101 - NO LONGER AVAILABLE LX
BDE-000000-00.A91089
000000-00
|
-
|
|
|
|
101 - ARMATURE SA GB
BDE-393921-07.A15
393921-07
|
£41.24
|
£49.49
|
|
|
102 - NO LONGER AVAILABLE LX
BDE-000000-00.A91090
000000-00
|
-
|
|
|
|
102 - FIELD 230V GB
BDE-605527-02.A0
605527-02
|
£30.08
|
£36.10
|
|
|
103 - SWITCH
BDE-945614-00.A136
945614-00
|
-
|
|
|
|
104 - NO LONGER AVAILABLE LX
BDE-000000-00.A91091
000000-00
|
-
|
|
|
|
104 - BRUSH 115V
BDE-949647-01.A1
949647-01
|
-
|
|
|
|
104 - BRUSH 230V GB
BDE-949647-02.A7
949647-02
|
£9.41
|
£11.29
|
|
|
105 - CABLE GB
BDE-562226-09.A12
562226-09
|
-
|
|
|
|
105 - CABLE XW
BDE-562226-07.A9
562226-07
|
£57.22
|
£68.66
|
|
|
105 - NO LONGER AVAILABLE
BDE-000000-00.A91092
000000-00
|
-
|
|
|
|
106 - OUTER FLANGE
BDE-622613-02.A31
622613-02
|
£4.69
|
£5.63
|
|
|
107 - INNER FLANGE
BDE-391969-00.A84
391969-00
|
£1.82
|
£2.19
|
|
|
108 - SCREW
BDE-562160-06.A18
562160-06
|
£1.50
|
£1.80
|
|
|
109 - RETAINING PLATE
BDE-605415-00.A127
605415-00
|
-
|
|
|
|
110 - NO LONGER AVAILABLE
BDE-000000-00.A91093
000000-00
|
-
|
|
|
|
110 - GUARD
BDE-944586-00.A59
944586-00
|
£3.30
|
£3.96
|
|
|
111 - RING
BDE-393576-00.A7
393576-00
|
£1.50
|
£1.80
|
|
|
112 - SCREW
BDE-330045-46.A34
330045-46
|
£1.50
|
£1.80
|
|
|
113 - GEARCASE COVER
BDE-390521-00.A29
390521-00
|
-
|
|
|
|
114 - NO LONGER AVAILABLE
BDE-000000-00.A91094
000000-00
|
-
|
|
|
|
114 - SPINDLE
BDE-391971-00.A18
391971-00
|
-
|
|
|
|
116 - CORD PROTECTOR LX
BDE-401088-03.A1
401088-03
|
£1.50
|
£1.80
|
|
|
116 - CORD PROTECTOR GB
BDE-N542553.A380
N542553
|
£3.80
|
£4.56
|
|
|
117 - GEAR & PINION GB
BDE-945295-02.A16
945295-02
|
£19.90
|
£23.88
|
|
|
117 - GEAR & PINION LX
BDE-945295-02.A17
945295-02
|
£19.90
|
£23.88
|
|
|
118 - SCREW
BDE-562097-01.A50
562097-01
|
£1.50
|
£1.80
|
|
|
121 - SIDE HANDLE
BDE-573115-00.A8
573115-00
|
£2.78
|
£3.34
|
|
|
122 - FLANGE
BDE-403156-00.A3
403156-00
|
£1.42
|
£1.70
|
|
|
123 - NUT
BDE-945292-00.A67
945292-00
|
£1.50
|
£1.80
|
|
|
124 - BUTTON
BDE-944574-00.A72
944574-00
|
£1.50
|
£1.80
|
|
|
125 - SPRING
BDE-562210-00.A44
562210-00
|
£1.50
|
£1.80
|
|
|
126 - SPINDLE LOCK
BDE-944571-00.A16
944571-00
|
-
|
|
|
|
127 - BEARING
BDE-605040-22.A112
605040-22
|
£4.69
|
£5.63
|
|
|
128 - SLEEVE
BDE-641823-00.A95
641823-00
|
£1.50
|
£1.80
|
|
|
129 - BAFFLE SA
BDE-401635-00.A38
401635-00
|
-
|
|
|
|
130 - BUFFER
BDE-949638-01.A141
949638-01
|
£1.50
|
£1.80
|
|
|
132 - BRUSH HOLDER
BDE-606574-00.A2
606574-00
|
£7.18
|
£8.62
|
|
|
133 - SPRING
BDE-562204-00.A23
562204-00
|
£1.50
|
£1.80
|
|
|
134 - NO LONGER AVAILABLE
BDE-000000-00.A91095
000000-00
|
-
|
|
|
|
135 - BEARING
BDE-605040-02.A159
605040-02
|
£2.26
|
£2.71
|
|
|
136 - END CAP
BDE-394938-01.A11
394938-01
|
-
|
|
|
|
137 - SUPPORT
BDE-611540-00.A6
611540-00
|
£1.50
|
£1.80
|
|
|
138 - WRENCH
BDE-401680-00.A65
401680-00
|
£4.69
|
£5.63
|
|
|
139 - SCREW
BDE-562097-05.A54
562097-05
|
£1.50
|
£1.80
|
|
|
140 - FLANGE
BDE-401622-01.A24
401622-01
|
£1.50
|
£1.80
|
|
|
141 - SPACER INSULATING
BDE-398906-00.A57
398906-00
|
£1.50
|
£1.80
|
|
|
145 - SCREW
BDE-562097-00.A167
562097-00
|
£1.50
|
£1.80
|
|
|
150 - NO LONGER AVAILABLE
BDE-000000-00.A91096
000000-00
|
-
|
|
|
|
160 - BEARING
BDE-N110359.A83
N110359
|
£3.75
|
£4.50
|
|
|
160 - BEARING
BDE-390821-01.A0
390821-01
|
£3.30
|
£3.96
|
|
|
162 - LINK
BDE-611737-00.A7
611737-00
|
£1.42
|
£1.70
|
|
|
162 - SERVICE KIT
BDE-N413824.A6
N413824
|
-
|
|
|
|
163 - BUTTON
BDE-569624-01.A10
569624-01
|
£1.50
|
£1.80
|
|
|
163 - SERVICE KIT
BDE-N413824.A7
N413824
|
-
|
|
|
|
164 - SCREW
BDE-562097-13.A21
562097-13
|
£1.50
|
£1.80
|
|
|
165 - SERVICE KIT
BDE-610704-00.A2
610704-00
|
£17.48
|
£20.97
|
|
|
800 - GREASE
BDE-286436-00.A192
286436-00
|
£126.63
|
£151.96
|
|
|
816 - RATING PLATE
BDE-569037-00.A116
569037-00
|
£3.80
|
£4.56
|
|
|
821 - BRAND LABEL
BDE-946194-00.A7
946194-00
|
£1.50
|
£1.80
|
|
