648697-00
|
£1.88
|
£2.25
|
|
|
41 - BEARING
BDE-330003-64.A99
330003-64
|
£4.69
|
£5.63
|
|
|
41 - BEARING
BDE-330003-64.A100
330003-64
|
£4.69
|
£5.63
|
|
|
44 - ARMATURE SA
BDE-N415778.A0
N415778
|
-
|
|
|
|
44 - ARMATURE SA GB
BDE-N415778.A1
N415778
|
-
|
|
|
|
45 - MAGNET
BDE-611202-00SV.A28
611202-00SV
|
-
|
|
|
|
45 - MAGNET
BDE-611202-00SV.A29
611202-00SV
|
-
|
|
|
|
46 - SUPPORT BEARING
BDE-N171820.A27
N171820
|
-
|
|
|
|
46 - SUPPORT BEARING
BDE-N171820.A28
N171820
|
-
|
|
|
|
47 - BEARING & SEAL
BDE-391032-00.A24
391032-00
|
£3.80
|
£4.56
|
|
|
47 - BEARING & SEAL
BDE-391032-00.A25
391032-00
|
£3.80
|
£4.56
|
|
|
48 - BAFFLE
BDE-610124-01.A3
610124-01
|
£4.69
|
£5.63
|
|
|
48 - BAFFLE
BDE-610124-01.A4
610124-01
|
£4.69
|
£5.63
|
|
|
49 - BRUSHBOX SA
BDE-610126-00.A19
610126-00
|
£7.85
|
£9.42
|
|
|
49 - BRUSHBOX SA
BDE-610126-00.A20
610126-00
|
£7.85
|
£9.42
|
|
|
50 - SCREW
BDE-330019-25.A8
330019-25
|
£1.50
|
£1.80
|
|
|
50 - SCREW
BDE-330019-25.A9
330019-25
|
£1.50
|
£1.80
|
|
|
51 - GEARCASE SA
BDE-N068175SV.A2
N068175SV
|
£47.08
|
£56.49
|
|
|
51 - GEARCASE SA
BDE-N068175SV.A3
N068175SV
|
£47.08
|
£56.49
|
|
|
52 - SCREW
BDE-330045-45.A65
330045-45
|
£1.50
|
£1.80
|
|
|
52 - SCREW
BDE-330045-45.A66
330045-45
|
£1.50
|
£1.80
|
|
|
71 - RATING PLATE GB
BDE-N107523
N107523
|
-
|
|
|
|
72 - DUST PORT OPTIONAL
BDE-N104672.A2
N104672
|
£5.88
|
£7.06
|
|
|
72 - DUST PORT
BDE-N104672.A3
N104672
|
£5.88
|
£7.06
|
|
|
73 - SCREW OPTIONAL
BDE-N106370.A0
N106370
|
£1.50
|
£1.80
|
|
|
73 - SCREW
BDE-N106370.A1
N106370
|
£1.50
|
£1.80
|
|
|
800 - GREASE 90 GMS
BDE-870889-02.A733
870889-02
|
£7.85
|
£9.42
|
|
|
800 - GREASE
BDE-283484-01.A27
283484-01
|
£80.98
|
£97.18
|
|
|
856 - GUIDE FENCE GB
BDE-381091-01.A2
381091-01
|
£3.80
|
£4.56
|
|
|
856 - GUIDE FENCE OPTIONAL
BDE-381091-01.A3
381091-01
|
£3.80
|
£4.56
|
|
|
861 - KITBOX OPTIONAL
BDE-N153976.A6
N153976
|
£78.12
|
£93.74
|
|
|
861 - KITBOX
BDE-N153976.A7
N153976
|
£78.12
|
£93.74
|
|
|
862 - SPRING CLIP OPTIONAL
BDE-605265-00.A13
605265-00
|
£12.17
|
£14.60
|
|
|
862 - SPRING CLIP
BDE-605265-00.A14
605265-00
|
£12.17
|
£14.60
|
|
|
866 - BATTERY 18V - 4.0AH - 72WH DCS391L2 GB
BDE-N195933.A31
N195933
|
£218.32
|
£261.98
|
|
|
866 - BATTERY 18V - 4.0AH - 72WH DCS391M2 GB
BDE-N195933.A32
N195933
|
£218.32
|
£261.98
|
|
|
871 - CHARGER 10.8V - 18V GB
BDE-N450537.A61
N450537
|
£157.18
|
£188.61
|
|
